Page 1 User's Guide (Copy Part) Network Multi-Function Plotter LP-1020-MF LP-1020L-MF Read this User's Guide to use the plotter safely and properly. Keep this manual in a place where you can quickly access it at any time. Seiko I Infotech Inc.
Page 3 U00107747800 November 2007 ©Seiko I Infotech 2007 Reprinting of this manual without permission is prohibited. The content of this manual may be changed without notice. D-SCAN is a registered trademark of Seiko Instruments, Inc. Ethernet is a registered trademark of Xerox, Inc.
Page 5 Introduction Thank you for purchasing our LP-1020-MF, LP-1020L-MF Network Multi- Function Plotter (here referred to as “this device”). This manual describes an operating method of the copy function, delivery function, and file function provided by this device. For the print function, paper loading, replacement of consumables, and paper jam clearings, see the "User's Guide (Plotter Unit)"...
Page 6: Safety Precautions
Safety precautions The following symbols are used in this manual to ensure the proper use of the plotter and to prevent the plotter from being damaged. Please follow these guidlines: Warnings must be followed carefully to avoid serious WARNING bodily injury or death. Cautions must be observed to avoid damage to your CAUTION equipment and bodily injury.
Page 7 Warning DO NOT touch any of the parts inside the plotter with a "HIGH VOLTAGE" label attached as it may result in electric shock. DO NOT touch any of the parts inside the plotter with a "HIGH TEMPERATURE" label attached as it may result in severe burns. DO NOT disassemble or modify the plotter.
Page 8 Caution DO NOT disassemble, modify the toner cartridge. If toner gets on your skin or clothes, wash off the affected area immediately with soap and water. Handle the toner cartridge with extreme care. Should any toner get into your eyes, do not rub them, flush them immediately with water, and see a physician immediately.
Page 9: How To Read This Manual
How to read this manual Notation method Markings Warning ◆ This mark indicates warnings that must be followed carefully to avoid serious bodily injury or death. Caution ◆ This mark indicates cautions that must be observed to avoid damage to the equipment and bodily injury. Note ◆...
Page 10 Key/LCD/LED notations Indicates a control panel key. Press the [ZOOM] key. If the [ZOOM] key is pressed, the screen switches over to the ZOOM setting screen. Z o om ( %) 1 0 0 . 0 ( 2 5 . 0 - 4 0 0 . 0 ) [ E n t e r ] t o S e t Expresses the selected item.
Page 11: Table Of Contents
TABLE OF CONTENTS Introduction Safety precautions ................ii How to read this manual ..............v Chapter 1 Getting started Restrictions on Copying ..............1-2 Control panel ................... 1-3 Multi-functions .................. 1-7 Print function ............... 1-7 Copy function ..............1-7 Delivery function ..............1-7 File function .................
Page 12 Routine maintenance ..............1-22 Cleaning the scanning are and scanner glass ....1-22 Chapter 2 Copy function Flow of copy operation ..............2-2 Flow of manual feed copy ..............2-4 Copy function overview ..............2-6 Select original size ................2-7 Operation steps ..............
Page 13 Select paper fed location ............... 2-28 Operation steps ..............2-28 Selecting paper type ..............2-29 Operation steps ..............2-29 Enter number of copies ..............2-31 Operation steps ..............2-31 Add margin ..................2-32 Operation steps ..............2-32 Move original position ..............2-35 Operation steps ..............
Page 14 Mirror ..................... 2-56 Operation steps ..............2-56 Reverse ..................2-58 Operation steps ..............2-58 Copying long original ..............2-60 Operation steps ..............2-61 Sorting ................... 2-63 Operation steps ..............2-63 Reset ..................... 2-66 Operation steps ..............2-66 Reprint ................... 2-67 Operation steps ..............
Page 15 Flow of delivery operation ..............3-7 Delivery function overview ............. 3-10 Select original size ................. 3-11 Operation steps ..............3-15 Select original type ................ 3-16 Operation steps ..............3-17 Adjust background ................. 3-18 Operation steps ..............3-19 Adjust density ................3-20 Operation steps ..............
Page 16 Designate resolution ..............3-32 Operation steps ..............3-32 Compress image data when transferred........3-34 Operation steps ..............3-34 Reset ..................... 3-36 Operation steps ..............3-36 Chapter 4 Memory function Memory function overview ............... 4-2 Save settings to memory ..............4-3 Operation steps ..............
Page 17 Chapter 5 File function File function ..................5-2 Preparation before using file function ..........5-3 Checking network connection of the device ......5-3 Installing exclusive application ..........5-3 Screens of file function ..............5-4 Busy wait screen ..............5-4 Occupancy display screen ..........5-4 Scan start wait screen ............
Page 19: Chapter 1 Getting Started
Chapter 1 Getting started Chapter 1 provides necessary information to operate this device. Read this chapter to understand the basics of this device before proceeding to the following chapters. Contents of this chapter Restrictions on copying Control panel Multi-functions Main functions Original How to input an original Routine maintenance...
Page 20: Restrictions On Copying
Restrictions on Copying Note that the copying of some items may be limited or prohibited by law. Copying of the following items is prohibited by law. • Bank bills, coins, securities, government-issued marketable securities, government bond securities, municipal securities (including those stamped “sample”). •...
Page 21: Control Panel
Control panel ▼Control panel The keys, LEDs and LCD are laid out on the control panel as illustrated in the following diagram. WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE...
