Technical Information Manual Revision n. 8 24 March 2014 MOD. A 1735 - A 1835 A 1735B - A 1835B 12/28 CHANNEL HV BOARDS MANUAL REV.8 NPO: 00101/00:17XXx.MUTx/08...
Page 2
User. It is strongly recommended to read thoroughly the CAEN User's Manual before any kind of operation. CAEN reserves the right to change partially or entirely the contents of this Manual at any time and without giving any notice. Disposal of the Product The product must never b e dumped in the Municipal Waste.
Title : Re vision date: Re vision: User's Manual (MUT) Mod. A1735-A1835-A1735B-A1835B HV Boards 24/03/2014 TABLE OF CONTENTS MOD. A 1735 - A 1835 HV BOARDS ........................5 ............................. 5 UNCT IONAL DESCRIPTION ........................6 HANNEL HARACT ERISTICS ABLE ................................7...
Page 4
. A1735B - A 1835B ..........14 SIDE VIEW T OP VIEW LIST OF TABLES 2.1 - C . A 1735 / 1735B - A 1835 / 1835B HV B ....6 ABLE HANNEL CHARACTERIST ICS OF THE OARDS 3.1 - F ..........................
The boards are compatible with the CAEN Universal Multichannel Power Supply System (SYx527) The Mod. A 1735 - A 1735B output channels have 1.5 kV / 7 mA full scale range (dip- switch selectable); the Mod. A 1835 - A 1835B output channels offer either 1.5 kV / 7 mA or 1.5 kV / 200 µA full scale range (dip-switch selectable).
12 CH POSITIVE POSITIVE 1.5 KV 7/0.2 mA 1.5 KV 7/0.2 mA Fig. 1.1 – Mod. A 1735 – A 1835 (LEFT) and Mod. A 1735B – A 1835B (RIGHT) front panel NPO : File name: Number of pages: Page : 00101/00:17XXx.MUTx/08...
24/03/2014 Technical Specifications 1.4.1 Packaging The Mod. A 1735 – A 1835 modules are housed in a 5 TE-wide, 6U-high mechanics. The Mod. A 1735B – A 1835B modules are housed in a 10 TE-wide, 6U-high mechanics. 1.4.2 External connections The location of all components of the front panel is shown in Fig.
IEXT Fig. 1.2 – Mod. A 1735B – A 1835B HV Multipin Connector 1.4.3 Displays CH ON 0..11 LEDs (A 1735 - A1835): Function: they light up as the relevant channel is on. Type: red LEDs for positive polarity version;...
Document type: Title : Re vision date: Re vision: User's Manual (MUT) Mod. A1735-A1835-A1735B-A1835B HV Boards 24/03/2014 2. Safety information and installation requirements General safety information This section contains the fundamental safety rules for the installation and operation of the boards.
Refer to Manual Installation The Mod. A 1735 – A 1835 are single-width boards which can be inserted in any slot of the SYX527 crate. The Mod. A 1735B – A 1835B are double-width boards which occupy two SY 1527 slots each. At power ON the SYX527 system processor will scan all the slots in the crate to find out where the module is plugged and what kind of module it is.
24/03/2014 3. Operating modes The Mod. A 1735 – A 1835 and A 1735B – A 1835B boards can be controlled, either locally or remotely, through the SYX527 software interface. For details on SYX527 system operation, please refer to the User's Manual of this product. The following sections contain a description of commands available for the board control and status monitoring.
Document type: Title : Re vision date: Re vision: User's Manual (MUT) Mod. A1735-A1835-A1735B-A1835B HV Boards 24/03/2014 • (channel in OVERVOLTAGE condition) • (channel in UNDERVOLTAGE condition) • EXTTRIP (channel OFF due to external TRIP line signal) • INTTRIP (channel OFF due to internal OVERCURRENT condition) •...
Document type: Title : Re vision date: Re vision: User's Manual (MUT) Mod. A1735-A1835-A1735B-A1835B HV Boards 24/03/2014 T A B C Dip Switch (side view) 4 3 2 1 Out 0 Out 1 Out 2 Channels Channels Channels Out 3 Out 4 Out 5 Controller...
