DD700 TCP/IP Ethernet Card Setup Instructions
Equipment Needed: DD700 Indicator, PT# 899-100143 DD700 Ethernet TCP/IP Option Card, Cross over
Ethernet cable, Computer with available Ethernet adapter for local area network.
Software Needed: Digi Device discovery. Download at: https://www.digi.com/support/
productdetail?pid=5574&type=utilities Then select your operating system to download as shown below.
1. Install the option card into one of the available option card slots on the DD700
2. Connect the cross over Ethernet cable and power on the indicator. You will be prompted to set up the option
card, select Yes:
(right side of display), then configure the output with the desired output string. Press
ESC when finished.
3. In the computer select settings in your start window, then go to network and sharing center. Double click the
TCP/IPV4 settings shown below to enter a new IP address.
B-TEK Scales, LLC • 1510 Metric Ave. SW Canton, OH 44706 • Toll Free: 800.266.8900 • Fax: 330.471.8909
Advertisement
Related Manuals for B-TEK Scales DD700
Summary of Contents for B-TEK Scales DD700
- Page 1 3. In the computer select settings in your start window, then go to network and sharing center. Double click the TCP/IPV4 settings shown below to enter a new IP address. B-TEK Scales, LLC • 1510 Metric Ave. SW Canton, OH 44706 • Toll Free: 800.266.8900 • Fax: 330.471.8909...
- Page 2 4. Open Digi Device discovery. The digi program should find Ethernet card in DD700 with default IPaddress, Subnetmask, gateway, port. Note: If the Digi Device web interface will not open in Internet Explorer check the settings in the following: open Internet Explorer click on tools, Internet options, connections, LAN settings, uncheck box in proxy server section if box is checked.