Page 22 ● [COPY] key The COPY mode is selected and the LED on the side of the key turns on. For details, see Chapter 2. ● [DELIVERY] key The DELIVERY mode is selected and the LED on the side of the key turns on.
Page 23 ▼Control panel WASTE TONER TONER These LEDs indicate the status of the device. PROCESS MANUAL FEED ● [TONER] LED Indicates the toner status. On: There is sufficient toner. DATA ERROR Flashing: Toner is running low. Off: There is no toner (plots cannot be produced without replacement.) ●...
Page 24 ● [ERROR] LED This LED indicates whether an error condition has occurred. ON: An error exists. OFF: No error BACKGROUND ORIGINAL ORIGINAL SIZE TYPE REMOVAL DENSITY SCALE x1 PAPER AUTO TEXT/LINE FEED DARK FIXED SCALE FIXED-SIZE ORIGINAL TEXT/PHOTO PORTRAIT FIXED-SIZE IMAGE PHOTO NORMAL...
Page 25: Multi-Functions
Multi-functions This device provides the print, copy, delivery, and file functions. Any of these functions can be selected by a single key operation. Print function Graphic data created by a workstation or personal computer (hereinafter called the computer) are received and printed. For details, see “User's Guide, Plotter Units.”...
Page 26: File Function
File function From a computer connected via network, image data scanned by this device can be received using the exclusive application. For details, see Chapter 5.
Page 27: Main Functions
Oyama PART NO. 123456789 SHEET Tanaka Shimano Ioka Oyama PART NO. 123456789 SHEET Seiko I Infotech Inc. Design Department DRAWING NO. 123456789 PAGE Seiko I Infotech Inc. Design Department DRAWING NO. 123456789 PAGE Original having colored background ■ Copy/Delivery by erasing background 4-R2.0...
Page 28 Shimano Ioka Oyama PART NO. 123456789 SHEET A4 long PAGE A4 long PAGE Seiko I Infotech Inc. Design Department DRAWING NO. 123456789 Seiko I Infotech Inc. Design Department DRAWING NO. 123456789 Bottom Vertical direction Horizontal direction 4-R2.0 ■ Copy by shifting 4-R2.0...
Page 29 APPROVED BY CHECKED BY SIGNED BY DRAWN BY PART NO. 123456789 SHEET Tanaka Shimano Ioka Oyama Seiko I Infotech Inc. Design Department DRAWING NO. 123456789 PAGE ■ Copy/Delivery by 4-R2.0 4-R2.0 reversing the original 50.0 50.0 (⇒ pages 2-58, 3-30)
Page 30: Original
Acceptable original size and thickness Maximum width: 914.4 mm (36 inches) Minimum width: 182 mm (7.2 inches) Maximum length: 2,500 mm (98.4 inches) (LP-1020-MF) 10,000 mm (393.7 inches) (LP-1020L-MF) (LP-1020-MF+Functional extension kit LP-815) Minimum length: 210 mm (8.3 inches) Thickness: 0.05 - 0.2 mm (0.002 - 0.008 inches), non-transparent or semi-...
Page 31: Unacceptable Originals
▼Original · Taped or glued original · Original with poor straightness at the top · Original such as photo that easily sticks to the glass · Original written with a pencil that may soil the glass by being rubbed In addition, use a carrier sheet if non-fixed size original is to be read in the fixed size.
Page 32: Scanning Area
Scanning Area This device can scan the original except for a border area of 5 mm (0.2 inches) at the top and bottom and 3 mm (0.12 inches) on both sides respectively. 5mm (0.2 inches) (0.12 inches) Maximum (0.12 inches) 1219.2 mm ...
Page 33: How To Input An Original
How to input an original ▼How to input an original This paragraph describes how to input an original. How to input an original Adjust the position of the original width guide. Adjust the original width guide to the applicable line according to the original size.
Page 34 Input the original. Input the original facedown along the original width guide. The inserted original is automatically pulled in the device. ◆ Butt the original against the front Roller Slack roller and give it some slack, so that the original can be inserted straight.
Page 35: Removing Original Reject Guide
▼How to input an original Removing original reject guide ■Removing scanner exit guide When scanning a long original or rounded original, remove the scanner exit guide before scanning. Open the scanner cover. Lift the scanner cover up to its stop position. Pull the stopper towards the arrow direction and raise the scanner cover.
Page 36 Close the scanner cover. Stopper While supporting the scanner cover with your right hand, release the stopper with your left hand and close the scanner cover slowly. Close the scanner cover completely until it clicks. 1-18...
Page 37: How To Scan Originals With A Crease
▼How to input an original ■Removing the original width guide If the return of the original is changed between front and rear exit frequently, remove the original width guide in advance. Hook your finger on the claw at the bottom and while opening the claw, pull towand you, and the original width guide will be removed.
Page 38 Close the scanner cover. Stopper While supporting the scanner cover with your right hand, release the stopper with your left hand and close the scanner cover slowly. Close the scanner cover completely until it clicks. 1-20...
Page 39: Cancel The Scanning Of Original
▼How to input an original Input the original. Close the scanner cover, and set the original facedown. ◆ If the shadow of the crease still appears in the scanned output, the shadow may be reduced by reversing the inputting direction of the original. Cancel the scanning of original To cancel the scanning because of the feed isn’t straight or the original jams, do the following:...
Page 40: Routine Maintenance
Routine maintenance The scanning area may become soiled by originals, thus requiring regular cleaning. Note ◆ Never use volatile solvents such as thinner, benzine, and alcohol. Cleaning the scanning are and scanner glass Wipe the shading guide and scanner glass with a dry cloth. If extremely dirty, use the cloth dampened with water or neutral detergent diluted with water and then wrung dry.
Page 41: Chapter 2 Copy Function
Chapter 2 Copy function This section describes the copy function of the device. Contents of this chapter Flow of copy operation Flow of manual feed copy Copy function overview Select original size Select original type Adjust background Adjust density Set scale Performing auto reduction Select paper fed location Selecting paper type...
