- Page 1 USER MANUAL DuraNET 10-10 ® Rugged 5-Port 10/100 Ethernet Switch MNL-0603-01 rev A1 14 DEC 2011 RUGGED SOLUTIONS FOR REAL WORLD APPLICATIONS www.parvus.com...
- Page 2 Although the information contained herein has been carefully verified, Parvus Corporation assumes no responsibility for errors that might appear in this document or for damage to property or persons resulting from improper use of this manual or related software. Parvus reserves the right to change the contents and form of this document, as well as the features and specifications of its products at any time without notice.
-
Page 3: Table Of Contents
DuraNET 10-10 User Manual Table of Contents Table of Contents ..............................3 Chapter 1 Introduction ............................5 Functional Description ............................5 Block Diagram ............................... 5 Features ................................. 6 Chapter 2 Quick Start-up ............................ 7 ... - Page 4 DuraNET 10-10 User Manual Appendix A – Glossary of Terms ..........................19 Eurotech Group Worldwide presence ........................21 Page 4 of 22 MNL-0603-01 rev A1 REF. ECO-TBA Effective: 14 Dec 2011...
-
Page 5: Chapter 1 Introduction
M12 connectors in a sealed and fanless metal chassis designed for mounting to any machine or flat surface. With provisions for exposure to wide thermal ranges, shock, vibration, dust particles, and liquid immersion, the rugged DuraNET 10-10 combines proven and open-architecture PC104 Ethernet switch and vehicle-grade power supply components in a rugged package designed for maximum reliability under extreme conditions, including provisions for hazardous locations and potentially explosive atmospheres. -
Page 6: Features
Options CBL-2430-01 Starter Ethernet Cable for DuraNET 10-10 Ethernet Switch, M12 to RJ-45 CBL-2430-02 Starter Power Cable for DuraNET 10-10 Ethernet Switch for M12 Connector Conformal Coated Internal Printed Circuit Boards (PCBs) for Enhanced Humidity Protection Warranty ... -
Page 7: Chapter 2 Quick Start-Up
The standard configuration also includes support for auto-crossover, auto-polarity, auto-negotiation, and bridge loop prevention. The DuraNET 10-10 provides much the same functionality as you would expect in a high quality off-the-shelf retail switch but in a rugged, ultra-reliable package designed for outdoor, mobile and extreme environments. The following sections of this chapter assumes the utilization of either the starter cable set or a custom set of cables made specifically for the intended target system, vehicle, or craft. - Page 8 DuraNET 10-10 User Manual CBL-2430-01 Starter Ethernet Cable for DuraNET 10-10 Ethernet Switch, M12 to RJ-45 (For J1 / J2 / J3 /J4 / J5 Connector) CBL-2430-02 Starter Power Cable for DuraNET 10-10 Ethernet Switch for M12 Connector (for J6 Connector)
-
Page 9: Chapter 3 Connector Description
DuraNET 10-10 User Manual Chapter 3 Connector Description This chapter includes the pinouts and signal descriptions for the DuraNET 10-10. Also provided in this section are connector part numbers along with suggested mating connectors. Connector Identification Table 3.1 DUNET-10-10-00 and -02 Connectors... -
Page 10: Connector Part Numbers
Figure 3.2 Connector Layout using RJ-45 connectors. See Table 3.3 Connector Part Numbers The following table shows the manufacturer part numbers for the various connectors fitted to the DuraNET 10-10, together with the recommended mating connections. Table 3.3 DUNET-10-10-01 and -03 Connector Part Numbers... -
Page 11: Connector Pinouts
This section provides the pinouts necessary for creating cables that would properly connect to this assembly. Note: If custom cabling is not designed and built by Parvus, all EMI and EMC design considerations for the cabling harness must be handled by the party responsible for building said cabling. -
Page 12: J1-J5 Switched Ethernet For Dunet-10-10-00 And -02
DuraNET 10-10 User Manual J1-J5 Switched Ethernet For DUNET-10-10-00 and -02 Connector Alignment: facing insert side of connector, master keyway is facing up. Table 3.4 J2 Pin Signals Signal Description Tx1+ Transmit Positive Tx1- Transmit Negative Rx1+ Receive Positive Rx1- Receive Negative Connector J2 pins 5 through 13 are not connected. -
Page 13: Chapter 4 Specifications
DuraNET 10-10 User Manual Chapter 4 Specifications This chapter provides the specifications for the DuraNET 10-10. Technical Specifications This section describes the technical specifications of the DuraNET 10-10. Data Transfer 10 Mbits/sec or 100 Mbits/sec, Full Duplex or Half Duplex Mode Compliance ... -
Page 14: Reliability
Weight The DuraNET 10-10 assembly weighs approximately 3.5 lbs (1.58 kgs) without cabling attached. Dimensions The following diagrams provide the physical dimensions of the DuraNET 10-10. Several angles of the assembly are depicted. Figure 4.1 Front Dimensions Page 14 of 22 MNL-0603-01 rev A1 REF. - Page 15 DuraNET 10-10 User Manual Figure 4.2 Side Dimensions Figure 4.3 Mounting Dimensions (Bottom Side) MNL-0603-01 rev A1 REF. ECO-TBA Effective: TBA Page 15 of 22...
-
Page 16: Chapter 5 Troubleshooting
Parvus is unable to test the DuraNET 10-10 against all known Ethernet device chipsets, and as such can not guarantee 100% compatibility with all devices. If you are having difficulty communicating through one of the DuraNET 10-10 ports to an external Ethernet device, please ensure that the external device has a working network interface by testing it with another Ethernet communication device. -
Page 17: Returning For Service
Maintenance The DuraNET 10-10 is a rugged Ethernet switch designed for harsh mobile environments. As such, it requires no maintenance except light cleaning for aesthetic appeal, isopropyl alcohol works best. If anything beyond this needs to be done refer to the “Returning for Service” section above. -
Page 18: Chapter 6 Contact Info
DuraNET 10-10 User Manual Chapter 6 Contact Info Main Phone: +1 (801) 483-1533 Fax: +1 (801) 483-1523 Sales +1(800) 483-3152 or (801) 483-1533, sales@parvus.com Product Technical Support +1 (801) 433-6322, tsupport@parvus.com Customer Feedback feedback@parvus.com Company contact info: ® Parvus Corporation 3222 S. - Page 19 DuraNET 10-10 User Manual Appendix A – Glossary of Terms 10BaseT 10 Mbps Ethernet system based on Manchester signal encoding transmitted over Category 3 or better twisted-pair cable. 100BaseTX 100-Mbps Fast Ethernet specification using Category 5 UTP wiring. Based on the IEEE 802.3u standard.
