- Page 1 杭州金指码实业有限公司 Customer : Applied To : Product Name : Magnetic Transducer Model Name : KPM-G1203B1-3293 Drawing No. : OEM3293R Compliance with ROHS Signature of Approval Signature of KEPO Approved by Checked by Issued by Date 宁波凯普电子有限公司 Ningbo Kepo Electronics Co.,Ltd.
-
Page 2: Table Of Contents
额定极限条件 4. Electrical Characteristics 电性能 5. Measuring Method 测试方法 6. Physical Characteristics 机械性能 7. Environmental Characteristics 环境性能 8. Dimensions 尺寸 9. Packaging Standard 包装标准 10. Cautions 警告 11. Cautions for Use 注意事项 12. Revision 履历表 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 3: Maximum Rating
3. 额定极限条件 Maximum Rating 项目 规 格 Item Specification 工作温度范围 -20 ～ +70 ℃ Operating Temperature Range 储存温度范围 -30 ～ +80 ℃ Storage Temperature Range 额定电压 3.3V Rated Voltage 工作电压 2 ～ 5V Operating Voltage Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 4: Electrical Characteristics
℃ , 湿度 45 ～ 85%R.H. 的范围内测试 . Part shall be measured under a condition (Temperature :+5 to +35 ℃ ,Humidity :45 to 85%R.H.)unless the standard condition (Temperature :+25 ± 3 ℃ ,Humidity :60 ± 10 %R.H.) is regulated measure. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 5: Physical Characteristics
分别在每个插针的轴向施加 9.8 牛顿的静荷 插针没有断开和 重 10 秒 . 可见的损伤 插针强度 No visible Terminal The force 10 seconds of 9.8N is applied to damage and Strength Pulling each terminal in axial direction. cutting off Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 6: Environmental Characteristics
-20± 2 ℃试验箱中，再工作 1 小时，经过 6 个循环后，在正常大气 压条件下恢复 1 小时，进行测量 20 Sec. +70 ℃ -20 ℃ 1 hour 1 hour 表 1 Table 1 项 目 试验后变化量 Specification after test Item 声压级 初始值± 10dB Sound Pressure Level Initial Value ± 10dB Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 7: Dimensions
Page Specification for Magnetic Transducer Revision No. Model No. : KPM-G1203B1-3293 Drawing No. OEM3293R 8. Dimensions 6.5± 0.2 Ø12 2-Ø0.6 waterproof seal Ø2.6 FIRST ANGLE PROJECTION UNIT ± 0.5 Tolerance : Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 8: Packaging Standard 包装标准 10. Cautions 警告
控制在 3 秒内 . In case of using solder iron for soldering, the top of soldering iron's temperature should be kept less than +350 ℃ .Moreover the soldering time should be also kept with in 3seconds. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 9: 12. Revision
Page Specification for Magnetic Transducer Revision No. Model No. : KPM-G1203B1-3293 Drawing No. OEM3293R 12. Revision Rev. DATE PAGE DESCRIPTION SIGN primary 2008.11.21 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
