T O P S K Y
replacement parts, or questions please visit our website at
if that is possible,order-ID, pictures or detail of issue will be helpful.

Special Warnings

Ø
Keep your furniture out of direct sunlight. Please use desk pads and coasters to protect
the surface from dents, scratches, and moisture from hot or cold liquids.
Ø
For cleaning, wipe the surface with a damp (not wet) cloth or wipe dry with a clean lint
free cotton cloth. Window cleaning liquid or a similar cleaning liquid can be used to
clean glass surface.

Operation Instructions

Ø
Please check that all parts are present before you start the assembly of your furniture.
For the protection of your furniture, place all parts on a clean and smooth surface to
prevent any damage.
Ø
Please periodically check all fitting and re-tighten as necessary.
Ø
Please assemble the table by 2 persons or more.
Ø
Do NOT over tighten hardware.
CUSTOMER SERVICE
For fastest service on claims, request for
www.topskyfurniture.com
e-mail: service@topskyfurniture.com
Phone number: +1 725-333-1988
TS500047

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS500047 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TOPSKY TS500047

  • Page 1 TS500047 T O P S K Y CUSTOMER SERVICE For fastest service on claims, request for replacement parts, or questions please visit our website at www.topskyfurniture.com e-mail: service@topskyfurniture.com Phone number: +1 725-333-1988 if that is possible,order-ID, pictures or detail of issue will be helpful.
  • Page 2 TS500047 There are 6 holes in total on the columns. But you will not use 2 holes of them at all. We just want to make sure the installation for part #5 more convenient. 12" Item. Item. Part. QTY. Part.
  • Page 3 TS500047 .SCREWS M6X35...
  • Page 4 TS500047 .SCREWS M5X55 · Please confirm that there are no other holes on the side of the 3 columns facing you. · After confirmation, you can install part #5. .SCREWS .SCREWS .SCREWS M6X30 M6X12 *Do not over tighten the screws before assembly the desk board.
  • Page 5 TS500047 .SCREWS M6X30 .SCREWS M6X12...
  • Page 6 TS500047 .SCREWS M6X30 .SCREWS M3.5X14 The direction to assemble sliding rail Left Side You can refer to the following website to see “How to install the slide rail" https://youtu.be/iKzIHs_t33Y Right Side Or scan the QR code to see this video...
  • Page 7 TS500047 .SCREWS M4X8 Left Side Right Side Left Side Right Side Please follow the screw direction,otherwise the slide rail may be stuck. *If you find that the distance between the two sides of the slide rail is too large or too small, please loosen G screw a little in step 6 appropriately to adjust.
  • Page 8 TS500047...
