CIS WAP XL - User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WAP XL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CIS WAP XL

Summary of Contents for CIS WAP XL

  • Page 1 CIS WAP XL - User Manual...

  • Page 2: Table Of Contents

    Table of Contents Welcome to Custom Integration Solutions ....................... 4 Overview ................................... 4 Package Contents ..............................4 Power ..................................4 Indoor use only ............................... 4 Device Details ................................5 Ports..................................5 LED Indicators ................................5 Buttons ..................................5 Mounting Options ................................ 6 Wall Mount ................................
  • Page 3 Managing Access Points with the Wireless Manager .....................17 Linking CIS Access Points to the Wi-Fi Manager ....................17 Viewing the Connected Access Points .........................18 Viewing Connected Devices ..........................18 Changing the SSID of Managed Access Points ....................19 Changing the Wi-Fi Password of Managed Access Points ................19 Configuring Access Points in Standalone Mode .....................21...

  • Page 4: Welcome To Custom Integration Solutions

    CIS wireless access points provide a compact and powerful solution for your home and commercial connectivity needs. The CIS WAPXL provides the power of our ACWAP with increased range. Link it to the Wi-Fi manager and control it with your CIS router, just like our other access points.

  • Page 5: Device Details

    USR LED light starts flashing, (5 seconds) then release the button to reset to the default CIS configuration. You can use this procedure if you have forgotten the password to access the device, or simply wish to return the unit to its default configuration state.

  • Page 6: Mounting Options

    Mounting Options The CIS-WAPXL has multiple mounting options for walls, ceilings, and low-voltage mounting brackets. Wall Mount 1. Plug the Ethernet cable into Ether1. 1. Drill two 4.5-5mm holes. 2. Move the access point into position. 2. Insert the plastic anchors.

  • Page 7: Ceiling Mount

    Ceiling Mount 1. Drill two 4.5-5mm holes for the screws. 1. Thread the ethernet cable through the hole 2. Drill a hole for the ethernet cable. in the metal plate. 3. Attach the metal plate on the other side of 2.

  • Page 8: Low Voltage Mounting Brackets

    Low Voltage Mounting Brackets Attach the metal strip to the low voltage gang Attach the mounting bracket to the metal strip box using the included screws. using the flathead screws. Connect the ethernet cable to Ether1 of the access Slide the access point onto the mount until it point.

  • Page 9: Quick Setup

    Quick Setup 1. Connect the Ethernet cable from your router to Ether1 on the access point. If your router supports PoE, turn it on to power the device. If not, use the included PoE injector. 2. (Optional) Connect an additional access point or device to Ether2. The port is bridged, meaning it acts like a switch port.

  • Page 10: Accessing The Web Interface

    1. Connect your laptop or PC to the router. 2. Obtain the IP address of your access points. If you’re using a CIS router, access the web configuration by typing 10.100.1.1 in a web browser (10.100.1.1 is the default, but some systems may be different).

  • Page 11: Setting The Access Point's Identity

    Setting the Access Point’s Identity The identity is used to identify your device on the network. Troubleshooting will become easier when you set the identity correctly. Set the identity of the access point based on its location E.g., Basement. The Identity setting can be found in the System tab in the left toolbar.

  • Page 12: Undo / Redo

    Undo / Redo Undo and Redo buttons are located in the left toolbar. You may use them to quickly undo/redo any changes made to configuration. Show / Hide Passwords Selecting the Hide Passwords button in the left toolbar will toggle the displaying of passwords related to Wi-Fi, Hotspot, and more.

  • Page 13: Changing The Default Password

    Changing the Default Password After you log in for the first time, please create a new a password to increase the security of the device. Enter the old password in the top field and a secure password in the new and confirm password fields. Setting the Time Zone You can find the Clock settings under the System tab in the left toolbar.

  • Page 14: Ip Addressing

    The DHCP Client Tab The DHCP Client tab will present you with the IP address assigned to your access point from the router. CIS recommends creating a DHCP reservation for access points and other network infrastructure devices. Renewing the IP Address...