Page 42: Flow Of Copy Operation
Flow of copy operation This paragraph describes the basic operation flow when an original is copied. Select the original size. Select the original size. (For details, see page 2-7.) Select the original type. Select what image type the original is. (For details, see page 2-13.) Adjust the background.
Page 43 ▼ Flow of copy operation Enter the number of copies. Enter the desired number of copies. (For details, see page 2-31.) Input the original. Input the original to the device. (For details, see page 1-15.) Press the [START] key. Press the [START] key. If the SCAN START has been set to the ORIGINAL SET in the system menu, the copy/delivery starts automatically without pressing the [START] key.
Page 44: Flow Of Manual Feed Copy
Flow of manual feed copy This paragraph describes a basic operation flow when an original is copied on the manually fed paper. Select the original size. Select the original size. (For details, see page 2-7.) Select the original type. Select what image type the original is. (For details, see page 2-13.) Adjust the background.
Page 45 ▼ Flow of manual feed copy Set the location of paper feed to “MANUALS.” Set so that the original can be copied on the paper set on the manual paper feeding holder of the device. (For details, see “User's Guide ( Plotter Unit)”...
Page 46: Copy Function Overview
Copy function overview The copy functions provided by this device are as listed below. Detailed setting steps are described on the following pages. Function list Description Original Size Sets the original size. Original Type Selects the image type according to the original. Background Removal Removes the background color.
Page 47: Select Original Size
◆ If the original size is set to “AUTO”, the MARGIN (⇒ page 2-32), FramErase (⇒ page 2-44), and MOVE (⇒ page 2- 35) settings are ineffective. ◆ For the LP-1020-MF without optional HDD, if the original size is set to “AUTO” or “SYNCHRO”, continuous scanning of the original cannot be performed.
Page 48 The original sizes applicable to this device are as listed below: A series fixed form original Name of Lengthwise length Widthwise length Settable direction fixed form 1189 mm (46.8 inches) 841 mm (33.1 inches) Portrait 841 mm (33.1 inches) 594.5 mm (23.4 inches) Portrait/Landscape 594.5 mm (23.4 inches) 420.5 mm (16.6 inches) Portrait/Landscape...
Page 49 ▼ Select original size 8.5× 11 series fixed form original Name of Lengthwise length Widthwise length Settable direction fixed form 1117.6 mm 863.6 mm Portrait (44 inch) (34 inch) 863.6 mm 558.8 mm Portrait/Landscape (34 inch) (22 inch) 558.8 mm 431.8 mm Portrait/Landscape (22 inch)
Page 50 Map series fixed form original Name of Lengthwise length Widthwise length Settable direction fixed form 1000.0 mm 700.0 mm Portrait (39.4 inches) (27.6 inches) 700.0 mm 500.0 mm Portrait/Landscape (27.6 inches) (19.7 inches) Map series width original Name of Paper width Original min.
Page 51 ▼ Select original size China series width original Name of Paper width Original min. length Original max. length width 914 mm width 914 mm (36 inches) 910 mm width 910 mm (35.8 inches) *LP-1010-MF 900 mm width 900 mm (35.4 inches) 2,500 mm (98.4 inches) 880 mm width...
Page 52: Operation Steps
Operation steps Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER TONER TONER AUTO TEXT/LINE FEED PROCESS DARK MANUAL FEED FIXED SCALE FIXED-SIZE TEXT/PHOTO...
Page 53: Select Original Type
SHEET Tanaka Shimano Ioka Oyama PART NO. 123456789 SHEET Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE ◆ For the original with dark background and thin lines, select “BLUE PRINT”...
Page 54: Operation Steps
Operation steps Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER TONER AUTO TEXT/LINE TONER FEED PROCESS MANUAL FEED DARK FIXED SCALE FIXED-SIZE ORIGINAL...
Page 55: Adjust Background
SHEET 123456789 SHEET Tanaka Shimano Ioka Oyama PART NO. Tanaka Shimano Ioka Oyama PART NO. Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE 4-R2.0 4-R2.0 4-R2.0 4-R2.0 50.0 4-R2.0...
Page 56: Operation Steps
Operation steps Keys used POWER WARNING LIGHT MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND DENSITY SCALE x1 SIZE TYPE REMOVAL WASTE PAPER TONER TONER AUTO TEXT/LINE FEED PROCESS DARK MANUAL FEED FIXED SCALE FIXED-SIZE TEXT/PHOTO...
Page 57: Adjust Density
UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY 123456789 Tanaka Shimano Ioka Oyama PART NO. SHEET Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE Dark Normal Light 4-R2.0 4-R2.0 4-R2.0 50.0 50.0 50.0 XXXXXXXXX XXXXXXXXX...
Page 58: Operation Steps
Operation steps Keys used POWER WARNING LIGHT MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND DENSITY SCALE x1 SIZE TYPE REMOVAL WASTE PAPER TONER TONER AUTO TEXT/LINE FEED PROCESS DARK MANUAL FEED FIXED SCALE FIXED-SIZE TEXT/PHOTO...
Page 59: Set Scale
CHECKED BY SIGNED BY DRAWN BY XXXXXXXXX Tanaka Shimano Ioka Oyama PART NO. 123456789 SHEET MODEL PAGE Seiko I Infotech Inc. Design department DRAWING NO. 123456789 SCALE UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY Tanaka Shimano...
Page 60: Operation Steps (Scale ¥1)
Operation steps (SCALE ×1) Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER TONER AUTO TEXT/LINE TONER FEED PROCESS MANUAL FEED DARK FIXED SCALE FIXED-SIZE...
Page 61: Operation Steps (Fixed Scale)
▼ Set scale Operation steps (FIXED SCALE) Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER TONER TONER AUTO TEXT/LINE FEED PROCESS DARK...
Page 62 Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to the paper size for Print. F i x e d A S c a l e O r i g i n a l : A 1 P r i n t : A1 [ E n t e r ] t o S e t Press the [ ] or [ ] key.
Page 63: Operation Steps (Zoom)
▼ Set scale Operation steps (ZOOM) Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER TONER TONER AUTO TEXT/LINE FEED PROCESS MANUAL FEED DARK...
Page 64: Operation Steps (Non-Proportional Scale)
Operation steps (NON-PROPORTIONAL SCALE) Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER TONER AUTO TEXT/LINE TONER FEED PROCESS MANUAL FEED DARK FIXED SCALE FIXED-SIZE...
