Page 1 Owner’s Manual & Safety Instructions Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference.
Page 2 Do not alter anything else inside NVR. Service Have your NVR equipment serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the equipment is maintained. Item 57648 For technical questions, please call 1-888-866-5797. Page A...
Page 3 Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock. SAVE THESE INSTRUCTIONS. Page B For technical questions, please call 1-888-866-5797. Item 57648...
Page 4 (See Figure A.) Figure A: Outlets for 2-Prong Plug Extension Cords Note: Do not use an extension cord with the Power Adapters. Symbology Double Insulated Alternating Current Volts Amperes Item 57648 For technical questions, please call 1-888-866-5797. Page C...
Page 5: Table Of Contents
USER MANUAL Contents SAFETY INSTRUCTION ........................6 Chapter 1 Product Overview ......................1 Rear Panel ..........................1 1.2 Remote Controller ........................... 2 Chapter 2 NVR Connection ......................3 2.2 Connection Diagram ........................3 2.3 Power Supply Connection ......................3 Chapter 3 NVR Common Operations ..................... 4 3.1 Using the Supplied Mouse ......................
Page 6 USER MANUAL 5.1.3 Image Control ......................... 29 5.1.4 PTZ ............................31 5.1.5 Video Cover ..........................32 5.1.6 Motion ............................33 5.1.7 PIR ............................34 5.1.8 Deterrence ..........................35 5.1.9 Intelligent Analysis ......................... 36 5.1.9.1 PID (Perimeter Intrusion Detection) ..................... 36 5.1.9.1.1 Alarm Setup ..........................
Page 7 USER MANUAL 5.4.2.1 Model Configuration ........................70 5.4.2.2 Database Management ......................... 71 5.4.3 Alarm ............................73 5.4.3.1 Face Recognition ........................... 73 5.4.3.2 AD (Attribute Detection) ......................... 76 5.4.3.3 PD & VD (Human & Vehicle Detection) ..................76 5.4.3.4 PID (Perimeter Intrusion Detection) ..................... 77 5.4.3.5 LCD (Line Crossing Detection) .....................
Page 8 USER MANUAL 5.7.3 Maintenance ......................... 123 5.7.3.1 Log ..............................124 5.7.3.2 Load Default ..........................125 5.7.3.3 Upgrade ............................125 5.7.3.4 Parameter Management ......................126 5.7.3.5 Auto Reboot ..........................126 5.7.3.6 Developer Mode ........................... 127 5.7.4 IP Camera Maintain ......................127 5.7.4.1 Upgrade IP Camera ........................
Page 9 USER MANUAL Chapter 7 Remote Access via Web Client ................. 170 7.1 Basic System Environment Requirements ................170 7.2 Web Plugin Download and Installation ..................170 7.3 Web Client Manager ........................172 7.3.1 Live Interface ........................172 7.3.2 Playback ..........................175 7.3.2.1 Playback Control Buttons ......................
Page 10: Safety Instruction
USER MANUAL SAFETY INSTRUCTION Please carefully read the following safety instruction so as to avoid personal injuries and prevent the equipment and other connection devices from being damaged. 1. Power sources (note: please use the power supply attached or specified by the manufacturer) Never operate the equipment by using unspecified power supply.
Page 11 USER MANUAL 13. Do not ingest battery, Chemical Burn Hazard, This product contains a coin / button cell battery. If the coin / button cell battery is swallowed, it can cause severe internal burns in just 2 hours and can lead to death. Keep new and used batteries away from children.
Page 12: Chapter 1 Product Overview
USER MANUAL Chapter 1 Product Overview 1.1 Rear Panel 1) Startup and shutdown 2) Connect the attached power supply 3) Audio signal output, RCA interface 4) Connect to VGA monitor, such as PC monitor 5) HDMI high-definition port 6) Connect USB devices, such as USB mouse and USB flash disk. 7) Network input interface of the router / switch 8) Built-in PoE switch for camera connection.
Page 13: Remote Controller
USER MANUAL 1.2 Remote Controller Icon Description Numeric keys Press to display channel 1~8 9、0 Numeric keys Press to display all channels Multiple display mode Menu Press to enter or exit the Main Menu Mute Mute On/off Submenu Go to submenu Up arrow key;...
Page 14: Chapter 2 Nvr Connection
USER MANUAL Chapter 2 NVR Connection 2.2 Connection Diagram Note: Above diagram is for reference only. The practical connection may be different Speaker depending on the NVR you purchased. 2.3 Power Supply Connection Caution: Use only the supplied power adapter that came with the NVR Connect one end of the power adapter to the power connector on the back of the NVR.
Page 15: Chapter 3 Nvr Common Operations
USER MANUAL Chapter 3 NVR Common Operations 3.1 Using the Supplied Mouse Left Button: Click to select menu options. During live viewing in split-screen view, double-click on a channel to view it in full- screen. Double-click the channel again to return to split-screen viewing. Click upon a channel on Live Viewing screen to open Camera Quick Toolbar.
Page 16: Password
USER MANUAL 3.3 Password For the first time when you run the NVR, you must be required to set your own password immediately in order to protect your privacy. Please be sure to record your username and password and save them in a secure place. Choose an OSD language Language: Input the device ID in the parentheses.
Page 17: Chapter 4 Nvr Starting Up
USER MANUAL Chapter 4 NVR Starting up 4.1 Start Wizard Startup Wizard will help to configure the system and get the NVR works quickly. 4.1.1 Start Wizard Click the Start Wizard to proceed to the next step 4.1.2 Network Configuration If you connect to a router allows to use DHCP, please check the box.
Page 18 USER MANUAL Subnet Mask: Subnet mask is a network parameter which defines a range of IP addresses that can be used in a network. If IP address is like a street where you live then subnet mask is like a neighborhood. The subnet address also consists of four groups of numbers, separated by periods.
Page 19: Date/Time
USER MANUAL case, you do not need to configure manually port forwarding on your router. If your router does not support UPnP, make sure the port forwarding is completed manually in your router. Mapping Strategy: If you want the port randomly distributed by the router UPNP server, choose “Auto”;...
Page 20: Ip Camera
Time: Set the start time and end time for daylight saving 4.1.4 IP Camera This menu allows you to add IP cameras to the NVR. 57648 PoE NVR, the IP camera will get online automatically if the IP camera is connected to the PoE port on the NVR rear panel.
Page 21: Disk
USER MANUAL 4.1.5 Disk If the HDD is installed in the NVR for the first time, it must be formatted. Select the HDD and then click Format HDD button to format the HDD. Overwrite: Use this option to overwrite the old recordings on the HDD when the HDD is full. For example, if you choose the option 7 days then only the last 7 days recordings are kept on the HDD.
Page 22: Mobile
USER MANUAL 4.1.7 Mobile If your NVR come with a P2P ID, you can scan the QR code with your mobile app to view the NVR remotely. 4.1.8 Summary You can check the system summary information you had set in the start wizard and finish the wizard.
Page 23: Live View Screen Overview
USER MANUAL 4.2 Live View Screen Overview Status Icons This indicates that the NVR is currently recording. This icon appears when the camera has detected motion. This icon indicates that the HDD is in error to work This icon indicates the HDD is unformatted This icon indicates the HDD is full.
Page 24: Camera Quick Toolbar
USER MANUAL 4.2.1 Camera Quick Toolbar In live viewing, click the left button of your mouse on a connected camera to display the Camera Quick Toolbar. Click to manually record the channel immediately. If the manually recording is in process, the icon will be in red color.
