ESD electronic CPCI-HD/2 Hardware Manual

Hd-drive, cf-card slot and 2 sata-interfaces
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CPCI-HD/2
HD-Drive, CF-Card Slot
and 2 SATA-Interfaces
Hardware Manual
to Product I.2318.04, I.2318.02
CPCI-HD/2
Hardware Manual • Doc. No.: I.2318.21 / Rev. 1.1
Page 1 of 14
esd electronic system design gmbh
Vahrenwalder Str. 207 • 30165 Hannover • Germany
http://www.esd.eu
Phone: +49 (0) 511 3 72 98-0 • Fax: +49 (0) 511 3 72 98-68

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPCI-HD/2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ESD electronic CPCI-HD/2

Summary of Contents for ESD electronic CPCI-HD/2

  • Page 1 CPCI-HD/2 Hardware Manual • Doc. No.: I.2318.21 / Rev. 1.1 Page 1 of 14 esd electronic system design gmbh Vahrenwalder Str. 207 • 30165 Hannover • Germany http://www.esd.eu Phone: +49 (0) 511 3 72 98-0 • Fax: +49 (0) 511 3 72 98-68...
  • Page 2 All rights to this documentation are reserved by esd. Distribution to third parties, and reproduction of this document in any form, whole or in part, are subject to esd's written approval. © 2013 esd electronic system design gmbh, Hannover esd electronic system design gmbh Vahrenwalder Str.
  • Page 3 Date of print: 2013-08-22 Document type DOC0800 number: Hardware version: CPCI-HD/2 Rev.1.0 Document History The changes in the document listed below affect changes in the hardware as well as changes in the description of the facts, only. Revision Chapter Changes versus previous version...
  • Page 4 ● The CPCI-HD/2 may become warm during normal use. Always allow adequate ventilation around the CPCI-HD/2 and use care when handling. ● Do not operate the CPCI-HD/2 adjacent to heat sources and do not expose it to unnecessary thermal radiation. Ensure an ambient temperature as specified in the technical data.

  • Page 5: Table Of Contents

    Installation........................10 4. LEDs............................11 Position of the LEDS......................11 Indication........................11 Connector Assignment....................... 12 SATA Interface for external Drives..................12 Declaration of Conformity......................13 Order Information........................14 CPCI-HD/2 Hardware Manual • Doc. No.: I.2318.21 / Rev. 1.1 Page 5 of 14...

  • Page 6: Overview

    ATA interfaces, one channel is used to control a CompactFlash slot and one channel to control the local 2.5” HD drive. In the CPCI-HD/2 standard version (order No.: I.2318.04) the hard disk is included in the scope of delivery. The factory installed HD capacity may change upwards with the improvement of drive technology.

  • Page 7: Technical Data

    CompactPCI Specification, Rev. 2.0 Connectors Connector coding no colour coding universal board (3.3 V or 5 V signal voltage tolerant) Table 2: CompactPCI Bus CPCI-HD/2 Hardware Manual • Doc. No.: I.2318.21 / Rev. 1.1 Page 7 of 14...

  • Page 8: Hdd Interface

    Data transfer mode SATA 1 (1,5 Gb/s) Controller SIL 3811 Connector 7-pin Serial ATA-connector, angled modification to Rear-I/O connection available on request Table 5: CompactFlash interface Page 8 of 14 Hardware Manual • Doc. No.: I.2318.21 / Rev. 1.1 CPCI-HD/2...

  • Page 9: Software Driver Support

    (support@esd.eu) in case of problems. Note: ‘hot-plug’ supported ® from version 6.x, driver contained in standard Kernel VxWorks ® I.2318.31: VxWorks driver in source code + documentation in source code CPCI-HD/2 Hardware Manual • Doc. No.: I.2318.21 / Rev. 1.1 Page 9 of 14...

  • Page 10: Hardware Installation

    Danger! Never carry out work while power supply voltage is switched on! Select an open 3U-CompactPCI bus slot. The CPCI-HD/2 can be inserted into any 3U-slot. Insert the CPCI-HD/2 module into the selected CompactPCI slot. Carefully push the board until it snaps into place.

  • Page 11: Leds

    Activity - data transfer at interface SATA1 LED220C green Activity - data transfer at HDD interface LED220B green Activity - data transfer at CompactFlash interface LED220A Table 6: Description of LEDs CPCI-HD/2 Hardware Manual • Doc. No.: I.2318.21 / Rev. 1.1 Page 11 of 14...

  • Page 12: Connector Assignment

    DT+, DT-, DR+, DR- … Receive and transmit signal lines of the respective interface. The data direction reference is the external drive (device). GND... Reference potential Page 12 of 14 Hardware Manual • Doc. No.: I.2318.21 / Rev. 1.1 CPCI-HD/2...

  • Page 13: Declaration Of Conformity

    Declaration of Conformity 6. Declaration of Conformity CPCI-HD/2 Hardware Manual • Doc. No.: I.2318.21 / Rev. 1.1 Page 13 of 14...

  • Page 14: Order Information

    Type Properties Order No. CompactPCI MassMemoryBoard (3U/4HP) - 2 interfaces for external SATA drives CPCI-HD/2 - 1 interface for on-board 2.5” IDE-HDD I.2318.04 - 2.5” HDD installed, capacity ≥ 40 Gbyte - 1 CF-card slot (type I) in front panel...
  • Page 15 Information about Usage of CompactFlash ® Cards! A correct functionality of the CompactFlash interface can only be ensured by usage of CompactFlash cards with guaranteed SSD-properties. esd therefore recommends to use one of the listed SLC-cards: - Western Digital SiliconDrive II (e.g. 4GB: SSDC04G-4600) - Cactus CompactFlash 303 Series (e.g.