Page 65 ▼ Set scale Enter numeric value with the ten keys. Enter the enlargement/reduction ratio in horizontal direction with the ten keys. Numeric values can be entered in a range of 25.0 to 400.0 %. N o n - P r o p S c a l e ( %) V e r t i c a l : 2 0 0 .
Page 66: Performing Auto Reduction
Performing auto reduction The original that cannot be accommodated in the print paper is automatically reduced so that it is accommodated in the print paper. Notes ◆ Setting of Fixed Scale/Zoom/Non-Proportional Scale is disabled, if “Auto” is selected. ◆ Auto reduction is not performed, if original is copied on the manually fed paper.
Page 67 ▼ Performing auto reduction Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to “Scale Mode”. F e e d P a p e r T y p e S c a l e mo d e P a g e : 0 2 / 0 2 [ E n t e r ] t o S e l e c t Press the [Enter] key.
Page 68: Select Paper Fed Location
Select paper fed location Select which paper loaded into this device is to used for printing. Operation steps Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY...
Page 69: Selecting Paper Type
Selecting paper type Select what type of paper is used for copy among those set in the device. Notes ◆ This setting is valid only when the paper location is set to “Auto”. (⇒ page 2-26). Operation steps Keys used WARNING LIGHT POWER COPY...
Page 70 Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the paper type setting screen. F e e d : P a p e r T y p e N o ne N o rmal T r a c e F i l m P a g e : 0 1 / 0 1 [ E n t e r ] t o S e l e c t...
Page 71: Enter Number Of Copies
Enter number of copies Enter the number of copies. Note ◆ If an original is copied on the manually fed paper, the number of copies is ineffective even if entered. Operation steps Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER...
Page 72: Add Margin
Ioka Oyama PART NO. 123456789 SHEET Tanaka Shimano Ioka Oyama PART NO. 123456789 SHEET Seiko I Infotech Inc. Design department DRAWING NO. 123456789 A4 long PAGE Seiko I Infotech Inc. Design department DRAWING NO. 123456789 A4 long PAGE Bottom Note ◆...
Page 73 ▼ Add margin Press the [PAPER FEED] key. If the [PAPER FEED] key is pressed, the screen switches to the PAPER FEED setting screen. F e e d Ma r g i n ( mm) F r ame E r a s e / O f f s e t F r ame E r a s e ( mm) O f f s e t ( mm) P a g e : 0 1 / 0 2 [ E n t e r ] t o S e l e c t...
Page 74 Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to the bottom. F e e d : Ma r g i n ( mm) T o p : 1 0 B o t t om : ( 0 - 1 0 0 ) [ E n t e r ] t o S e t Enter numeric value with the ten keys.
Page 75: Move Original Position
UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY 123456789 Tanaka Shimano Ioka Oyama PART NO. SHEET Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE XXXXXXXXX XXXXXXXXX MODEL MODEL SCALE UNIT XXXXXXXXXXXXXXXXXXXX XXXXXXXXXXXXXXXXXXXX TITLE TITLE KED BY...
Page 76: Operation Steps
Operation steps Keys used WARNING LIGHT POWER MENU COPY PRINT RESET MEMORY POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER TONER TONER AUTO TEXT/LINE FEED PROCESS DARK MANUAL FEED FIXED SCALE FIXED-SIZE TEXT/PHOTO...
Page 77 ▼ Move original position Press the [ ] or [ ] key. Press the [ ] or [ ] key to select the Offset. F e e d : F r ame E r a s e / O f f s e t F r ame E r a s e O f f s e t P a g e : 0 1 / 0 1...
Page 78 Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the Offset setting screen. F e e d : O f f s e t ( mm) V e r t i c a l : + H o r i z o n t a l : + ( - 1 0 0 –1 0 0 ) [ E n t e r ] t o S e t...
Page 79 ▼ Move original position Press the [Enter] key. Press the [Enter] key to complete the setting. C o p y R e a d y SCN : 0 0 CP Y : 0 0 / 0 0 S E T : 0 1 AU TO A 0 A 1 Ma n u a l F e e d 1 0 0 .
Page 80: Partial Copy
Oyama PART NO. 123456789 SHEET A4 long Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE ◆ If you want to take a test copy several times according to the darkness or image quality of original, use this function so that you can check the results from partial copy.
Page 81 ▼ Partrial copy Press the [ORIGINAL] key. If the [ORIGINAL] key is pressed, the screen switches to the ORIGINAL setting screen. O r i g i n a l S e r i e s E j e c t D i r e c t i o n S c a nMe d i a P a r t i a l C o p y (mm) P a g e : 0 1 / 0 1...
Page 82 Press the [ ] or [ ] key. Press the [ ] or [ ] key to select the “Length”. O r i g i n a l : P a r t i a l C o p y (mm) P o s i t i o n : 5 0 L e n g t h : 0 ( 0 –1 0 0 0 0 )
Page 83 ▼ Partrial copy Press the [Enter] key. Press the [Enter] key to complete the setting. Note ◆ For the device not equipped with HDD or if ScanMedia is set to “Memory” (⇒ page 2-60), to take a partial copy that exceeds 1,250 mm (49.2 mm), the settings must be changed as follows in advance.
Page 84: Erase Frame
XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY 123456789 Tanaka Shimano Ioka Oyama PART NO. SHEET Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE 4-R2.0 50.0 XXXXXXXXX MODEL SCALE UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY...
Page 85: Operation Steps
▼ Erase frame Operation steps Keys used POWER WARNING LIGHT MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER TONER TEXT/LINE TONER AUTO FEED PROCESS DARK MANUAL FEED FIXED SCALE...
Page 86 Press the [ ] or [ ] key. Press the [ ] or [ ] key to select FrameErase. F e e d : F r ame E r a s e / O f f s e t F r ame E r a s e O f f s e t P a g e : 0 1 / 0 1 [ E n t e r ] t o S e t...
Page 87 ▼ Erase frame Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the FrameErase setting screen. F e e d : F r ame E r a s e ( mm) T o p : 0 B o t t om : 0 L e f t : 0 R i g h t : 0...
Page 88: Select The Size Of The Original
Select the size of the original Select media series that indicates the correct width of the original. If once the display will display the choices for that series. (⇒ page 2-21). Note ◆ For this setting, only the media series for which the ENABLE SERIES is set to “ON”...
Page 89 ▼ Select the size of the original Press the [Enter] key. When you have selected the series choice and pressed the [Enter] key, the screen switches to the Series setting screen. O r i g i n a l : S e r i e s 9 "...