Page 25: Taskbar
USER MANUAL 4.2.2 Taskbar Click to open the Start Menu Click to choose different layout for live view Click to choose more layouts for live view Click to start viewing channels in a sequence. You’re able to set the sequence display mode on 5.7.1.3 Output Configuration Quick playback.
Page 26: Unlock And Lock Screen
USER MANUAL 4.2.3.1 Unlock and Lock Screen The screen will be locked to protect unauthorized OSD operation while the NVR is not in menu operation 1 minute. If necessary, you can also lock the screen operation manually. To do so, go to Star Menu, and then click the Lock Screen icon to lock the system immediately.
Page 27: Chapter 5 Nvr System Setup
USER MANUAL Chapter 5 NVR System Setup You are able to configure the NVR for Channel, Record, Alarm, Network, Device & System from Start Menu  Setup. 5.1 Channel In this section, you are allowed to configure the camera connection, live view display, manage IP cameras, adjust IP camera’s image, PTZ setup, Video Cover, Motion, and more.
Page 28: Channel
USER MANUAL 5.1.1 Channel 5.1.1.3 IP Channels In this section, you are able to configure the connection of your wired IP cameras. If your NVR comes with PoE ports, please go to 5.1.3.1 PoE NVR Connection, if your NVR comes without PoE port, please go to 5.1.3.2.
Page 29: Poe Nvr Connection
USER MANUAL 5.1.1.3.1 PoE NVR Connection For the PoE NVR, it is allowed to connect the IP cameras via the internal PoE ports and/or external LAN(WAN) port. NOTE: It is not recommended to connect more than 1 camera via switch or router to the PoE port.
Page 30 USER MANUAL Default Password: To configure the default user name and password of Private, Onvif and RTSP protocol connection. Default password is “admin”.
Page 31 USER MANUAL State: Show the connection status of the camera. Icon with green background color: camera is well-connected. Icon with green grey color: failed to connect camera. Click the icon to show the failure reason. If the failure reason is “User name or password error”, it means the camera user name and password is different from the default user name and password.
Page 32: Steps To Connect Plug & Play Poe Cameras
USER MANUAL 5.1.1.3.1.1 Steps to Connect Plug & Play PoE Cameras 1. Keep the default settings. 2. Change the default user name and password to be same with the cameras. 3. Make sure your IP camera is set to DHCP IP address already. If your camera is set to static IP address which is different from the IP address segment inside the PoE router, your IP camera will be unable to get online.
Page 33 USER MANUAL If you want to add an individual channel manually, click the edit icon in the channel list, and then click the drop-down arrow next to Switch Mode to select “Manual” and click save. 5.1.1.3.1.2.1 Add Individual Camera in the LAN 1.
Page 34 USER MANUAL 2. Select the camera you want to connect and then click button. Input the user name and password of the camera and then click button. Alias: To define the camera ID you want to display in the live view screen. Port: Camera communication port.
Page 35 USER MANUAL 5.1.1.3.1.2.2 Add Multiplex Cameras in the LAN 1. Click Search button, all available cameras in the LAN will be displayed. Or click button, the NVR will search & add all available cameras in the LAN. Add All 2. Select the cameras from the search result, and then click “Add”. You would need to input the user name and password of the cameras.
Page 36 USER MANUAL 3. The added cameras will be displayed in the channel list. 5.1.1.3.1.2.3 Add Cameras from Other NVR in the LAN The NVR allows to add cameras from other NVR in the local network. 1. Click button, all available devices in the LAN will be displayed. There is an edit Search icon if the device is an NVR.
Page 37 USER MANUAL 3. Select the NVR in the search list, and then click button. 4. Input the user name and password of the NVR and then click button. 5. The added cameras will be displayed in the channel list.
Page 38: 3.1.3Add Cameras From Internet
USER MANUAL 5.1.1.3.1.3Add Cameras from Internet If your NVR is connected to internet, you’re able to add cameras from internet with WAN IP address. 1. Click button in the search page. 2. Input the IP address or domain name, port, protocol, user name & password of the IP camera.
Page 39: Non-Poe Nvr Connection
USER MANUAL 5.1.1.3.2 Non-PoE NVR Connection For Non-PoE NVR connection, please refer to 5.1.3.1.2 Steps to Connect External Cameras From LAN. 5.1.1.4 POE Power In this page, you will find the real-time power consumption of each PoE port, total actual power &...
Page 40: Image Control
USER MANUAL Setup: Click icon for more setup. Choose a channel to configure Adjust the Hue value for the image color Adjust the Bright value for the image color Adjust the Contrast value for the image color Adjust the Saturation value for the image color Click Apply to save settings.
Page 41 USER MANUAL Choose a channel to Select the desired built-in IR cut filter mode to ensure the camera works properly both in the day and night. Set the delay time of IR-CUT Set the IR LED / Supplement lights on/off Flip vertical Flip horizontal To enable the corridor mode...
Page 42: Ptz
USER MANUAL 5.1.4 PTZ This menu allows to configure the PTZ (Pan-Tilt-Zoom) settings for the speed dome cameras. Channel: Channel name Signal Type: If your PTZ camera is connected to the RS485 port, then choose “Analog”, otherwise choose “Digital”. Below items need to be set for Analog PTZ only. Protocol: Choose the communication protocol between the PTZ capable camera and NVR.
Page 43: Video Cover
USER MANUAL 5.1.5 Video Cover This menu allows you to create privacy zone(s) if you want to partially cover some certain part of the images. You can create up to 4 privacy zones in any size and location on the camera image.
Page 44: Motion
USER MANUAL 5.1.6 Motion This menu allows you to configure motion parameters. When motion has been detected by one or more cameras, your NVR will alert you to a potential threat at your home. It does this by sending you an email alert with an attached image from the camera to use as a reference (if this option is enabled) and/or sending push notifications via the mobile app.
Page 45: Pir
USER MANUAL 5.1.7 PIR This menu allows you to configure PIR parameters. When PIR has been detected by one or more cameras, your NVR will alert to you a potential threat. It does this by sending you an email alert with an attached image from the camera to use as a reference (if this option is enabled) and/or sending push notifications via the mobile app.
Page 46: Deterrence
USER MANUAL 5.1.8 Deterrence This menu allows you to configure the deterrence parameters. Channel: channel name. Setup: Click icon into the setup page. Deterrence Area: The whole screen is marked for deterrence detection (red blocks) as default. If you want to disable the deterrence detection on a certain area, click the grid cursor and then drag the mouse to highlight the scope to unmark...
Page 47: Intelligent Analysis
USER MANUAL 5.1.9 Intelligent Analysis The optional intelligent Analysis functions, including (Perimeter Intrusion Detection), (Line Crossing Detection), (Stationary Object Detection), (Pedestrian Detection), (Face Detection), and (Cross Counting), (Sound Detection) and Video Tampering. Note: Intelligent Analysis function is not AI function. 5.1.9.1 PID (Perimeter Intrusion Detection) Perimeter Intrusion Detection function detects people, vehicle or other objects which enter and loiter in a pre-defined virtual region, and some certain actions can be taken when the...
Page 48: Alarm Setup
USER MANUAL Rule Number: Max. 4 rules available. Rule Switch: Activate or inactivate the rule 1. Choose one of the Rule Number. It is the number of PID area. Maximum 4 areas you can set for PID function. 2. To enable the detection in Rule Switch.
