- Page 1 SPECIFICATION Customer : Applied To : Product Name : Mechanical Buzzer Model Name : KPMB-G38012L-3212 Drawing No. : OEM3212R Compliance with ROHS( 本品符合 ROHS 指令 ) Signature of Approval Signature of KEPO Approved by Checked by Issued by Date 宁波凯普电子有限公司...
-
Page 2: Table Of Contents
电性能 5. Measurement Block Diagram & Response Curve 测试图和曲线图 6. Physical Characteristics 机械性能 7. Environmental Characteristics 环境性能 8. Dimensions 尺寸 9. Packaging Standard 包装标准 10. Cautions 警告 11. Cautions for Use 注意事项 12. Revision 履历表 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 3: Maximum Rating
-30 ～ +70℃ Storage Temperature Range 额定电压 12VAC/50HZ Rated Voltage 工作电压 10.5～13.5VAC Operating Voltage 4. 电性能 Electrical Characteristics Specification Item 规 格 项目 Max.Rated Current 250mA 额定电流 Min.Sound Pressure Level 75dB/12VAC/20cm 最小声压 Coil Resistance 54.5± 10%Ω 直流电阻 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 4: Measurement Block Diagram & Response Curve
℃ , 湿度 45 ～ 85%R.H. 的范围内测试 . Part shall be measured under a condition (Temperature :+5 to +35 ℃ ,Humidity :45 to 85%R.H.)unless the standard condition (Temperature :+25 ± 3 ℃ ,Humidity :60 ± 10 %R.H.) is regulated measure. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 5: Physical Characteristics
分别在每个插针的轴向施加 9.8 牛顿的静荷 插针没有断开和 重 10 秒 . 可见的损伤 插针强度 No visible Terminal The force 10 seconds of 9.8N is applied to damage and Strength Pulling each terminal in axial direction. cutting off Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 6: Environmental Characteristics
-20± 2 ℃试验箱中，再工作 1 小时，经过 6 个循环后，在正常大气 压条件下恢复 1 小时，进行测量 20 Sec. +60 ℃ -20 ℃ 1 hour 1 hour 表 1 Table 1 项 目 试验后变化量 Specification after test Item 声压级 初始值± 10dB Sound Pressure Level Initial Value ± 10dB Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 7: Dimensions
Page Specification for Mechanical Buzzer Revision No. Model No. : KPMB-G38012L-3212 Drawing No. OEM3212R 8. Dimensions 28.5 6.55 Ø3.1 Plastic tube AWG26#(RED) AWG26#(BLACK) FIRST ANGLE PROJECTION UNIT Tolerance : ± 0.5 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... -
Page 8: Packaging Standard
控制在 3 秒内 . In case of using solder iron for soldering, the top of soldering iron's temperature should be kept less than +350 ℃ .Moreover the soldering time should be also kept with in 3seconds. Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com... - Page 9 Page Specification for Mechanical Buzzer Revision No. Model No. : KPMB-G38012L-3212 Drawing No. OEM3212R 12. Revision Rev. DATE PAGE DESCRIPTION SIGN primary 2009.06.18 Ningbo Kepo Electronics Co.,Ltd. http://www.chinaacoustic.com...
