CIS—WAP/ACWAP
Welcome
Thank you for choosing CIS! This quick setup guide will assist you with getting your CIS access points up
and running. For more detailed configuration, please check the user manuals located on our website. If
you have any questions, please do not hesitate to contact our support team.
Overview
CIS access points provide excellent Wi-Fi coverage in homes and commercial applications. The small foot-
print and weatherproof housing make them a great fit for a range of indoor and outdoor applications.
They can be mounted on walls or ceilings with the Ethernet cable completely hidden from sight.
Combine the access points with a CIS router for centralized management of your access points. Easily
push SSID and password changes to all access points from a single interface.
The CIS-ACWAP (Gen 2) has been upgraded with increased throughput, a DC input, and an additional
Ethernet port for linking other devices.
CIS access points provide support for the following standards:
CIS-WAP: 2.4 GHz range—802.11 b/g/n supported
•
CIS-ACWAP: 2.4 GHz and 5 GHz ranges—802.11 a/b/g/n/ac supported
•
Powering the Access Points
CIS-WAP : Power via the DC jack, the included PoE injector, or power directly from a PoE router or
•
switch.
CIS-ACWAP: Power via the included PoE injector or directly from a PoE router or switch.
•
CIS-ACWAP (Gen 2): Power via the DC jack, the included PoE injector, or power directly from a PoE
•
router or switch. Use ETH1 if using PoE input.
CIS-WAP
CIS-ACWAP
CIS-ACWAP
(Gen 2)
Advertisement
Table of Contents
Related Manuals for CIS WAP
Summary of Contents for CIS WAP
- Page 1 CIS-ACWAP: 2.4 GHz and 5 GHz ranges—802.11 a/b/g/n/ac supported • Powering the Access Points CIS-WAP : Power via the DC jack, the included PoE injector, or power directly from a PoE router or • switch. CIS-ACWAP: Power via the included PoE injector or directly from a PoE router or switch.
- Page 2 Mounting CIS access points can be securely mounted to a wall, ceiling, or pole with the included mounting straps. 1. Use the template (included in the box) to mark the location of the screw holes.
- Page 3 Link to Wi-Fi Manager All CIS routers include a Wireless Manager that allows you to manage your access points from a single location. All changes to the SSIDs, passwords and other options will be propagated to all of the access points on the network.
- Page 4 This allows older devices to connect to the 2.4 GHz, and newer devices to connect to the 5 GHz network using a single SSID. Remember, the CIS WAP only provides 2.4 GHz. Use the same SSID for 2.4 and 5 GHz...
- Page 5 CIS—WAP/ACWAP Changing the Wi-Fi Password of Managed Access Points Select the Wi-Fi Password tab. Click on the network that you’d like to change the password for. If you’ve purchased a guest network, it will appear here. Enter the passphrase in the box below. It is highly recommended you select only WPA2 PSK for security reasons, as WPA is vul- nerable to cracking.
- Page 6 Hold this button while the device is powered off, then apply power. Keeping holding until the USR LED light starts flashing, (5 seconds) then release the button to reset to the default CIS configuration. You can use this procedure if you have forgotten the password to access the device, or simply wish to return the unit to its default configuration state.