Page 49 USER MANUAL In the page, you can configure the alarm action when an alert is triggered. Buzzer: Disable or to active the buzzer to emit an alarm tone in 10, 20, 40 or 60 seconds when the detection is triggered. Alarm Out: If your NVR support to connect to external alarm device, you can set to emit an alarm tone.
Page 50: Lcd (Line Crossing Detection)
USER MANUAL 5.1.9.2 LCD (Line Crossing Detection) Line Crossing Detection function detects people, vehicle or other objects which cross a pre- defined virtual line, and some certain actions can be taken when the alarm is triggered. Check the box to enable LCD function. Switch: Sensitivity: Set the sensitivity level.
Page 51: Sod (Stationary Object Detection)
USER MANUAL Note: 1) The lines shall not be too close to the edges of the camera picture, to avoid any failure to trigger an alarm when the target cross through it. 2) The lines shall not be set too short, to avoid any failure to trigger an alarm when the target passes outside it.
Page 52 USER MANUAL Channel: Select the channel you want to configure Rule Number: Max. 4 rules available. Rule Switch: Activate or inactivate the rule 1. Choose one of the Number. It is the number of SOD area. Maximum 4 areas you Rule can set for SOD function.
Page 53: Fd (Face Detection)
USER MANUAL For Alarm setup, please refer to 5.1.9.1.1 Alarm Setup 5.1.9.4 FD (Face Detection) Face Detection function detects the faces of moving people appear in a pre-defined region. Switch: Check the box to enable FD function. Click Setup icon to draw a virtual region in the camera image.
Page 54: Cc (Cross Counting Detection)
USER MANUAL of the region should be a convex polygon. Concave polygon will be not able to save. 3. Click Save to save your settings. 4. If you want to adjust the size of the region, click the red box in the region, the borders of the region will be changed to red color.
Page 55 USER MANUAL Channel: Select the channel you want to configure Rule Number: Max. 4 rules available. Rule Switch: Activate or inactivate the rule 1. To enable the detection in Rule Switch. 2. Choose a Rule Type. AB: If a target object is detected moving from side A to side B, the system will count 1 to enter number;...
Page 56: Sd (Sound Detection)
USER MANUAL 5.1.9.6 SD (Sound Detection) With the sound detection, it can trigger an alarm while detecting the sound rise or decline, and some certain actions can be taken when the alarm is triggered. Switch: enable or disable sound detection. Rise: enable or disable sound rise detection.
Page 57: Intelligent Schedule
USER MANUAL 5.1.9.8 Intelligent Schedule In order to active the intelligent function, you need to config the schedule. The schedule will be active in 24 hours x 7 days. To set the schedule, choose one channel then drag the cursor to mark the slots. The sky- blue blocks in the time slots will be active for intelligent detections.
Page 58: Record
USER MANUAL 5.2 Record This menu allows you to configure the recording parameters. 5.2.1 Encode This menu allows you to configure the recording video or network transmission picture quality. Generally, defines the recording video quality which will be saved in the Mainstream HDD;...
Page 59: Record
USER MANUAL ETR: setting different streams for normal and alarm recording. In the Audio section, you can define the input/output volume, and encode type of the audio. 5.2.2 Record This menu allows you to configure the channel recording parameters. 5.2.2.1 Record Record Switch: Check to enable the recording in this channel.
Page 60: Record Schedule
USER MANUAL 5.2.2.2 Record Schedule This menu allows you to specify when the NVR records video and defines the recording mode for each channel. The recording schedule lets you set up a schedule like, daily and hourly by normal (continuous) recording, motion recording, I/O alarm recording & PIR recording (if your NVR supports).
Page 61: Capture
USER MANUAL 5.2.3 Capture This menu allows to configure the image capture function. 5.2.3.1 Capture Enable Capture: Enable or disable automatic capturing on the channel. Stream Type: Select the image resolution by mainstream or substream. Normal Interval: Time interval to capture an image in normal recording. Alarm Interval: Time interval to capture an image when motion, IO alarm or PIR is triggered Capture: Enable or disable manual capture in the channel...
Page 62: Capture Schedule
USER MANUAL 5.2.3.2 Capture Schedule Channel: Select the channel to set its capture parameters. Normal: When the time slot is marked green, this indicates the channel performs normal capture for that time slot. Motion: When the time slot is marked yellow, this indicates the channel capture images when a motion is detected during that time slot.
Page 63: Alarm
USER MANUAL 5.3 Alarm In this section, you can configure the alarm actions when alert occurs. 5.3.1 Motion Channel: Channel name Buzzer: The NVR can use its internal buzzer to emit an alarm tone. You can set the buzzer duration in seconds when an alarm is triggered. Alarm Out: Optional function.
Page 64: Pir
USER MANUAL 5.3.2 PIR This menu allows you to configure parameters of PIR Alarm. Channel: Channel name Buzzer: The NVR can use its internal buzzer to emit an alarm tone. You can set the buzzer duration in seconds when an alarm is triggered. Alarm Out: Optional function.
Page 65: Intelligent
USER MANUAL 5.3.4 Intelligent You can configure the PID / LCD/ PD&VD / SOD / FD / Sound Detection / Video Tampering alarm function here. Channel: Channel name Buzzer: The NVR can use its internal buzzer to emit an alarm tone. You can set the buzzer duration in seconds when an alarm is triggered.
Page 66: Ptz Linkage
USER MANUAL 5.3.5 PTZ Linkage If you had connected the PTZ cameras, you can set the linkage between PTZ cameras and Motion Alarm and/or external I/O sensor alarm and/or PIR alarm. With the linkage function, you can turn your PTZ cameras focus to the preset point when a motion, I/O alarm and or PIR alarm happens.
Page 67: Alarm Schedule
USER MANUAL 5.3.7 Alarm Schedule In this menu, you can set several schedules, including Alarm out, Push, FTP Upload, Cloud Upload and Buzzer. Channel: Select the channel to set its capture parameters. To set the schedule, choose one channel and one of the alarm types then drag the cursor to mark the slots.
Page 68 USER MANUAL Click to configure the face detection conditions. Channel: Channel selection Snap Mode: There are “Optimal Mode” (automatically select & push the best image from all face images of the same person whose faces were captured during his/her duration of stay), “Realtime Mode”...
Page 69 USER MANUAL Apply Mode: Set the face detection angle, including “Frontal View”, “Multi Angle” and “Customize” mode. Roll Range: Set the range of face rotation under the customize mode. Pitch Range: Set the range of face pitch under the customize mode Range: Set the range of face horizontal flipping under the customize mode.
Page 70 USER MANUAL If you choose Rect mode, you can choose “Full Screen” or “Customize” to adjust the shape of rectangular detection zone in the camera image. Faces appear in this zone will be detected and captured. If you choose Line mode, you need to adjust the position, length of the line, and choose the detection direction from B...
Page 71: Pd & Vd (Human & Vehicle Detection)
USER MANUAL 5.4.1.2 PD & VD (Human & Vehicle Detection) Switch：To enable or disable the Human & Vehicle detection. Click to configure the detection conditions. Channel: Channel selection Snap Mode: There are “Optimal Mode” (automatically select & push the best image from all captured images of the same vehicle during its duration of stay), “Realtime Mode”...
Page 72: Pid (Perimeter Intrusion Detection)
USER MANUAL Detection Mode: Motion Mode will detect moving objects. Static Mode will detect both moving faces and still objects. Detection Range: Set the detection zone. You can choose “Full Screen” or “Customize” to adjust the shape of rectangular detection zone in the camera image. Target objects appear in this zone will be detected and captured.