Page 90: Select Original Reject Direction
Select original reject direction The device provides two options for where the original is rejected after scanning, front and rear. The output choice is selected here. Note ◆ For the front reject, the original length is limited to maximum 48 inches (1219.2 mm). Operation steps Keys used WARNING LIGHT...
Page 91 ▼ Select original reject direction Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the Eject Direction setting screen. O r i g i n a l : E j e c t D i r e c t i o n R e a r F r o n t P a g e : 0 1 / 0 1...
Page 92: Adjust Sharpness Of Original
Adjust sharpness of original The outline of an original can be made sharp or blurred. Note ◆ After the sharpness of an original was adjusted, if the original type is changed (⇒ page 2-13), the original sharpness setting changes, thus requiring care. Operation steps Keys used WARNING LIGHT...
Page 93 ▼ Adjust sharpness of original Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the Sharpness setting screen. L i n e : S h a r p n e s s O f f We a k N o rma l S t r o n g...
Page 94: Adjust Contrast Of Original
UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY 123456789 Tanaka Shimano Ioka Oyama PART NO. SHEET Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE Dark Normal Bright 4-R2.0 4-R2.0 4-R2.0 50.0 50.0 50.0 XXXXXXXXX XXXXXXXXX...
Page 95 ▼ Adjust contrast of original Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to the Contrast. L i n e T h r e s h o l d S h a r p n e s s C o n t r a s t L i n e Gu a r a n t e e P a g e : 0 1 / 0 2...
Page 96: Mirror
XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY PART NO. 123456789 SHEET Tanaka Shimano Ioka Oyama Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE 4-R2.0 50.0 XXXXXXXXX MODEL SCALE UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY...
Page 97 ▼ Mirror Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to the Mirror. L i n e L i n e Gu a r a n t e e L i n e T h r e s h o l d M i r r o r R e v e r s e P a g e : 0 2 / 0 2...
Page 98: Reverse
UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY PART NO. 123456789 SHEET Tanaka Shimano Ioka Oyama Seiko I Infotech Inc. Design Department DRAWING NO. 123456789 PAGE 4-R2.0 4-R2.0 50.0 50.0 XXXXXXXXX XXXXXXXXX MODEL MODEL SCALE UNIT SCALE...
Page 99 ▼ Reverse Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to the Reverse. L i n e L i n e Gu a r a n t e e L i n e T h r e s h o l d M i r r o r R e v e r s e P a g e : 0 2 / 0 2...
Page 100: Copying Long Original
HDD, “HDD” setting is invalid even if it is selected. ◆ The maximum copy and printing length of the device is: LP-1020-MF 2.5 m (98.4 inches) LP-1020L-MF 10 m (393.7 inches) ◆ When copying a long original, the copy paper is also long, thus requiring careful handling.
Page 101: Operation Steps
▼ Copying long original Operation steps Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE REPRINT STOP SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER TONER TONER AUTO TEXT/LINE FEED PROCESS DARK MANUAL FEED...
Page 102 Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to the area to be selected. O r i g i n a l : S c a nMe d i a Memo r y P a g e : 0 1 / 0 1 [ E n t e r ] t o S e l e c t...
Page 103: Sorting
SHEET Tanaka Shimano Ioka Oyama PART NO. Tanaka Shimano Ioka Oyama PART NO. MODEL MODEL Seiko I Infotech Inc. Design Department DRAWING NO. 123456789 PAGE Seiko I Infotech Inc. Design Department DRAWING NO. 123456789 PAGE SCALE UNIT SCALE UNIT XXXXXXXXXXXXXXXXXXXX...
Page 104 Press the [ ] or [ ] key. If the [ ] or [ ] key is pressed, display of the first line on the screen changes to the store mode. The storage capacity at a time is 99 originals or 10GB.
Page 105 ▼ Sorting Press the [Enter] key. Press the [Enter] key, and the print will start. ◆ To return to the copy mode from the store mode, press the [ ] or [ ] key. The stored originals are all deleted if the copy mode is restored.
Page 106: Reset
Reset The data set for copy is reset to initial settings. Note ◆ The device saves the data of the original copied last. If that original is to be printed additionally, it can be printed by a single key operation without scanning the original again.
Page 107: Reprint
Reprint The device saves the data of the original copied last. If that original is to be printed additionally, it can be printed without scanning the original again. Note ◆ The reprint is enabled only when the REPRINT LED is lighting.
Page 108: Force Print
Force print This device provides the Force Print function that selects a different paper if the designated paper is not available when a copy operation is performed. Operation steps Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE...
Page 109 Note ◆ Force print is enabled only if the paper larger than the required paper is present. ◆ Force print is disabled if print is made on manually fed paper. ◆ When selecting paper feed location (⇒ page 2-28), if a drawer is specified for paper feed, force print is disabled (in this case, print is always made on the paper in the specified drawer).
Page 111: Chapter 3 Delivery Function
Chapter 3 Delivery function Chapter 3 describes the delivery function of this device. Contents of this chapter Delivery function Preparation before using delivery function Flow of delivery operation Delivery function overview Select original size Select original type Adjust background Adjust density Select media series used for original Select original eject direction Adjust sharpness of original...
Page 112 Delivery function In the DELIVERY mode of the device, the scanned data can be saved in the delivery host computer connected via network, or the data can be transferred to other computers on the same network. To use the delivery function, plot share must be installed beforehand in the delivery host computer used and various settings must be made with this application software.
Page 113: Preparation Before Using Delivery Function
Preparation before using delivery function To use the delivery function, preparation is required in advance. Make preparation following the procedure given below. Checking network connection of the device Check that the IP address, subnet mask, and gateway address of the device are set correctly.
