Summary of Contents for Arenti VBELL 1

  • Page 1: Vbell 1

    VBELL 1...

  • Page 2: Table Of Contents

    Set Tamper Alarm ..........................21 Recording and Playback ....................... 22 Micro SD card Recording ......................... 22 Cloud storage service ........................23 Playback ..............................25 Album ..............................28 Camera settings ..........................29 Camera Name ............................29 Share Arenti Devices with others ....................29...

  • Page 3: Video Doorbell Introduction

    Wireless Chime ..........................36 Amazon Echo Show & Google Home ..................37 Device version ............................38 Delete the Device ..........................39 Use Arenti APP ..........................40 Messages ............................... 40 Sharing History ..........................41 Alarm Message ..........................41 System Messages ........................... 41 Scene ...............................

  • Page 4: Status Indicator

    Status Indicator Front Status Indicator Camera status No light on Not power /stand by Constant blue/slow flashing Working properly/ WiFi Connection succeeded Blue fast flashing Upgrading Red flashing slowly Waiting to connect/ WiFi is not configured Red flashing fast Network abnormal/ WiFi connection failed Charge Doorbell Take off the rubber, plug in the Micro-USB charge the camera.
  • Page 5 Scan QR code or search ‘Arenti on App Store (IOS); Play Store (Android). Download and install Arenti APP. Open the APP tap ‘Sign up’’ to create and account and log in. Open the Arenti APP home page, Click’+’ at the right top page. Follow the guide on the APP to add the camera.
  • Page 6 2. Waiting for camera to boot up around 10s. Press the Bell,confirm camera is working. Make sure the network indicator red flashing slowly and enable it . If not, please reset the camera(move thecamera head and u top find the reset bottom), then wait the network indicator red flashing slowly.
  • Page 7 4. APP will generate the QR code for camera to scan. Keep your phone 5-8 inches(15- 25cm) from the lens . Please scan the QR code when indicator in red flashing slowly. 5. A tone will be heard when successfully scanned. Then tap ‘Notification tone heard’ After reading QR code, camera get the WiFi information(name/password) from APP QR code, and start to connect the WiFi.

  • Page 8: Install The Doorbell

    6. Around 10-30s later, the camera indicator turns to constant blue, means camera connect the WiFi. And APP will find the device and add it to APP. Tap ‘Done’ to finish the process. Note: When adding the camera, ensure the WIFI network is good, the camera is normally turned on, and the indicator light flashes red slowly.
  • Page 9 Note: the back plate is fixed on the back of the door bell,please release the back plate screw, and take off the back plate before install it. Install with screws: Install with 3M Stickers:...

  • Page 10: Pair The Chime

    Installation Precautions: To prevent injury, the unit must be securely fastened to the wall by the installation instructions Pair the Chime LED indicator of chime: Flashing red light -- Wait for pairing Fixed blue light --- Succeed to pair Install the battery or plug in the cable to power on the camera: 1.

  • Page 11: View Your Camera

    3. View Your camera Home page privacy Multiple views Play Camera Live video Play camera history video Get technical support Add new device Video audio ON/OFF Manually capture, the image will save to the album Full screen mode Manually record, the recording will save to the album Device Wi-Fi signal Sub-stream mode...

  • Page 12: Multiple Views

    Press and hold to move the camera to the sequence you need. Then tap Done ,back to the device list. Multiple Views If you have 2 or more cameras added in your Arenti App, you can view multiple streams at the same time.

  • Page 13: Live Video

    icon , the first 4 cameras will show in one screen. You can slide the screen to check next 4 camera. You can choose camera to 2-way audio, Manual capture, record. Live video Icon to view the camera Live video. Tap the SD to choose SD/HD different resolution.

  • Page 14: Pick Up The Ring Call

    After visitor pressing the Bell, you will receive the notification of the call, and tap the notification, will open the Arenti APP. You can choose to answer or hang up the call. After picking up the phone, you will possible to talk with the person at front the doorbell.

