New Digital T2 01 Manual

EN
* NOTE: this Tuner is supporting the reception of Free To Air
programs only
CONTENTS OF THE PACKAGE
Tuner Unit, Remote Control Unit, 2 pcs AAA type Batteries,
User Manual
Front panel and controls
1 2 3
Rear panel
and connection diagrams:
HDMI cable
OR
1 2
1. Read and follow these instructions.
2. Do not use this apparatus near water, heat sources, do not expose to direct sunlight and the
temperatures higher than in a normal household. For Indoor use only!
3. Clean only with a dry cloth, protect from moisture and dirt, do not cover the ventilation grid.
4. Operate this product only from the type of power source indicated on the label. Protect the
Device and the power cord from the moisture, physical damage.
5. Unplug this apparatus during lightning storms or when unused for a longer period.
6. Do not disassemble the unit or try to insert any extraneous items into it.
7. Refer all servicing to qualified service personnel only. Servicing is required when the apparatus
has been damaged in any way, including damage to the mains cord or plug, if the unit was
exposed to liquids or moisture, has been dropped, or not operating correctly.
1 POWER – Switches between working and Standby mode
2 CH-
5
3 CH+ switches TV program down the list
4 IR (Infrared remote control) window
4
5 USB -- connector for an external USB memory device (USB 2.0 support) located on the right
side
SCART
cable
1 RF IN: This socket connects to your external Aerial.
2 HDMI: High definition audio and video output used to connect to the TV HDMI socket
3 TV SCART – analog Audio/video output for connection to TV set
3
HIGH DEFINITION DIGITAL TERRESTRIAL
DVB-T2/T TUNER WITH H264 SUPPORT
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
Risk of electric shock!
DO NOT OPEN!
ATTENTION
Risque de choc electrique!
NE PAS OUVRIR!
This symbol indicates that dangerous voltages constituting a risk of electric shock are
present within this unit.
This symbol indicates that there are important operating and maintenance
instructions in the literature accompanying this unit.
This symbol indicates that this product incorporates double insulation between
hazardous mains voltage and user - accessible parts. When servicing use only identical
replacement parts.
This symbol on the product or in the instructions means that your electrical and
electronic equipment should be disposed at the end of life separately from your
household waste. There are separate collection systems for recycling.
For more information, please contact the local authority or your retailer where you
purchased the product.
This symbol on the product means that your equipment is suitable only for indoor use.
FRONT AND REAR PANELS AND CONNECTIONS DIAGRAM
switches TV program up the list
