- Page 1 User manual WLAN Card 802.11b/g/n USB Adapter (Ralink RT3070) Model Number: WUS-N10M Revision: 1.0 Alpha Networks Proprietary and Confidential Information...
- Page 2 Revision History Rev. Date Author Reason for Changes • Jun. 22,2010 Dephany Liu New released Alpha Networks Proprietary and Confidential Information...
-
Page 3: Table Of Contents
EQUIREMENTS 2.3.1 Information ................................ 2.3.2 Configuration ................................ 2.3.3 Encryption ................................ 2.4 M ............................ ECHANICAL EQUIREMENTS 2.5 C ............................ OMPATIBILITY EQUIREMENTS 2.6 R ................ EQUIREMENTS OF ELIABILITY AINTAINABILITY AND UALITY 2.7 E ........................... NVIRONMENTAL EQUIREMENTS Alpha Networks Proprietary and Confidential Information... - Page 4 2SHUDWLRQ 0DQXDO , ,QVWDOO 'ULYHU ,QVWDOO WKH WHVW GULYHU $OSKD 1HWZRUNV 3URSULHWDU\ DQG &RQILGHQWLDO ,QIRUPDWLRQ...
- Page 5 7; VLJQDO FRPPDQG 6HOHFW 7;5; VLWH 6HOHFW FKDQQHO GDWDUDWH DQG &KDLQ )RU FRQWLQXH 7; VHOHFW FRQWL SUHVV VWDUW W[ )RU FRQWLQXH SDFNHWV W[ VHW UHSHDW WR SUHVV VWDUW W[ $OSKD 1HWZRUNV 3URSULHWDU\ DQG &RQILGHQWLDO ,QIRUPDWLRQ...
- Page 6 5; VLJQDO FRPPDQG 6HOHFW 7;5; VLWH 6HOHFW FKDQQHO GDWDUDWH DQG &KDLQ $OSKD 1HWZRUNV 3URSULHWDU\ DQG &RQILGHQWLDO ,QIRUPDWLRQ...
-
Page 7: Scope
Support WEP, 802.1x, WPA and WPA2 enhanced security Friendly user configuration and utilities Drivers support Windows 2K, XP 32/64-bit, Vista 32/ 64-bit Support external WPS button to connect Access Point easily High speed USB 2.0 interface RoHS compliant Alpha Networks Proprietary and Confidential Information... -
Page 8: Requirements
Note: The maximum power setting will vary according to individual country regulations. 2.2.1.8 Receiver Sensitivity Typical Sensitivity at each RF chain. Frame (1000-byte PDUs) Error Rate = 8% –94dBm at 1Mbps –92dBm at 2Mbps –90dBm at 5.5Mbps Alpha Networks Proprietary and Confidential Information... -
Page 9: Ieee 802.11G Section
BPSK, QPSK, 16QAM, 64QAM with OFDM Modulation Type 2.2.3.3 Operating 2400 ~ 2483.5MHz ISM band Frequency 2.2.3.4 Data Rate GI=800ns GI=400ns 20MHz 40MHz 20MHz 40MHz 13.5 14.4 19.5 40.5 21.7 28.9 43.3 57.8 58.5 121.5 65.0 Alpha Networks Proprietary and Confidential Information... -
Page 10: General Section
–87dBm at MCS0/8 –83dBm at MCS1/9 –81dBm at MCS2/10 –78dBm at MCS3/11 –76dBm at MCS4/12 –72Bm at MCS5/13 –70dBm at MCS6/14 –68dBm at MCS7/15 2.2.4 General Section Feature Detailed Description 2.2.4.1 Antenna Type External antenna Alpha Networks Proprietary and Confidential Information... -
Page 11: Software Requirements
Support open system and shared key authentication 2.3.3.2 WEP Management Four WEP keys can be selected STA with WEP off will never associate any AP with WEP enabled WEP Key Format: Option for Hex format Alpha Networks Proprietary and Confidential Information... -
Page 12: Mechanical Requirements
MTBF Mean Time Between Failure > 30,000 hours 2.6.2 Maintainability There is no scheduled preventive maintenance required 2.6.3 Quality The product quality is followed-up by Alpha Networks factory quality control system 2.7 Environmental Requirements Feature Detailed Description 2.7.1 Operating The product is capable of continuous reliable operation when operating... - Page 13 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio...
- Page 14 for 2.4G band by supplied firmware programming tool. OEM shall not supply any tool or info to the end-user regarding to Regulatory Domain change. As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM integrator is still responsible for testing their end-product for any additional compliance requirements required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).