Page 114: Connecting Delivery Host Computer
Connecting delivery host computer After the preparation of delivery host computer is completed, set the IP address of delivery host computer to the device. Press the [MENU] key. If the [MENU] key is pressed, the screen changes to the menu mode. Me n u mo d e MENU # S E T UP...
Page 115 ▼ Preparation before using delivery function Press the [ ] key. If the [ ] key is pressed, the screen changes as shown below. Me n u Mo d e # COMM. P ARAM . # E TH E RN E T Press the [ ] key.
Page 116 Press the [ ] key. Press the [ ] key is pressed, the digit of numeric value can be moved. Me n u Mo d e #D E L I V E R Y ADDR ✽0 0 0 . 0 0 0 . 0 0 0 . 0 0 0 [ E n t e r ] t o S e t Press the [ ] or [ ] key.
Page 117: Flow Of Delivery Operation
Flow of delivery operation Prior to start of the delivery operation, make sure that the preparation before using the delivery function (⇒ page 3-3) has already been completed. Press the [DELIVERY] key. If the [DELIVERY] key is pressed, the device requests the delivery host computer to send a delivery list, and the screen switches to the delivery list receiving screen.
Page 118 Press the [ ] or [ ] key. The delivery list is displayed on the screen. Also, the delivery destination selected at present is attached with “✽” at the top. The delivery destination can be moved with [ ] or [ ] key for confirmation.
Page 119 ▼ Flow of delivery operation Select the original size. Select the original size. (For details, see page 3-11.) Select the original type. Select what image type the original is. (For details, see page 3-16.) Adjust the background. Adjust the background color if the original has uneven density. (For details, see page 3-18.) Adjust the density.
Page 120: Delivery Function Overview
Delivery function overview The delivery functions provided by this device are as follows. Detailed setting steps are described on the following pages. Function list Description Original Size Sets the original size. Original Type Selects the image type according to the original.
Page 121: Select Original Size
XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY Tanaka Shimano Ioka Oyama PART NO. 123456789 SHEET Seiko I Infotech Inc. Design department 123456789 PAGE DRAWING NO. XXXXXXXXX MODEL SCALE UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY...
Page 122 The original sizes applicable to this device are as listed below: A series fixed form original Name of Lengthwise length Widthwise length Settable direction fixed form 1189 mm (46.8 inches) 841 mm (33.1 inches) Portrait 841 mm (33.1 inches) 594.5 mm (23.4 inches) Portrait/Landscape 594.5 mm (23.4 inches) 420.5 mm (16.6 inches) Portrait/Landscape...
Page 123 ▼ Select original size 8.5× 11 series fixed form original Name of Lengthwise length Widthwise length Settable direction fixed form 1117.6 mm 863.6 mm Portrait (44 inch) (34 inch) 863.6 mm 558.8 mm Portrait/Landscape (34 inch) (22 inch) 558.8 mm 431.8 mm Portrait/Landscape (22 inch)
Page 124 Map series fixed form original Name of Lengthwise length Widthwise length Settable direction fixed form 1000.0 mm 700.0 mm Portrait (39.4 inches) (27.6 inches) 700.0 mm 500.0 mm Portrait/Landscape (27.6 inches) (19.7 inches) Map series width original Name of Paper width Original min.
Page 125: Operation Steps
▼ Select original size China series width original Name of Paper width Original min. length Original max. length width 914 mm width 914 mm (36 inches) 910 mm width 910 mm (35.8 inches) *LP-1010-MF 900 mm width 900 mm (35.4 inches) 2,500 mm (98.4 inches) 880 mm width...
Page 126: Select Original Type
SHEET Tanaka Shimano Ioka Oyama PART NO. 123456789 SHEET Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE ◆ For the original with dark background and thin lines, select BLUE PRINT here and also set the contrast adjustment (⇒...
Page 127: Operation Steps
▼ Select original type Operation steps Select the original type. Press the [ORIGINAL TYPE] key, and the LED lighting position shifts. Press the [ORIGINAL TYPE] key until the LED of the original size to be selected turns on. S c a n R e a d y 0 1 / 0 4 : De s t i n a t i o n 1 [ <...
Page 128: Adjust Background
123456789 SHEET PART NO. 123456789 SHEET Tanaka Shimano Ioka Oyama Tanaka Shimano Ioka Oyama Seiko I Infotech Inc. Design department 123456789 PAGE Seiko I Infotech Inc. Design department 123456789 PAGE DRAWING NO. DRAWING NO. 4-R2.0 4-R2.0 4-R2.0 4-R2.0 50.0 4-R2.0 50.0...
Page 129: Operation Steps
▼ Adjust background Operation steps Press the [BACKGROUND REMOVAL ] or [BACKGROUND REMOVAL ] key. If the [BACKGROUND REMOVAL ] or [BACKGROUND REMOVAL ] key is pressed, the LED lighting position shifts. Numeric value becomes large with [BACKGROUND REMOVAL ] key, or small with [BACKGROUND REMOVAL ] key.
Page 130: Adjust Density
XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY 123456789 Tanaka Shimano Ioka Oyama PART NO. SHEET PAGE Seiko I Infotech Inc. Design department DRAWING NO. 123456789 Dark Normal Light 4-R2.0 4-R2.0 4-R2.0 50.0 50.0 50.0 XXXXXXXXX XXXXXXXXX XXXXXXXXX...
Page 131: Operation Steps
▼ Adjust density Operation steps Press the [DENSITY ] or [DENSITY ] key. If the [DENSITY ] or [DENSITY ] key is pressed, the LED lighting position shifts. The LED shifts in DARK direction with [DENSITY ] key, or in LIGHT direction with [DENSITY ] key.
Page 132: Select Media Series Used For Original
Select media series used for original Select media series used for original. Notes ◆ For this setting, only the media series for which the ENABLE SERIES is set to “ON” in the system menu are displayed. (For details, see “User's Guide, Plotter Unit” prepared separately.) ◆...
Page 133 ▼ Select media series used for original Press the [Enter] key. After confirming that the ORIGINAL SERIES has been selected, if the [Enter] key is pressed, the screen switches to the original series setting screen. O r i g i n a l : S e r i e s 9 "...
Page 134: Select Original Eject Direction