Page 73 USER MANUAL 1. Choose one of the Number. It is the number of LCD lines. Maximum 4 lines you Rule can draw. 2. Choose the detection target type. 3. To enable the detection in Rule Switch. 4. Choose a Rule Type.
Page 74: Lcd (Line Crossing Detection)
USER MANUAL 5.4.1.4 LCD (Line Crossing Detection) Line Crossing Detection function detects human beings, vehicles or other objects which cross a pre-defined virtual line, and some certain actions can be taken when the alarm is triggered. Check the box to enable the LCD function. Switch: Sensitivity: Set the sensitivity level.
Page 75: Cc (Cross Counting)
USER MANUAL 5. Use your mouse to click 2 points in the camera picture to draw a virtual line. 6. Click Save to save your settings. 7. If you want to modify the position or length of the line, click the red box in the line, the color of the line will be changed to red color.
Page 76 USER MANUAL Select the channel you want to configure Channel: Type: Choose the detection target objects. Motion will detect all moving objects, Person will detect human beings only, Vehicle will detect vehicles only. Alarm Number: The NVR will send an alert if the number of entries minus the number of exits exceeds the alarm number.
Page 77: Hm (Heat Map)
USER MANUAL to enter number; if a target object is detected moving from side A to side B, the system will count 1 to exit number. 5. Use your mouse to click 2 points in the camera picture to draw a virtual line. 6.
Page 78: Cd (Crowd Density Detection)
USER MANUAL borders of the region will be changed to red color. Click and hold the left button of your mouse to move the position of the region, or drag the corners to resize the region. 5. If you want to remove one of the regions from the camera picture, click the red box in the region and then click Remove button.
Page 79: Qd (Queue Length Detection)
USER MANUAL Max Pixel: Set the maximum detection pixel box. The people can be recognized only when he/she is smaller than the pixel box. Max Detection: The NVR will send an alert if the number of people inside the detection area exceeds the Max Detection number.
Page 80 USER MANUAL Min Pixel: Set the minimum detection pixel box. The people can be recognized only when he/she is larger than the pixel box. Max Pixel: Set the maximum detection pixel box. The people can be recognized only when he/she is smaller than the pixel box. Max Detection: The NVR will send an alert if the number of crowds in the line inside the detection area exceeds the Max Detection number.
Page 81: Schedule
USER MANUAL 5.4.1.9 Schedule In order to active the AI function, you need to config the schedule. The schedule will be active in 24 hours x 7 days. To set the schedule, choose one channel then click on one of the detection items on the right side, then drag the cursor to mark the slots.
Page 82: Database Management
USER MANUAL 5.4.2.2 Database Management You’re able to create the face database to classify different faces. There are 3 default groups: Allow List, Block List and Stranger. You can use add icon delete icon to add or delete customized groups. Import Database: Import database from USB memory.
Page 83 USER MANUAL Click Local Storage Device to import face images which were captured and saved in the NVR local HDD storage. Choose the start time and end time manually. Or you can select the time interval from 1 day, 2 days, 3 days, 4 days, 5 days, 6 days, 1 week and 1 month, and then click the button to move to left or right period.
Page 84: Alarm
USER MANUAL Use the same method to add face images from external USB storage devices. 5.4.3 Alarm To configure the alarm action when an AI alert happens. 5.4.3.1 Face Recognition To configure alarm actions for different face groups when faces detected. Enable Alarm: To enable or disable the alarm function.
Page 85 USER MANUAL Alarm Channel: To choose which channel(s) will be applied to the alarm setting. Alarm: Click to configure the alarm actions. Buzzer: The NVR can use its internal buzzer to emit an alarm tone. You can set the buzzer duration in seconds when an alarm is triggered.
Page 86 USER MANUAL Channel: Select the channel to set its capture parameters. To set the schedule, choose one channel then drag the cursor to mark the slots. The blue blocks in the time slots will be active for alarm. The schedule is valid only for the selected channel each time when you set.
Page 87: Ad (Attribute Detection)
USER MANUAL 5.4.3.2 AD (Attribute Detection) Attribute detection is a function to detect people’s facial features and send an alarm according to the settings. Alarm Type: Select the alarm trigger condition. If the selection is “No Mask”, the NVR will send an alarm if it detects a person doesn’t wear a face mask.
Page 88: Pid (Perimeter Intrusion Detection)
USER MANUAL Time: To configure the external alarm time when Human & Vehicle is detected. Latch Record: Click icon and choose which channel(s) you want to record when the Human & Vehicle detection is triggered. Post Recording: You can set how long after an event occurs that the NVR will continue to record.
Page 89: Lcd (Line Crossing Detection)
USER MANUAL FTP Video Upload: To upload alarm video to FTP server when an alarm is triggered. To enable FTP, please view 5.4.4 FTP. Picture to Cloud: To upload alarm images to Cloud server when an alarm is triggered. To enable Cloud, please view 5.5.2 Cloud.
Page 90: Cc (Cross Counting)
USER MANUAL 5.4.3.6 CC (Cross Counting) To configure alarm actions for CC alarms. Buzzer: The NVR can use its internal buzzer to emit an alarm tone. You can set the buzzer duration in seconds when an alarm is triggered. Alarm Out: Optional function.
Page 91: Qd (Queue Length Detection)
USER MANUAL Latch Time: To configure the external alarm time when an alarm is triggered. Record: Click icon and choose which channel(s) you want to record when an alarm is triggered. Post Recording: You can set how long after an event occurs that the NVR will continue to record.
Page 92: Statistics
USER MANUAL Send Email: You can let the NVR to send you an auto-email when an alarm is triggered. FTP Picture Upload: To upload alarm images to FTP server when an alarm is triggered. To enable FTP, please view 5.4.4 FTP.
Page 93: Pd & Vd (Human & Vehicle Detection)
USER MANUAL 5.4.4.2 PD & VD (Human & Vehicle Detection) You can check the face recognition statistics in a certain period. 1. Choose the detection type in Intelligent. 2. Choose the channel(s). 3. Select the period from day, week, month, quarter and year. 4.
Page 94: Hm (Heat Map Statistics)
USER MANUAL 5.4.4.4 HM (Heat Map Statistics) You can check the heat map statistics in a certain period. 1. Choose the channel & date. 2. Choose the Report Type: Daily, Weekly, Monthly or Annually. 3. Choose the Cross Type: Cross In or Cross Out. 4.
Page 95: Network
USER MANUAL 5.5 Network This menu allows you to configure network parameters, such as PPPoE, DHCP. The most common types are DHCP. Most probably your network type is DHCP, unless the network is manually addressed. If you need an authentication user name and password to the Internet, then choose PPPoE.
Page 96: Pppoe
USER MANUAL 5.5.1.2 PPPoE This is an advanced protocol that allows the NVR to connect to the network more directly via DSL modem. Check the “Enable PPPOE” box, and then enter the User name & Password of the PPPoE. Click Apply to save, system will reboot to active the PPPoE setting.
Page 97: Ddns
USER MANUAL UPNP: If you want to log in remotely to the NVR using Web Client, you need to complete the port forwarding. Enable this option if your router supports the UPnP. You need to enable UPnP both, on NVR and router. In this case, you do not need to configure manually port forwarding on your router.
Page 98: Email
USER MANUAL 5.5.3 Email This menu allows you to configure email settings. Please complete these settings if you want to receive the system notifications on your email when an alarm is triggered, HDD becomes full, HDD is in error state, or Video Loss occurs. 5.5.3.1 Email Configuration mail: Check to enable.
Page 99: Email Schedule
