Warmington Southern Series Quick Start Manual

Door glass fitment
Hide thumbs Also See for Southern Series:
1
2

Advertisement

Table of Contents

Southern Series Door Glass Fitment

No: 1
The Southern Series Door Glass is a special heat
resistance glass designed for use in Fires.
No: 3
Remove the Glass. The bottom retainers should
still be in position & loosened enough to do so.
NOTE: Door Glass is not covered by Warranty

Tools - required but not supplied:

3mm Allen Key
No: 2
The glass can be replaced with the door still fitted to the Fire.
Remove the cap screws & retainers on the sides of the door that
hold the glass in position, then loosen the cap screws & bottom
retainers enough to be able to remove glass.
1 x
No: 4
Ensure that both glass rope and surfaces are clean before
replacing with the new glass.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Southern Series and is the answer not in the manual?

Questions and answers

Related Manuals for Warmington Southern Series

Summary of Contents for Warmington Southern Series

  • Page 1 No: 2 The glass can be replaced with the door still fitted to the Fire. The Southern Series Door Glass is a special heat Remove the cap screws & retainers on the sides of the door that resistance glass designed for use in Fires.
  • Page 2 No: 5 No: 6 Place the new glass into the door at the bottom Fit the side retainers back onto the door with the cap screws. Nip up and push against glass rope. Nip up bottom cap cap screws ensuring not to over tighten as this may crack/break the screws with a 3mm Allen Key to hold glass in glass.
