- Page 1 ELSETA IOmod 8DI8DO User manual for IEC 60870-5-103 protocol Elseta 4/17/2019 V1.1...
-
Page 2: Table Of Contents
Addressing configuration ......................10 Testing with “THE VINCI” software ......................10 Technical information ..........................12 Mounting and installation guide ........................ 13 IOmod 8DI8DO RS485 interface ......................13 IOmod 8DI8DO inputs ........................13 IOmod 8DI8DO outputs ........................14 Configuration over USB ..........................15 Driver installation .......................... - Page 3 4/17/2019 COPYRIGHTS AND TRADEMARKS Elseta is a trademark of UAB Elseta and identifies products manufactured by UAB Elseta. All of the product copyrights belong to UAB Elseta. These documents and product properties cannot be changed without the knowledge and written consent of UAB Elseta. This document may be modified by UAB Elseta without additional notice.
- Page 4 – areas where equipment failure can result in a nature or human injury. Do not operate the equipment in extreme weather conditions as they may affect the operation of the equipment. V1.1 | ELSETA | Introduction...
-
Page 5: Introduction
4/17/2019 1 INTRODUCTION IOmod 8DI8DO is a small size stand-alone Modbus RTU or IEC 60870-5-103 digital input and digital output controller (protocol depends on firmware). IOmod can be used for industrial applications, where digital signalling is used and robust communication is needed. IOmod is an ideal solution for applications such as data acquisition, control, process monitoring at remote places. -
Page 6: Output Control
When grouped, second pin in the pair is not used anymore – all requests for this pin generate an error. For example – OUT1 and OUT2 can be grouped, after that OUT2 is not V1.1 | ELSETA | Operational information... - Page 7 Now, General interrogation will be composed of 7 output states (with OUT2 missing), and 7 input states (with IN4 missing). Output and input numbers is represented by “Info number” in protocol. V1.1 | ELSETA | Operational information...
-
Page 8: Input Filter
1s. When user sends ON command, OUT2 is pulsed for 1s, and relay is set. This will connect NO contact and IN2 will turn on (assuming it is not inverted). When user sends OFF command, OUT1 is pulsed, and relay is reset, turning IN1 on. V1.1 | ELSETA | Operational information... -
Page 9: Output Detection With Inputs
“Remote Operation”. If inputs are never turned on or off, device will send “Remote Operation” message after time-out period, with current input statuses. Time-out period is configured by user as a Feedback Time. V1.1 | ELSETA | Operational information... -
Page 10: Addressing Configuration
Output address (Function type) 128, and output number (Info number). Fig. 3.6 shows 1 output command sent and “CMD ACK” response received. Fig. 3.7 shows first 4 Outputs and last 4 Inputs grouped (notice the order of info numbers). V1.1 | ELSETA | Testing with “THE VINCI” software... - Page 11 IOmod 8DI8DO 4/17/2019 Fig. 3.6. Replies from IOmod device after a command has been sent though “THE VINCI” software Fig. 3.7. Representation of grouped output and inputs in “THE VINCI” software V1.1 | ELSETA | Testing with “THE VINCI” software...
-
Page 12: Technical Information
Electrical specifications 8 x 2kV RMS (1 minute) isolated 12-24VDC; Inputs Selectable inversion. 8 x 3kV isolated open collector outputs (300mA Outputs each, Max 50V); Power Power Supply 9V to 33V Current consumption 70 mA V1.1 | ELSETA | Technical information... -
Page 13: Mounting And Installation Guide
Fig. 5.1. Typical device connection diagram IOmod 8DI8DO has 1/8 Unit load receiver which allows to have up to 256 units on line (compared to standard 32 units). To reduce reflections, keep the stubs (cable distance from main RS485 bus line) as short as possible when connecting device. -
Page 14: Iomod 8Di8Do Outputs
Fig. 5.3. Configuration with pull-ups and software input inversion on input pins 5.3 IOmod 8DI8DO OUTPUTS IOmod 8DI8DO has 8 open collector digital outputs. Internal clamp diodes are connected to each output which makes IOmod 8DI8DO ideal for driving inductive loads like relays. Maximum 300mA per output is allowed. -
Page 15: Configuration Over Usb
Fig. 6.2. Software update screen Select “x86” driver for 32-bit machine, or x64 for 64-bit machine. If not sure, select root folder (folder in which x64 and x86 lays inside). Fig. 6.3. Folder with Elseta device drivers V1.1 | ELSETA | Configuration over USB... -
Page 16: Iomod Configuration With Putty Terminal
(exit) before disconnecting device. Default values is set by pressing [6] on main screen and confirming changes [1]. Baud rate window is shown in Fig 6.5. Fig. 6.5. Baud rate and communication settings selection V1.1 | ELSETA | Configuration over USB... - Page 17 Input (Fig.6.7) and output grouping screen show the connection between neighbour pins. Straight pins show that input or outputs are not grouped. Grouped inputs or outputs contain fold slashes in direction of another pin in the pair. Fig. 6.7. Input grouping screen V1.1 | ELSETA | Configuration over USB...
- Page 18 Attached pins are automatically grouped to conform to IEC- 60870-5-103 protocol. Fig. 6.10. Diagnostics screen Changes in the device and firmware version are shown in a Diagnostics Screen. Such diagnostics screen for IOmod 8DIDO is shown in Fig. 6.10. V1.1 | ELSETA | Configuration over USB...
-
Page 19: Main Menu
(0 if not used) Output detection Attach and detach 0 – 60000 with inputs inputs to outputs for milliseconds (0 if (feedback) detection; not used) Set detection timeout (timeout to send “Remote Operation” V1.1 | ELSETA | Configuration over USB... -
Page 20: Protocol Simulator
Device should enter a Firmware Upgrade mode. It means that device switches from USB Console mode into Mass storage device and computer recognize it as USB Storage. It is recommended to close terminal window when entered firmware upgrade mode. Device should the reconnect as a Mass Storage Device: V1.1 | ELSETA | Configuration over USB... - Page 21 User then must delete existing file “firmware.bin”, and simply drag and drop new firmware file. Fig. 6.13. Firmware file of an IOMOD device Reconnect device, set default settings and check firmware version in Diagnostics screen. V1.1 | ELSETA | Configuration over USB...
-
Page 22: Information About The Equipment Manufacturer
IOmod 8DI8DO 4/17/2019 7 INFORMATION ABOUT THE EQUIPMENT MANUFACTURER Office address: L. Zamenhofo g. 3 LT-06332 Vilnius Lithuania Tel.: +370 5 2032302 Email: support@elseta.com Web: www.elseta.com V1.1 | ELSETA | Information about the equipment manufacturer... -
Page 23: Document History
2017.03.20 Initial IEC 60870-5-103 documentation V1.1 2019.04.17 RS, AJ Extended version for IEC 60870-5-103 firmware to conform to version v.1.7.5. New features: • Broadcast time synchronization; • Extension of configuration screens; • Diagnostics screen; V1.1 | ELSETA | Document history...