  • Page 15: Setting A Static Ip Address

    If your network falls in one of the ranges below, you can set the static IP address yourself. If it is outside of these ranges, you must call CIS to have a route created on the access point! Available address ranges: 172.16.1.0/24...
  • Page 16 Once the static IP aSddress is set, disable the DHCP client. Go to IP > DHCP Client and click on the entry. Click on the small ‘D’ button to disable it.

  • Page 17: Managing Access Points With The Wireless Manager

    Wi-Fi Manager. Check the Enabled box, click Apply, then OK. The device will display the message --- managed by CAPsMAN. The Access point is now linked to your CIS router and can be managed through the router’s configuration page.

  • Page 18: Viewing The Connected Access Points

    Viewing the Connected Access Points On your CIS router, select the Wi-Fi Manager section in the left toolbar. The active Wi-Fi radios will be displayed. If you select the WiFi Access points tab, you’ll be able to view the identity, MAC address and other information of the individual access points.

  • Page 19: Changing The Ssid Of Managed Access Points

    Enter the name of the SSID in the field. Copy and paste the SSID so that the 5GHz network has the same SSID. CIS Guest Changing the Wi-Fi Password of Managed Access Points Select the Wi-Fi Password tab. Click on the network that you’d like to change the password for. If you’ve...
  • Page 20 Click on the network you’d like to set the password for, then enter the passphrase in the box below. It is highly recommended you use only WPA2 PSK for security purposes. WPA is vulnerable to password cracking.

  • Page 21: Configuring Access Points In Standalone Mode

    Configuring Access Points in Standalone Mode CIS access points can be centrally managed via the Wi-Fi manager on CIS routers, or they can operate as standalone units. This section includes instructions for setting up access points as standalone units. Setting the SSID Select the Wireless tab from the left toolbar.

  • Page 22: Setting The Wi-Fi Password For Standalone Access Points

    Enter the password in the WPA2 Pre-Shared Key field. CIS recommends you leave WPA PSK disabled, as it is a vulnerable protocol. If you have legacy devices that require it, enable it, and copy and paste the...

  • Page 23: Enabling The Guest Network On Standalone Access Points

    Enabling the Guest Network on Standalone Access Points CIS access points running in standalone mode can run a simple guest network. To enable, click the E button in the WiFi Interfaces tab of the Wireless section. Enable both the 2.4 and 5 GHz networks.

  • Page 24: View Connected Devices

    View Connected Devices In the Wireless section, click the Registration tab to view the connected devices. You can identify them based on their MAC address. You can view the uptime, signal strength, traffic flow, and more. Setting up the Access Point as a Repeater In the Wireless section, select the WiFi Interfaces tab.

  • Page 25: Tools

    Tools UPnP Universal Plug and Play enables the discovery other devices located on the network and vice-versa. If you require UPnP, select it under the IP tab in the toolbar, then enable it. UPnP has implications on the security of the device, and it is recommended you leave it disabled unless required. Ping Ping uses Internet Control Message Protocol (ICMP) echo messages to determine if a remote host is active.

  • Page 26: Ip Scan

    IP Scan The IP scan tool locates devices on the network. It can also locate devices that have a static IP set internally if they are on the same network as your access point. To use the IP scan tool, select the network you wish to scan on (bridge-operations is default), then enter the network address and subnet mask using CIDR notation.

  • Page 27: Troubleshooting

    Some devices have issues with multiple access points with the same SSID. • If this is the case, contact CIS and we will make a separate SSID for these devices that is only broadcast on one access point.
  • Page 28 PoE. Try plugging the access point directly into the router or switch with a short cable. • CIS routers and switches provide more stable PoE when the port is set to “Forced On”. Review the user manuals for instructions.

  • Page 29: Warranty Information

    Solutions™ or a designated service center with prior notification and an assigned return authorization (RA) number. Contact Information Web: www.custom-integration-solutions.com Phone: Technical Support - (888) 976-3651 Email: activations@custom-integration-solutions.com CIS Access Points are in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EC.