Select original eject direction The device provides two ejects, front and rear, for the original. Which output the original is ejected to can be selected here. Note ◆ For the front ejects, the original length is limited to maximum 48 inches (1219.2 mm). Operation steps Press the [ORIGINAL] key.
Page 135 ▼ Select original eject direction Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the original eject direction setting screen. O r i g i n a l : E j e c t D i r e c t i o n R e a r F r o n t P a g e : 0 1 / 0 1...
Page 136: Adjust Sharpness Of Original
Adjust sharpness of original The outline of an original can be made sharp or blurred. Note ◆ After the sharpness of an original was adjusted, if the original type is re-selected (⇒ page 3-16), the original sharpness setting changes, thus requiring care. Operation steps Press the [IMAGE QUALITY] key.
Page 137 ▼ Adjust sharpness of original Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the sharpness setting screen. L i n e : S h a r p n e s s O f f We a k N o rma l S t r o n g...
Page 138: Adjust Contrast Of Original
UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY Tanaka Shimano Ioka Oyama PART NO. 123456789 SHEET Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE Dark Normal Bright 4-R2.0 4-R2.0 4-R2.0 50.0 50.0 50.0 XXXXXXXXX XXXXXXXXX...
Page 139 ▼ Adjust contrast of original Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to the Contrast. L i n e T h r e s h o l d S h a r p n e s s C o n t r a s t P a g e : 0 1 / 0 2 [ E n t e r ] t o S e l e c t...
Page 140: Reverse
UNIT XXXXXXXXXXXXXXXXXXXX TITLE APPROVED BY CHECKED BY SIGNED BY DRAWN BY Tanaka Shimano Ioka Oyama PART NO. 123456789 SHEET Seiko I Infotech Inc. Design department DRAWING NO. 123456789 PAGE 4-R2.0 4-R2.0 50.0 50.0 XXXXXXXXX XXXXXXXXX MODEL MODEL SCALE UNIT SCALE...
Page 141 ▼ Reverse Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to the reverse. L i n e L i n e T h r e s h o l d F i l e T r a n s f e r R e s o l u t i o n ( d p i ) R e v e r s e...
Page 142: Designate Resolution
Designate resolution Designate the resolution when an original is scanned. Operation steps Press the [IMAGE QUALITY] key. If the [IMAGE QUALITY] key is pressed, the screen switches to the image quality setting screen. L i n e L i n e T h r e s h o l d F i l e T r a n s f e r R e s o l u t i o n ( d p i ) R e v e r s e...
Page 143 ▼ Designate resolution Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the resolution setting screen. L i ne : Reso l u t i on ( dp i ) 6 0 0 4 0 0 3 0 0 2 0 0 1 5 0...
Page 144: Compress Image Data When Transferred
Compress image data when transferred The scanned image data can be compressed and transferred to the delivery host computer. If the data transfer is slow, try to set “Compression.” The format of image data delivered from the delivery host computer is set with the exclusive application.
Page 145 ▼ Compress image data when transferred Press the [Enter] key. If the [Enter] key is pressed, the screen switches to file transfer setting screen. L i ne : F i l e T r ans f e r S t a n d a r d C omp r e s s P a g e : 0 1 / 0 1 [ E n t e r ] t o S e t...
Page 146: Reset
Reset The data set for copy is reset to initial settings. Operation steps Press the [RESET] key. If the [RESET] key is pressed, the data set for copy is all reset. 3-36...
Page 147: Chapter 4 Memory Function
Chapter 4 Memory function Chapter 4 describes the memory function of this device. Contents of this chapter Memory function overview Save settings to memory Call settings from save memory Set as default Rename saved memory...
Page 148: Memory Function Overview
Memory function overview Various settings of copy and delivery functions are saved in the memory, and can be called for copy or delivery as necessary. This function is called the memory function. It will be very convenient if the settings frequently used or complicated settings are saved in the memory in advance, not requiring the writing down of settings and numeric values.
Page 149: Save Settings To Memory
Save settings to memory Save current various setting conditions to the memory. Up to ten data each for copy and delivery can be saved. Note In case of delivery, no delivery destination is saved. Operation steps Keys used WARNING LIGHT POWER MENU COPY...
Page 150 Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the memory save setting screen. Memo r y : S a v e Memo r y 1 Memo r y 2 Memo r y 3 Memo r y 4 P a g e : 0 1 / 0 3 [ E n t e r ] t o S e l e c t Press the [ ] or [ ] key.
Page 151: Call Settings From Save Memory
Call settings from save memory The settings are called from the save memory. Operation steps Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING DELIVERY FILE STOP REPRINT SCAN STOP ORIGINAL ORIGINAL BACKGROUND SIZE TYPE REMOVAL DENSITY SCALE x1 WASTE PAPER...
Page 152 Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the memory restore screen. Memo r y : R e s t o r e Memo r y 1 Memo r y 2 Memo r y 3 Memo r y 4 P a g e : 0 1 / 0 3 [ E n t e r ] t o S e l e c t...
Page 153: Set As Default
Set as default Frequently used settings or complicated settings can also be saved as default, not as the memory. Once they have been saved as default, the settings will return to the values set as default when the device is turned on, a mode is changed, or resetting is executed afterwards.
Page 154 Press the [ ] or [ ] key. Press the [ ] or [ ] key to move to the set as default. Memo r y R e s t o r e S a v e S e t A s D e f a u l t R e n ame P a g e : 0 1 / 0 1 [ E n t e r ] t o S e l e c t...
Page 155: Rename Saved Memory
Rename saved memory The saved memory can be renamed. Changing the name of each saved memory to a discriminating one makes it easier to find when restoring the memory. Operation steps Keys used WARNING LIGHT POWER MENU COPY PRINT MEMORY RESET POWER SAVING...
Page 156 Press the [Enter] key. If the [Enter] key is pressed, the screen switches to the memory restore confirmation screen. Memo r y : R e n ame Memo r y 1 Memo r y 2 Z ume n a 2 Z ume n a 1 P a g e : 0 1 / 0 3 [ E n t e r ] t o S e l e c t...