  • Page 15: Manually Capture

    Manually Capture icon to capture the image. Image will save in Album. Manually Record icon to start record the video, tap to stop the record, the record will save in Album.

  • Page 16: Full Screen

    Full Screen icon to check the video in full screen.

  • Page 17: 2-Way Audio

    Go to camera live video page- Settings-Alert Settings-Motion detection-On Battery camera equipped PIR sensor , It will detect the body heat from 2~10 meters. And you can customize the detection range to meet your needs. Set from Arenti APP-Device (tap device to live video page)-Settings-Alert settings- Motion Detection-Sensitivity...

  • Page 18: Human Shape Detection

    Sensitivity Detection range Level 1-2 (Low) Up to 2-5 meters Level 3 (Mid) Up to 5-8 meters Level 4-5 (High) Up to 8-10 meters Note: sun's rays, cars, animal, other heat source will trigger the pir sensor and cause the false alarms.

  • Page 19: Alert Plan

    Alert Plan User can set the time period of the alarm, the device only triggers alarm event during the time period...

  • Page 20: Set Up Push Notifications

    Your mobile phone will receive the Alarm notification when camera detect the motion. 2. Set your phone to allow Arenti App to send push notifications. Go to your phone Settings, find Notifications and among the App list find the Arenti App. Make sure the mobile phone allow the Arenti App send notifications.

  • Page 21: Set Tamper Alarm

    Set Tamper Alarm Set the Tamper Alarm, after enable it. If the doorbell is ddismantled, doorbell will make a sound alert and a notification will send to user APP.

  • Page 22: Recording And Playback

    ‘Click ‘sound. Set Recording(Micro SD card) 1. Event recording: Arenti APP-Device(tap device to live video page)-Settings-Recording Management- Event recording-Choose the Recording time-10/20/30 sseconds Note: It will only record the motion alarm recordings to the SD card. Each event...

  • Page 23: Cloud Storage Service

    Cloud storage service Arenti will give away 3 months free event cloud storage service for each camera. Each device needs its own plan, Cloud Storage Service Fee will be charged per device. Note: the rules may change in the future Activate Cloud storage service 1.
  • Page 24 2. End free trial event cloud storage service Arenti APP-Device(Tap device to live video page)-Settings-Could Storage Service-End trial 3. Buy/renew the event cloud storage service plan Tap Buy/Renew Plan icon to order the cloud storage service for your device. Set recording-Cloud storage...

  • Page 25: Playback

    1. Event recording: You can use the free trial or buy/renew the event cloud storage service plan to save the motion alarm recordings to the cloud storage 2. Full day recordings: You can buy/renew the event cloud storage service plan to save the Continuous recordings to the cloud storage Note: Please end trial the free event cloud storage service first, then camera will start the service that you bought.
  • Page 26 2. Tap icon to select a date to search the recordings. Tap the icon to scale timeline and slide to find the recordings you want to replay, waiting for loading and it’ll automatically start to play. 3. Tap ‘Alert’ to search and play alarm recordings.
  • Page 27 4. Playback from the Alarm messages. Go to Messages-Alarm messages-Device, choose the messages, tap icon to play the recording.

  • Page 28: Album

    Album You can browser all picture/video that captured manually in album. Also you can share the video/picture in album.

  • Page 29: Camera Settings

    6. Camera settings Camera Name You can rename the camera Arenti APP-Device(Tap device to live video page)-Settings-Device name,after you input the new name,tap OK to save. Share Arenti Devices with others 1. Arenti APP-Device (Tap device to live video page)-Settings-Device Share-Add-...
  • Page 30 2. Launch the Arenti APP in another mobile phone and tap Me-Qrcode. Scan the Qrcode to share the device. Also you can manually input the user account to share the device.And accept the shared device on another mobile phone.

  • Page 31: Device Information

    Your friends account could access the Live video, recordings in SD card(not allowed via cloud storage) Device information You can check the camera information from: Arenti APP-Device (Tap device to live video page)-Settings-Device information: Network Name, Signal Strength, Virtual ID,IP, Mac Address, Time zone.