USER MANUAL 1~3: Enter the email address where you want to receive the event notifications Receiver from the NVR. Interval: Configure the length of the time interval between the notification emails from the NVR. To make sure all settings are correct, click Test Email. The system sends an automated email message to your inbox.
Page 100: Ftp
USER MANUAL 5.5.4 FTP This menu allows you to enable FTP function to view and load captured snapshots from NVR to your storage device over FTP. Enable: Click to enable FTP function. Server IP: Enter your FTP server IP address or domain name. Port: Enter the FTP port for file exchanges.
Page 101: Ip Filter
USER MANUAL 5.5.5 IP FILTER IP filter helps to control the remote login devices by using Allow List and Block List to filter the IP address. If you want to activate this function, check the Enable box. Choose either Enable Allow List Enable Block List.
Page 102: Voice Assistant
USER MANUAL 5.5.6 Voice Assistant The voice assistant function allows to connect your NVR to your GoogleCast or Amazon Fire TV Stick, and cast the real-time surveillance images to your TV monitor by voice control. 5.5.6.1 Voice Assistant with Amazon Fire TV Stick 1.
Page 103 USER MANUAL 3. Connect the Fire TV Stick to your TV monitor, and power on it. Connect the Fire TV Stick to the Wi-Fi which is in the same LAN with your NVR. 4. To use your existing profile or add a new profile and login your Amazon account which is same as the one you bind to the NVR.
Page 104 USER MANUAL 5. Search cand install Amazon Alexa to your mobile phone from app store, and then login with the Amazon account which is same as the one you bind to the NVR. 6. Touch “More”, and then touch “Skills & Games”.
Page 105 USER MANUAL 7. Touch the search icon on the right top corner. 8. Input the keyword: smart camera view, and search.
Page 106 USER MANUAL Touch the “Smart Camera View” in the search result list. Touch “ENABLE TO USE”.
Page 107 USER MANUAL 9. You would need to link your Amazon account. Sign in the Amazon account which is same as the one you bind to the NVR. Touch “Done” after the skill is successfully linked. 10. Touch “DISCOVER DEVICES” and wait a moment for the app to search the cameras. Touch when the devices were found and connected.
Page 108 USER MANUAL 11. Choose one of the devices and then touch SET UP DVICE. You can add the camera to a group or skip. 12. Repeat setup 11 to add all cameras and then touch Done to finish.
Page 109 USER MANUAL 13. All added cameras will be listed in the Devices. Touch the Cameras icon to check all added cameras.
Page 110 USER MANUAL 14. Press and hold on the voice button on the remote controller of the fire TV stick, and speak the command clearly. The command could be like: Show the XXX camera / Show XXX. XXX is the camera channel name. For example, if the channel name is “Office”, you could speak “Show my office camera”.
Page 111 USER MANUAL 15. Wait for a while, you will see the real time images from the Office camera in your TV monitor. 16. If you want to quit the camera live view, speak “Stop”. 17. If you have changed the channel name, you would need to discover and add the camera again.
Page 112: Voice Assistant With Google Chromecast
USER MANUAL 5.5.6.2 Voice Assistant with Google Chromecast 1. Input your Google account, and the click Bind button to connect to bind your Google account. To choose the video stream you want to cast to your TV monitor. 2. Go to Channel – Live menu, and give a Channel Name which is easy to call to the channel(s) you want to cast to your TV monitor.
Page 113 USER MANUAL 5. To login your Google account which is same as the one you bind to the NVR. 6. Touch “Get Started” to create a home, and then touch “New devices”. Input the Home nickname and address and then touch “Next”. To allow location access for the app.
Page 114 USER MANUAL 7. The app will automatically try to search devices from your local network. Choose Chromecast / Google TV. Make sure your Chromecast is turned on already, then touch Next. 8. Your Chromecast will be found. Touch to connect. Confirm the code by touching Yes. Next 9.
Page 115 USER MANUAL 10. Choose the Wi-Fi network for your Chromecast and input the Wi-Fi password to connect. Make sure the Wi-Fi you choose is the same one with your mobile phone and is in the same local network with your NVR. Touch Continue to next step.
Page 116 USER MANUAL 12. Now the Chromecast has been added to your Google Home. Touch the + icon on the left top corner. Indoor, then choose Set up device. Choose “Work with Google”, touch the search icon on the right top corner and then input “smart camera view”.
Page 117 USER MANUAL Wait for a while, the Smart Camera View application will be linked to the Google Home. 13. Now the available cameras in your NVR will be displayed. Choose one of the cameras and then touch Next button. Choose a home & location for the cameras step by step.
Page 118 USER MANUAL 14. Repeat step 13 to add all cameras. 13. Search and install Google Assistant app to your mobile phone from app store. 14. Run the Google Assistant, login your google account which is same as the one you bind to the NVR.
Page 119: Platform Access
USER MANUAL 5.5.7 Platform Access This function is mainly used to connect 3 party platform, like ECMS/NVMS via Onvif protocol. Enable：Check to enable this function. Authentication：Login authentication type, options including Digest_sha256, Digest, Digest/WSSE, WSSE and None. Choose one of them to match to your 3 party platform.
Page 120 USER MANUAL Overwrite: Use this option to overwrite the old recordings on the HDD when the HDD is full. For example, if you choose the option 7 days then only the last 7 days recordings are kept on the HDD. To prevent overwriting any old recordings, select OFF. If you have disabled this function, please check the HDD status regularly, to make sure the HDD is not full.
Page 121: 110
USER MANUAL 5.6.1.1 S.M.A.R.T This function can be used to display technical information on the hard drive installed inside your NVR. You can also perform a test (there are three types available) to evaluate and detect potential drive errors. If for some reason the hard drive Whole Evaluation not passed, continue to use the disk: has developed a fault (such as one or more bad sectors), you can instruct your NVR to continue saving to the drive.
Page 122: Cloud
USER MANUAL 5.6.2 Cloud Cloud function allows to upload pictures and videos to your cloud storage. It supports Dropbox and Google Drive storage now. Cloud Type: To choose Dropbox or Google Drive. Cloud Overwrite: Use this option to overwrite the old recordings on the storage when it is full.
Page 123 USER MANUAL Login your email box and click the link in the email content. It will turn to the cloud server authorization login page. Input your Dropbox account name and password to login. Input the DVR local IP address and web port, and then click Authorize.
Page 124 USER MANUAL Input the DVR user name and password and then click OK. 10. Authorization finished; the webpage will turn to your Dropbox. 11. The Cloud has completed the setup if you find a new folder named by your NVR device name and MAC address in the Dropbox storage.
Page 125: System
USER MANUAL 5.7 System Change general system information such as date, time and region, edit passwords and permissions, and more. 5.7.1 General 5.7.1.1 General Name: Enter the desired name for your NVR. The name can include both letters and Device numbers.
Page 126: Date And Time
USER MANUAL 5.7.1.2 Date and Time Date & Time Date: Click the calendar icon to change the date. Time: Click the dialogue box to change the time. Date Format: Select the preferred date format. Time Format: Select the preferred time format. Time Zone: Select a time zone relevant to your region or city.
Page 127 USER MANUAL The NTP (Network Time Protocol) function allows your NVR to automatically sync its clock with a time server. This gives it the ability to constantly have an accurate time setting (your NVR will periodically sync automatically). Check to enable the NTP, and select a Server Address, click Update Now to manually sync the date &...
