WARNING : Before servicing this chassis please read the safety recommendations.
ATTENTION : Avant toute intervention sur ce châssis, lire les recommandations de sécurité.
ACHTUNG : Vor jedem Eingriff auf diesem Chassis, die Sicherheitsvorschriften lesen.
ATTENZIONE : Prima di intervenire sullo chassis, leggere le norme di sicurezza.
IMPORTANTE : Antes de cualquier intervención, leer las recomendaciones de seguridad.
Code : 351 530 30
- 0301 / 00M -
No copying, translation, modification on other use authorized. All rights reserved worldwide. • Tous droits de reproduction, de traduction, d'adaptation et d'exécution réservés pour tous les pays. • Sämtliche Urheberrechte an diesen Texten und Zeichnunge n stehen uns zu. Nachdrucke,
Vervielfältigungen - auch auszugsweise - nur mit unserer vorherigen Zustimmung zulässig. Alle Rechte vorbehalten. • I diritti di riproduzione, di traduzione, e esecuzione sono riservati per tutti i paesi. • Derechos de reproduccion, de traduccion, de adaptacion y de ejecucion reservados para todos los paises.
Page 1
All manuals and user guides at all-guides.com SERVICE MANUAL DOCUMENTATION TECHNIQUE 42WS90E TECHNISCHE DOKUMENTATION 42WS90E2 DOCUMENTAZIONE TECNICA DOCUMENTACION TECNICA Plasma WARNING : Before servicing this chassis please read the safety recommendations. ATTENTION : Avant toute intervention sur ce châssis, lire les recommandations de sécurité.
Page 2
All manuals and user guides at all-guides.com Do not disconnect modules when they are energized! Repairs on power supply section are to be carried out only with isolating transformer. Ne pas retirer les modules lorsqu' ils sont sous tension. N'effectuer les travaux de maintenance sur la partie reliée au secteur (Switch Mode) qu'au travers d'un transformateur d'isolement.
All manuals and user guides at all-guides.com DISASSEMBLING THE MODULES 1. Removing the back panel - Remove the 17 screws , the 8 screws and the screw - Remove the back panel. BACK PANEL 2. Removing the terminal panels (S), (V), R TERM, L TERM, S-I/O and VIDEO I/O modules - Remove the 2 screws on the left side of the set and - Remove the 2 screws...
All manuals and user guides at all-guides.com 3. Removing the AUDIO and VIDEO modules - Remove the 4 screws and take out AUDIO module, - Remove the 4 screws and take out VIDEO module. AUDIO MODULE VIDEO MODULE SHIELD CASE (AUD) SHIELD CASE (VID) 4.
All manuals and user guides at all-guides.com 5. Removing the bracket (fan)/DC fan - Remove the 7 screws , the 2 screws , and the screw the bracket (fan), - Take out the bracket (fan), - Remove the 4 screws and take out the grand boards L and R - Remove the 16 screws and take out the DC fan from...
All manuals and user guides at all-guides.com WIRE LOCATION After replacement of the modules refer to the below diagram to mount ferrites and connect the modules again. Note: “RA” connectors are only fitted in 42WS90E2. First issue 03 / 01...
All manuals and user guides at all-guides.com DIAGNOSTIC The power LED located on the front of the display is a bicolour LED wich indicates the operating status including the normal, standby and three error detections 42WS90E-42WS90E2 No energization of POWER unit Is the power...
Page 9
All manuals and user guides at all-guides.com 42WS90E-42WS90E2 Power LED unlit Is the power plug correctly Rearrange the power plug connected to the wall outlet? connection correctly. Fuses F1 and F2 have blown Is there AC 100V behind out. Replace the fuses. If they...
Page 10
All manuals and user guides at all-guides.com 42WS90E The power LED is flashing green Is 0V observed at Pin 4 of Failure in the ANALOG module IC6800 (ANALOG module)? Is 0V observed at Failure in fan's peripheral Failure in the...
Page 11
All manuals and user guides at all-guides.com 42WS90E The power LED is flashing red Failure in the Is 0V observed at Pin 57 of IC6800 (ANALOG module)? ANALOG module Is 0V observed at pin 5 Failure in the of IC6808 (ANALOG module) ?