  • Page 32: Installation Guide

    Installation Guide Check from: Arenti APP-Device (Tap device to live video page)-Settings-Device information APP will guide you to install the camera in a good wifi position, to keep camera working properly.

  • Page 33: Basic Function

    Basic function Speaker volume Basic function>Speaker volume Support user adjust camera speaker volume...

  • Page 34: Voice Message

    Voice Message Record a Voice message when you are not convenience to answer the ring call. You can tap the message icon when you are in pick up page. Doorbell will play the voice message that you recorded before.

  • Page 35: Time Setting

    Time setting Support to change the time format switch to 12h/24h Night Vision Set the camera’s color mode during different times of the day and night. When night vision is on, the infrared light will turn on also--to get clear Black&White image in the night. Automatic: The camera will automatically switch between Color and Black &...

  • Page 36: Power Management

    Power Management Check the camera Power Supply Mode/Remaining Battery (%) from Power Management. Wireless Chime Support to choose whether let the Chime rings.

  • Page 37: Amazon Echo Show & Google Home

    After bind, you can check the camera Live video on Amazon Device and Google Home device. Note: User name is the account name (email address/phone number) in Arenti APP and it is case sensitive. Need use lower case. Please do not use the auto-filling, input the information manually.

  • Page 38: Device Version

    Device version You can check the camera firmware whether need to be upgraded.

  • Page 39: Delete The Device

    If have new firmware to be upgraded, you can tap ‘upgrade’ to upgrade the camera firmware. Note: Whole upgrading process may take 5min, Please do not power off the camera when upgrading, camera will download the firmware from server and upgrade the firmware. Suggest keep camera near the wifi router for the better network to download.

  • Page 40: Use Arenti App

    7. Use Arenti APP Messages Tap the Messages at the bottom.

  • Page 41: Sharing History

    Sharing History Tap Sharing History to check the sharing messages Alarm Message Tap Alarm Messages-Device-check the Alarm message sent from camera System Messages Tap System Messages to check the battery low messages.

  • Page 42: Scene

    Scene No device support now. Coming soon. Account Register (Sign up) 1. Open the Arenti App, click "Sign Up, Choose the country and input email address; enable the "User agreement and Privacy Policy" ,tap ‘Next...
  • Page 43 2. Set the Nickname and Password, tap ‘Done’. Reset Password 1. Tap the ‘Forget password’ 2. Input the correct Email address/Phone number, tap ‘Next’ 3. Input the verification code you received, and input the new password you want to set. Done...

  • Page 44: App Settings

    APP Settings Launch APP tap Me-Settings:You can adjust the APP settings. 1. Pop up when receiving a message After enable and APP is opened, a pop-up page will be displayed when an alarm message is received.
  • Page 45 Turn on Hardware decoding 3. Call Ringtone 4. Play video in small window. The window will possible always top, when you using other APP on mobile phone. You can keep watch the camera Live video. 5. Message Service resident Enable the ‘Message Service resident ‘, APP will run in the background to facilitete receiving visitor calls and Alarm messages.
  • Page 46 6. Clear Cache Tap ‘Clear Cache’- delete Alarm pictures/Temporary Files 7. Deactivate Account Tap to Deactivate Account...

  • Page 47: Faq And Troubleshooting

    2. Please ensure the Message service resident (Arenti APP-Me-Settings) is enabled. The APP will Automatically run in the background to facilitate receiving visitor calls and alarm messages. 3. Please ensure notification for Arenti app has been enabled in phone setting. enter the phone system settings-notifications-find "Arenti" and enable notification permissions.

  • Page 48: Troubleshooting

    3. My camera not working, after powering on/plug in ,there is no indicator light Please try to use the other adapter/cable and check again, if keep no light on, please send the camera SN and order number to support@arenti.com 4. Why does the video always with the circle/buffering? The circle means that the video is loading, and the buffer and delay means that the network is not smooth.