Page 128 USER MANUAL The DST (Daylight Saving Time) function allows you to select the amount of time that Daylight Saving has increased by in your particular time zone or region. Enable DST: If Daylight Saving applies to your time zone or region, check this option to enable.
Page 129: Output Configuration
USER MANUAL 5.7.1.3 Output Configuration This menu allows you to configure video output parameters. Video Output: To choose the output options: To choose the display layout when you display the live view cameras in SEQ Mode: sequence. Set the sequency dwell time. SEQ Dwell Time: Set the VGA/HDMI output resolution.
Page 130: Multi-User
USER MANUAL 5.7.2 Multi-user This menu allows you to configure the user name, password and user permission. The system supports the following account types:  — System Administrator: The administrator has full control of the system, ADMIN and can change both administrator and user passwords and enable/disable password protection.
Page 131: Changing Password
USER MANUAL 5.7.2.1 Changing Password To change the password for the administrator or user accounts, click the User Edit icon The password has to be a minimum of 8 characters and can contain a mixture of numbers and letters. Enter your new password again to confirm, and then click Save to save your new password.
Page 132: Add New Users
USER MANUAL 5.7.2.2 Add New Users Select one of the user accounts that is currently disabled, click the User Edit icon Select Enable from the drop-down next to User Enable. Click the field next to User Name to change the user name for the account. Select from the drop-down next to Enable...
Page 133: Setting User Permissions
USER MANUAL 5.7.2.3 Setting User Permissions The administrator account is the only account that has full control of all system functions. You can enable or disable access to certain menus and functions of each user account. 1. Click the edit icon under Permission tab.
Page 134: Maintenance
USER MANUAL 2. Check the boxes next to any system menus or capabilities you would like the user to access. Click to check all boxes. Click Clear to check none of the boxes. 3. Click Save to save your modifications. 5.7.3 Maintenance In this section, you will be able to search &...
Page 135: Log
USER MANUAL 5.7.3.1 Log The system log shows you important system events, such as motion alarms and system warnings. You can easily create a backup file of the system log for a set time period to a USB flash drive. Log Searching and Backing Up: 1.
Page 136: Load Default
USER MANUAL 5.7.3.2 Load Default Reset the NVR settings to its out-of-box state. You can choose to reset all settings at once, or just settings on specific menus. Restoring default settings will not delete recordings and snapshots saved to the hard drive. Check the items you want restore, or check Select All to choose all items.
Page 137: Parameter Management
USER MANUAL 1. Copy the firmware file (.sw file) to your USB drive, and insert the USB flash drive into the NVR’s USB port. 2. Click Select File button to choose the firmware file in your USB flash drive, then Click OK. 3.
Page 138: Developer Mode
USER MANUAL Auto Reboot: Check to enable. Time: You can set the NVR to reboot by day, week or month. 5.7.3.6 Developer Mode This menu will allow to collect some debug information for professionals to analyze the system situation. Telnet: Only enable it when the after sales professionals require to do.
Page 139: Upgrade Ip Camera
USER MANUAL 5.7.4.1 Upgrade IP Camera This menu allows you to upgrade the IP camera’s firmware. 1. Choose one of the IP cameras you want to upgrade firmware. 2. Click Select File select the update file from your USB flash drive, then click OK. 3.
Page 140: Load Default Settings For Ip Camera
USER MANUAL 5.7.4.2 Load Default Settings for IP Camera 1. Choose the IP cameras you want to restore. 2. Click to restore settings. You will be required to input the Admin password to Load Default authenticate. 5.7.4.3 Reboot IPC To reboot the IP camera you select.
Page 141: Parameter Management
USER MANUAL 5.7.4.4 Parameter Management Select the IP camera, click Save Settings to export its setting values to your USB memory. Select the IP camera, click Load Settings to import setting values from your USB memory. 5.7.5 System Information This menu allows you to view the system information, channel information, record information &...
Page 142: Channel Information
USER MANUAL If your NVR supports P2P function, you will find the P2P ID & P2P QR code in the information page. You can scan this QR cord with mobile app to remote view the NVR. 5.7.5.2 Channel Information View channel information for each connected camera such as alias, mainstream and substream recording specifications, motion detection status &...
Page 143: Ai Scenario
USER MANUAL View network information. Total Band Width: It shows the NVR’s total input band width for IP cameras. Used Band Width: It shows the used band width of IP cameras. 5.8 AI Scenario AI Scenario function provides AI applications for different specific scenarios. Click the submenu title in the main setup page to get into the individual function setup page.
Page 144 USER MANUAL 1. Navigation bar on the left side: Channel View Mode: To count and view the real-time result by individual camera(s). Mostly used for small place with single entrance & exit. Group View Mode: To count and view the real-time result by group(s). Mostly used for big place with multiplex entrances &...
Page 145 USER MANUAL 4. Real-time counting data information bar This bar will display the real-time counting data for the selected channel. Available: Remaining allowed attendance number Inside: Current attendance number inside the control area Enter: Recorded number of the total entrants Exit: Recorded number of the total leaving attendance.
Page 146 USER MANUAL If you have enabled the Advertise Mode, your advertising pictures will be displayed with the real-time counting data together in the full screen mode. Learn more for Advertise Mode 5.8.1.3 Advise Mode. Right click your mouse to exit the full screen mode. 6.
Page 147: Channel View Setup
USER MANUAL 5.8.1.1 Channel View Setup Click the add icon or setup icon to get to the configuration page. To enable the channel(s) you want to realize the counting function in the Channel list. The Setup & Alarm icon will be in blue color if the camera in that channel supports AI function;...
Page 148 USER MANUAL Click one of the Setup to configure the detection conditions. icons Switch: Activate or inactivate the detection. Type: Choose the detection target objects. Motion will detect all moving objects, Person will detect human beings only, Vehicle will detect vehicles only. Sensitivity: Set the sensitivity level.
Page 149 USER MANUAL button of your mouse to move the line, or drag the terminals to modify the length or position of the line. ix. If you want to remove one of the lines from the camera picture, click the red box in the line and then click Remove button.
Page 150: Group View Setup
USER MANUAL 5.8.1.2 Group View Setup Click the add icon or setup icon to get to the configuration page. Click the Add IP Camera icon to add channel(s) to the group. Max. 8 groups can be set, but each one channel can be added to 1 group only. If a channel is enabled in the Channel View mode, it will be not allowed to add to any group.
Page 151 USER MANUAL Latch Time: To configure the external alarm time when the Available number is 0. Click the close icon or right click your mouse to go back to previous configuration page, and then click Apply button to save the settings. Click the Group View icon...
Page 152: Advertise Mode
USER MANUAL 11. Click the icon to add a map image from your USB memory. 12. Click icon to adjust the site of the IP cameras. Click and hold the channel icon and move one by one to adjust the position of your IP cameras on the map. You can click icon to display the map in full screen.