Page 157 ▼ Rename saved memory Press the [ ] key. Press the [ ] key to move to the next character. Memo r y : R e n ame A emo r y 1 [ E n t e r ] t o S e t Hence, repeat steps 6 and 7 to enter the memory name.
Page 159: Chapter 5 File Function
Chapter 5 File function Chapter 5 describes the file function of this device. Contents of this chapter File function Preparation before using file function Screens of file function...
Page 160 File function Change the mode of the device to “FILE,” and the original data is read from a computer connected via network. To use this function, the exclusive application PlotShareOneDX (standard application attached) is installed in advance in the computer connected via network and one of the functions of that application “ScanToFile”...
Page 161: Preparation Before Using File Function
Preparation before using file function To use the file function, the preparation must be made beforehand. Make preparation following the procedure given below. Checking network connection of the device Check that the IP address, subnet mask, and gateway address of the device are set correctly.
Page 162: Screens Of File Function
Screens of file function There are seven kinds of screens shown below in the file function. Busy wait screen If the [FILE] key is pressed, the following screen appears. This status waits an instruction from the exclusive application in the computer connected via network.
Page 163: Scanning Screen
▼ Screens of file function Scanning screen This screen is displayed from the start of scan to the end. S c a n n i n g H o s t : P C1 Processing After the scan is completed, this screen is displayed while the image data is being processed to send to the computer.
Page 164: Original Ejecting Screen
Original ejecting screen This screen is displayed if an original is not ejected when the image data sending to the computer is completed. E j e c t i n g H o s t : P C1...
Page 165: Chapter 6 Troubleshooting
Chapter 6 Troubleshooting Chapter 6 describes a troubleshooting method for this device. If a trouble is not removed despite the corrective measures, contact your dealer or our service center. Contents of this chapter Copy/scan cannot be performed clearly Copy/scan cannot be performed satisfactorily Delivery failed...
Page 166: Copy/Scan Cannot Be Performed Clearly
Copy/scan cannot be performed clearly Streaks appear in the copy/scan result ■The shading guide or scanner glass is dirty. ➝Clean the shading guide or scanner glass (⇒ page 1-20). Note ◆ Copying/scanning the original stained with the toner, ink, or dust makes the inside of scanner dirty. Remove stains on the original before starting the copy/scan.
Page 167 ▼ Copy/scan cannot be performed clearly Dust attaches to background. ■The BACKGROUND REMOVAL is set to smaller value. ➝Set the BACKGROUND REMOVAL to larger value (⇒ pages 2-15, 3-18). ■The SHARPNESS setting is too strong. ➝Reduce the SHARPNESS setting (⇒ pages 2-52, 3-26). Moire occurs.
Page 168: Copy/Scan Cannot Be Performed Satisfactorily
Copy/scan cannot be performed satisfactorily Original jammed and copy/scan failed. ■A folded original or strongly curled original causes a paper jam. ➝Change the original setting direction. ➝Use a document carrier. Copy function Margins are added in the original width direction, or both side edges of original are not copied.
Page 169 ▼ Copy/scan cannot be performed satisfactorily Both side edges of an original are not copied when the China series of original is copied. Or, a copy is taken with the margins added to both sides. ■China size setting is not correct. ➝Set the China size that matches the original and paper roll used by referring to “If China series of paper is used”...
Page 170 An attempt to take a partial copy failed because warning error “W COPY-0B31” “W COPY-0B32” occurred. ■Set value of “Position” is larger than original size. ➝To take a partial copy, set value of “Position” must be smaller than original size. For example, if an original of A3 fixed-size portrait is partially copied, setting such as “Position 1,000mm”...
Page 171 ▼ Copy/scan cannot be performed satisfactorily No margin is added, or desired margin is not added. ■The ORIGINAL SIZE is set to either AUTO, FIXED-SIZE PORTRAIT, or FIXED-SIZE LANDSCAPE. ➝The margin function is disabled if the ORIGINAL SIZE is set to either AUTO, FIXED-SIZE PORTRAIT, or FIXED-SIZE LANDSCAPE.
Page 172: Delivery Function
Delivery function An original is scanned with the margin added in the original width direction, or both side edges of an original are not scanned. ■The original series used is not set correctly. ➝Set the ORIGINAL SERIES of the delivery function to the original series used (⇒...
Page 173: Color Scanning Function
Color scanning function The color cannot be scanned. ■The color scanning is an optional feature, and requires a color upgrade kit: LP840, LP-841, LP842 or LP843. Without this kit, color scanning is not available. ➝When using the color scanning function, insert the CF card for color scanning to the plotter, and then power on.
Page 174: Delivery Failed
Delivery failed If an error message is displayed, follow the Measure given in “Chapter 13 Troubleshooting” in the User's Guide, Plotter Unit prepared separately. A delivery list cannot be got. ■The device is not connected to the network. ➝Connect the device to the network using the UTP cable. ■The network setting of the device is not set correctly.
Page 175 Communication from the device to the exclusive application for delivery is slow. ■The File transfer setting does not match the original type used. ➝A change in File transfer setting of the delivery function may increase the transfer speed to the exclusive application for delivery.

This manual is also suitable for:

Lp-1020l-mf

Seiko I Infotech LP-1020-MF User Manual

Chapter 1 Getting Started

Chapter 2 Copy Function

Chapter 3 Delivery Function

Chapter 4 Memory Function

Chapter 5 File Function

Chapter 6 Troubleshooting

Quick Links

Need help?

Questions and answers

Related Manuals for Seiko I Infotech LP-1020-MF

Summary of Contents for Seiko I Infotech LP-1020-MF

This manual is also suitable for:

Table of Contents