Page 12
All manuals and user guides at all-guides.com 42WS90E-42WS90E2 The power LED is fla- shing red and green Failure in the Is 0V observed at Pin 14 of IC6800 (ANALOG module)? ANALOG module Failure in the In the case of green and red flashing, the power supply...
All manuals and user guides at all-guides.com VIDEO TROUBLESHOOTING 42WS90E-42WS90E2 No video screen display Enter a color bar signal input Is there on-screen See page 18 display of VIDEO? With the signal line discon- Is there a video signal at...
All manuals and user guides at all-guides.com 42WS90E-42WS90E2 No RGB / PC screen display Enter a VGA or SVGA color bar signal input. Is there on-screen See page 18 display of "PC"? Is there horizontal sync at Is the LED litting green?
All manuals and user guides at all-guides.com 42WS90E-42WS90E2 No HD / DVD screen display Enter a color bar signal input Is there on-screen See page 18 display of "HD" or "DVD"? With the signal line discon- Is there a video signal at...
All manuals and user guides at all-guides.com 42WS90E-42WS90E2 No video in NTSC mode Is Y signal available at TP9003? Is there a video signal at TP9007? Is there a video signal at Pin Failure in the 1 of the YC connector?
All manuals and user guides at all-guides.com 42WS90E-42WS90E2 No video in PAL mode Is Y signal available at TP5004? Is there a video signal at TP5030? Is there a video signal at Pin Failure in the 1 of the YC connector?
All manuals and user guides at all-guides.com 42WS90E-42WS90E2 No display, ANALOG module analysis Is there a video signal at TP6139, TP6140 and TP6141? Is there a signal of 5Vp-p at Pins 1 ~ 47 of the AD connector (odd-numbers only)?
All manuals and user guides at all-guides.com 42WS90E-42WS90E2 Synchronisation trouble Enter a color bar signal input Is there a synchro. signal at Pins Is it a VIDEO input? Is it a HD/DVD input? 8 and 10 of the PC connector?
All manuals and user guides at all-guides.com AUDIO TROUBLESHOOTING 42WS90E-42WS90E2 No audio signal from SP output Is audio signal available at Failure in the AUDIO module at TP3001 and TP3002? Is audio signal available at pins Failure in the 1 , 3 , 4 , 6 , 8 , 10 of IC4001?
All manuals and user guides at all-guides.com ADJUSTMENTS ADJUSTMENTS NECESSARY AFTER REPLACEMENT OF MODULES: - After replacement of ANALOG module, perform the adjusments of "Video level" and "Video screen position". - After replacement of VIDEO module, perform the adjusments of "video level" and "video screen position". - After replacement of POWER or PDP module, perform the adjusment of "-180V and +180V"...
TP6141 (G-OUT) NTSC colour bar test pattern SERVICE Adjust "COLOR" line to obtain a blue level : MODE 1.2Vp-p (42WS90E) or 1.4 Vp-p (42WS90E2) Video input "D-CONTROL Adjust "TINT" line to obtain a blue level : TP6140 NTSC" menu 1.2Vp-p (42WS90E) or 1.4 Vp-p (42WS90E2)
Page 23
Check that Pedestal level is 1.8Vp-p, if not perform (B-OUT) adjustment of sub-contrast TP6141 (G-OUT) PAL colour bar test pattern SERVICE Adjust "COLOR" line to obtain a blue level : MODE 1.2Vp-p (42WS90E) or 1.4 Vp-p (42WS90E2) Video input "D-CONTROL White Cyan Magenta Blue Black TP6140 Linearly decreases PAL"...
VGA input Apply colour bar test pattern POWER +5V ADJ Adjust "+5V ADJ" : to either Video, HD/DVD or VGA input V = 5.0 V +/- 0.1 V (42WS90E) V = 5.1 V +/- 0.1 V (42WS90E2) First issue 03 /01...
All manuals and user guides at all-guides.com POWER module 42WS90E TP5 TP6 D-180V D+80V D+5V ADJ AC Inlet 42WS90E2 TP5 TP6 D+180V D+80V D+5V ADJ AC Inlet First issue 03 /01...