Page 153 USER MANUAL Check the Advertise mode in the Click Image button to load advising pictures from your USB memory. It supports to add maximum 16 pictures with jpg, png and bmp format, and the maximum resolution should be no more than 2560x1600. Click the add icon to add new picture(s) and click delete icon to delete the added picture one by one.
Page 154: Search Counting Data
USER MANUAL Go back to Channel View mode or Group View mode, click the full screen button the right upper corner to display your advertising pictures and the real-time counting data for the selected channel(s) or group(s). 5.8.1.4 Search Counting Data Click the Search to search the counting data.
Page 155: Face Attendance
USER MANUAL It is allowed to search separately for Channels and Groups. Choose the channel(s) or group(s) you want to search, set the search duration by day, by week, by month or by year and choose the target type you want to search. Click the search icon , the result will be displayed on the right side of the window.
Page 156 USER MANUAL 3. Individual attendance statistical data of each selected group. The total number of people who need to check attendance The number of people who have checked attendance already The number of people who haven’t checked attendance. 4. Live view screen: to display the live camera images. Click the screen split icons to change the display layout.
Page 157 USER MANUAL Working Days: To select the working days. It will affect the attendance statistical data. Click the setting icon to configure your email configuration. Check more on 5.5.3.1 Email Configuration.
Page 158: Chapter 6 Search, Playback & Backup
USER MANUAL Chapter 6 Search, Playback & Backup The Search function gives you the ability to search for and play previously recorded videos as well as snapshots that are stored on your NVR’s hard drive. You have the choice of playing video that matches your recording schedule, manual recordings or motion events only.
Page 159 USER MANUAL Stop Fast Forward, x2, x4, x8 and x16 Digital Zoom: Click to zoom in then click-and-drag on a camera image during playback to zoom in on the selected area. Right-click to return to regular playback. Video Clip. Quickly save a section of video to a USB flash drive. View more on 6.1.1.1 Video Clip Backup Save Video Clip.
Page 160: Search & Play Video In General
USER MANUAL 6.2 Search & Play Video in General This menu gives an option to search & play recording for a selected date. 1. Select a date to search for video recording from the calendar. 2. Choose a search type. 3.
Page 161 USER MANUAL 3. Click icon. 4. Check the channel(s) you want to make a video clip backup. 5. Move the mouse cursor to the timeline where you want to start the video clip. 6. Press and hold the left button of your mouse, and drag the drag the cursor to the timeline where you want to end the video clip.
Page 162: Event Search, Playback & Backup
USER MANUAL 6.3 Event Search, Playback & Backup Event search lets you view a list of video recordings with the channel, start and end time, and recording type conveniently summarized. You can also quickly back up events to a USB flash drive.
Page 163 USER MANUAL 7. You can switch the view of list form in by clicking below icons which is show at the right bottom corner of the screen: Thumbnails view. You can view the snapshots of the events. List view. The events will be displayed in list. Detailed view.
Page 164: Event Playback Control
USER MANUAL 6.3.1 Event Playback Control 1. Event List, you can select the events here. 2. Click icon to save your selected event videos to USB flash drive. Click icon to play video. 3. Control the playback with buttons on Video Playback Controls.
Page 165: Sub-Periods Playback
USER MANUAL 6.4 Sub-periods Playback Sub-periods playback allows you to play multiple normal recordings and motion events simultaneously from a single channel. With normal and event recordings, the video is divided evenly depending on the split-screen mode that has been selected. For example, if the video is an hour long and you have selected Split-screens x 4, each split-screen will play for 15 minutes.
Page 166: Smart Search
USER MANUAL 8. Use the timeframe options ( ) to view a smaller or larger time period. 9. Add Tag function: click add customized tag, click add default tag, enable to make mark in the current channel current time point. After adding, in tag playback page it will be able to jump to the “Tag”...
Page 167 USER MANUAL 6. It supports to narrow the search by selecting a certain area in the images. Click the icon on the Playback Controls bar, the aera selection page will be displayed. The selected aera will be marked with red grids. : select whole image.
Page 168: Tag Search
USER MANUAL 6.6 Tag Search You can search, play and manage the contents with tags you added in live view and/or playback. 1. Select the start time and end time you want to search. 2. Select the channel(s) you want to search. 3.
Page 169: Picture Search & View
USER MANUAL Insert your USB memory into the USB port, find out the folder where the video files are saved, and then click the play icon to play the video. 6.8 Picture Search & View This function can be used to search, play and copy snapshots to a USB flash drive. To search, play &...
Page 170: Picture Preview Control
USER MANUAL 8. When you click the left button of your mouse upon one of the pictures, system will show the picture information on the left bottom corner of the screen. 9. Check the box next the number of the event to select files, or check the box next Select select all pictures in the page.
Page 171: Slice Search
USER MANUAL 6.9 Slice Search This is a function to slice each hour’s video into 60 fragments. Choose the video stream type, channel, date and hour. The system will display 60 thumbnail images of each minute on the screen. Click on any one of the thumbnail images, the video will be played on the left bottom corner.
Page 172: Ai Search
USER MANUAL 6.10 AI Search 6.10.1 Face Choose date, time, channel, groups to search all captures faces. 1. Click icon to add customized faces. 2. Choose the Channels you want to search. 3. You can also set search conditions of the facial features in Attributes. 4.
Page 173: E-Map
USER MANUAL 6.10.1.1 E-Map E-Map function helps to track a person’s faces. Click the icon to sets the E-Map function. Click Load Map button to load a map image from your USB memory. Check the Edit box. Click and hold the channel icon and move one by one to adjust the site of your IP cameras on the map.
Page 174 USER MANUAL Click icon to select one face image from local storage or external USB storage. Select date & time, group(s), channel(s), set the similarity rate, and then click Search button. The system will display the result on the e-map. If the person was captured by multiple cameras, the system will display his/her moving track on the map.
Page 175: Human & Vehicle
USER MANUAL Click the play button on the play control, the system will automatically demonstrate the moving track. Check the Play Record box, recorded videos will be played meanwhile. 6.10.2 Human & Vehicle The system provides a quick search for human beings and vehicles. Select the date &...
Page 176: Pid &Lcd
USER MANUAL Right click your mouse upon one of the images, you will have 2 options: A. To view the file information. B. To start playback of the file. Choose one or more files, click the play button , the system will turn to the playback interface to play the selected file(s).
Page 177: Repeat Visitors
USER MANUAL Click Search, the result will be displayed on the right side of the window. Click one of the images, the system will show its basic information on the left side of the window, and the video will be played on the left bottom side. Right click your mouse upon one of the images, you will have 2 options: A.
Page 178 USER MANUAL Select the date & time, group(s) & channel(s). Set the Attributes. Set the Min. Interval time (second). Click Search, the result will be displayed on the right side of the window. You can sort the result by Time and Frequency.
