Em-Trak I100-X Quick Start Manual

TRACKING TRANSPONDER
I100-X | Identifier
DESCRIPTION
The Identifier I100-X is a ruggedized, fully self-contained
AIS Class B vessel tracking transponder, ideal for small
vessel tracking and monitoring.
I100-X can power itself using its own internal rapid-
recharge battery (+120hrs continuous operation), or be
connected directly to another onboard power source
such as engine, battery or solar with the battery then
acting as a backup.
I100-X is fully water and weather proof
and ruggedized to operate reliably without
maintenance in even the harshest of environments -
extreme heat/cold, humidity, shock and vibration.
Each I100-X is supplied as a complete kit which includes
the I100-X transponder, mounting bracket and rapid
charging dock. Accessories such as direct connect
power cable and alert indicator box are also available.
2W
IPx8
TRANSMIT 2W/CS WATERPROOF
FEATURES
I Certified AIS Class B Transmitter
I Power from battery or solar powered system
I Ruggedized for long term external use at sea
I Fully integrated GPS and VHF antenna system.
(IPx8 certified)
BATTERY GPS
FLEXIBILITY TO POWER FROM VESSEL / BATTERY / SOLAR
TYPICAL INSTALLATIONS SHOWN BELOW:
Product Code: 417-0077
I100-X Internal Battery Powered
I100-X Connected to vessel power
(requires additional cable
301-0130)
I100-X connected to vessel power
and using additional LED Indicator
Box – requires LED Indicator Box
Kit 417-0068