Page 179: Face Attendance
USER MANUAL 6.10.5 Face Attendance Face Attendance is used to assist in attendance checking by faces. It will help to analyze the absenteeism, coming late and leaving early. Note: In case of failure, do NOT take the face attendance function as your only measure to check attendance.
Page 180 USER MANUAL Click on the detail icon , you will see the captured images and videos of the first occurrence and the last occurrence of the person in the day. Click on the play button to have a quick playback.
Page 181: Chapter 7 Remote Access Via Web Client
USER MANUAL Chapter 7 Remote Access via Web Client Use the Web Client to remotely access your NVR at any time via a PC. Before you access the Web Client, you need to ensure that the internet settings of the NVR are configured properly.
Page 182 USER MANUAL 3. After installing the plug-in, close & launch again your browser and repeat step 1 to open the login page. Input your user name and password to login the web client. Note: For Microsoft Edge, Firefox, Google Chrome, Mac Safari, you don’t need to install the plug-in, but some functions might be limited.
Page 183: Web Client Manager
USER MANUAL 7.3 Web Client Manager The web client supports to fully control the NVR with administrator account. Please make sure to protect your user name & password for preventing illegal login. 7.3.1 Live Interface This is the first screen that opens after you have logged in to the Web Client. Here you can open or close live preview, record video to local computer manually, take snapshots of the screens, PTZ control, color adjustment, etc.
Page 184 USER MANUAL Bitrate button. Set camera to use mainstream, substream or mobile stream video settings. Mobile stream is available for IP channels only. 2- Live Video Stream Options: Mainstream: View all live videos using high-quality mainstream video settings. Substream: View all live videos using middle-quality substream video settings. Mobile Stream: View all live video using lower-quality mobile stream video settings to conserve bandwidth.
Page 185 USER MANUAL 8- PTZ Controls Directional Arrows: Click to move the PTZ camera Automatic line scan. PTZ Speed: Click to set the speed of the PTZ camera’s movement. Zoom: Click –/+ to zoom in or out. Focus: Click –/+ to adjust focus. Iris: Click –/+ to adjust iris.
Page 186: Playback
USER MANUAL 7.3.2 Playback You can search & play recording videos stored in the HDD inside the NVR, and download the videos to your computer. To search recordings: 1. Click Playback in the top-right corner of the window. 2. Select a day on the calendar to search for recordings from. Days with recordings appear with a red underline.
Page 187: Playback Control Buttons
USER MANUAL 7.3.2.1 Playback Control Buttons Play the recordings Pause Stop Go Forward One Frame: Move frame-by-frame through playback. Only available when Synchronous playback option is not checked. Click upon one of the channels which is being played and then click record button to record current video to your computer.
Page 188 USER MANUAL Choose the files you want to download, press Start Download button to begin, you will see the download status. Press Stop Download button to stop. Playback Speed. Click to choose the playing speed. Play All Channels: Click to play all channels you have chosen to searched. Only available when the Synchronous playback option is not checked.
Page 189: Remote Setting
USER MANUAL 7.3.3 Remote Setting Here you can remotely configure the settings of the NVR. Please see “Chapter 5 NVR System Setup” for more details on the NVR settings. 7.3.4 Local Setting Set download locations for recordings and snapshots taken using Web Client, and choose file type for video files.
Page 190: Chapter 8 Viewing Backed Up Video On Pc/Mac
USER MANUAL Chapter 8 Viewing Backed Up Video on PC/Mac This section will help you to play the backup files with the powerful video player which is attached in the CD or you can download from: http://al8.co For Mac users, please install the app “VideoPlayer_x.x.xx_xxxx_xx_x.dmg”, for example: VideoPlayer_1.0.32.dmg.
Page 191 USER MANUAL 3. Click Open File button or click button on the Play List to load single or multiple video files. It supports to add & play “.rf”, “.avi”, “.mp4”, “.264” and “.265” files. Click button to load a folder with backed-up videos. Video Player Control 1.
Page 192 USER MANUAL Multi-screen play. It allows to play multiple videos at a time. When you choose multi- screen, you can drag the video in Play List to the play screen. Take snapshot To save a video clip to your computer. Press once to start, press again to end the video clip.
Page 193 USER MANUAL Basic Settings: Set on-top mode Capture Settings: Set the format and the path to save snapshots.
Page 194: Chapter 9 Remote Access Via Mobile Devices
USER MANUAL Chapter 9 Remote Access via Mobile Devices The NVR supports to remote access via mobile devices based on Android & iOS operating system. Search RXCamView from Google Play Store for android devices or App Store for iOS devices and install. Run the app, the GUI is displayed as below:...
Page 195 USER MANUAL Touch the icon on the left top corner and then choose Device List to turn to the Device Manager page. Touch the + icon on the right top corner and then select “IPC/NVR/DVR”. The app will open your phone camera to enter the scan mode. If your NVR supports P2P, scan the P2P ID QR code inside your system info page or on the top cover of your NVR.
Page 196 USER MANUAL The added NVR will be displayed in the Device Manger page. Touch the play button to start live view. If your mobile is connecting to the Wi-Fi which is in the same LAN with your NVR, you can choose to add the NVR by using Online Search. Touch on the device in the search result list, and then input the port, use name, password to add.
Page 197 USER MANUAL If your NVR doesn’t support P2P, you must add the device manually. Touch on the Manual Add button, and then input the IP address or DDNS domain name, port, user name & password, click Save to add the NVR. For more operations about the app, please check on the Help menu in the app.
Page 198: Chapter 10 Appendix
USER MANUAL Chapter 10 Appendix 10.1 Troubleshooting Q: What can I do if the system does not detect the HDD? A: Check if the power supply system is properly connected and data cord and power cables are securely connected, and if something wrong with the HDD interface. Or you may check if your HDD is supported by referring to the specifications or descriptions.
Page 199: Usage Maintenance
USER MANUAL 11. Q: Why NVR cannot control PTZ? A: Please check if: a) PTZ in the front side is malfunctioned. b) Setting, connection and installation of PTZ decoder are not correct. c) NVR’s PTZ setting is not correct. d) Protocol of PTZ decoder does not match that of NVR. e) Address of PTZ decoder does not match that of NVR.
Page 200 USER MANUAL induced voltage. If the network cable is frequently plugged, it is suggested to replace connecting line regularly, or the input signal may be unstable. 6. This is a class A product. It maybe brings wireless interference in life. Under this situation, it need user to make measures.
Page 201 USER MANUAL...
Page 202 Record Serial Number Here: Note: If product has no serial number, record month and year of purchase instead. Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Reference UPC 193175419316. Limited 90 Day Warranty Harbor Freight Tools Co.

Cobra 57648 Owner's Manual & Safety Instructions

Chapter 1 Product Overview

Chapter 2 NVR Connection

Chapter 3 NVR Common Operations

Chapter 4 NVR Starting up

Chapter 5 NVR System Setup

Chapter 6 Search, Playback & Backup

Chapter 7 Remote Access Via Web Client

Chapter 8 Viewing Backed up Video on Pc/Mac

Chapter 9 Remote Access Via Mobile Devices

Chapter 10 Appendix

Quick Links

Related Manuals for Cobra 57648

Summary of Contents for Cobra 57648

Table of Contents
