User Manual
Canis014D07
Portable X-ray System
IMAGING THE FUTURE
E
Document version:
A0
E
Document ID:
921-201-02
Release date:
5/13/2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Canis014D07 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for iRay Technology Canis014D07

  • Page 1 User Manual Canis014D07 Portable X-ray System Document version: Document ID: 921-201-02 Release date: 5/13/2022 IMAGING THE FUTURE...
  • Page 3 Thanks you for purchasing the CANIS014D07 Portable X-Ray System (hereinafter referred to as CANIS014D07) from iRay Technology Taicang Ltd. (hereinafter referred to as iRay) as your X-ray solution. This manual contains all the general information about the CANIS014D07, which is intended to provide users with instructions on installation, operation and maintenance.
  • Page 4 CAUTION This symbol is used to indicate a prohibited operation. PROHIBITED This emphasizes or supplements important information about the main text. NOTE This symbol is used to indicate "Consult other sections of this manual for information". REFERENCE Canis014D07 User Manual...
  • Page 5 To Customers Abbreviations Abbreviations Explanation Federal Communications Commission Source-to-Skin Distance Serial Number User Interface Window Level Window Width Canis014D07 User Manual...
  • Page 6: Table Of Contents

    Recommended Exposure Time ..........................17 TECHNICAL SPECIFICATIONS ........................18 Portable X-Ray System ............................18 Adapter ................................. 20 Battery ...................................20 USER INTERFACE ............................22 Login Page ................................22 Home page ................................23 Patient Information Page ............................24 Image Acquisition Page ............................24 Canis014D07 User Manual...
  • Page 7 Contents Image View Page ..............................26 Setting Page ................................27 SERVICE INFORMATION ..........................31 Service Life ................................31 Periodic Inspection and Maintenance ........................31 Disinfection and Cleaning ............................ 32 Troubleshooting ..............................32 Company Information ............................32 Manufacturing Site ............................... 33 Canis014D07 User Manual...
  • Page 8: Safety Precautions

    Be sure to disconnect the power cable by holding the plug or connector, not by pulling  the cable itself. CAUTION If you pull the cable too hard, the core wire may be damaged, resulting in fire or electric shock. Canis014D07 User Manual...
  • Page 9: Battery

    The image will not be clear if the equipment moves or there is a vibration during X-ray exposure. Do not handle the equipment with wet hands.  CAUTION Otherwise, it may result in electric shock that could result in death or serious injury. Canis014D07 User Manual...
  • Page 10: Failure Handling

    In an area prone to vibration Chemicals or gases are generated Where flammable materials are placed CAUTION Oxygen-rich environment Other than the specified storage environment The equipment can be used at an altitude of less than 3,000 meters.  Canis014D07 User Manual...
  • Page 11: Regulatory Information

    Portable X-ray System Model :Canis014D07 Power Input :Adapter Port Input 24V DC Battery Port Input 18V DC iRay Imaging Technology (Haining) Limited 20XX-XX-XX No. 2, Caohejing RD., Haining, Jiaxing, Zhejiang, China 314499 Contains FCC ID: 2ACHK-01070189 (01)0697056909XXXX (11)XXXXXXXX (21)XXXXXXXXXXXXXXXXXXX Canis014D07 User Manual...
  • Page 12 This symbol indicates that the product must be sent to the appropriate Product label facility for recycling when the end user intends to discard the product. Battery label This symbol represents a safety symbol that indicates "reference to user Product label manual". Canis014D07 User Manual...
  • Page 13: Safety Standards For Medical Equipment

    Collateral standard: General requirements for radiation protection in /EN 60601-1-3:2008 + A1:2013 diagnostic equipment. IEC 60601-1-6:2010 + Medical electrical equipment -- Part 1-6: General requirements for basic A1:2013/EN 60601-1-6:2010 + safety and essential performance -- Collateral standard: Usability A1:2013 Canis014D07 User Manual...
  • Page 14: Fcc

    Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/ TV technician for help.  Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment. Canis014D07 User Manual...
  • Page 15 0 mm between the unit and the human body. Carry this device at least 0 mm away from your body to ensure RF exposure level compliant or lower to the reported level. Canis014D07 User Manual...
  • Page 16: Product Introduction

    Product Introduction Overview Intended Use The Canis014D07 is a portable dental X-ray system for dental diagnosis in adult and pediatric patients and is available only to trained and qualified dentist or dental technician. Essential Performance According to the IEC 60601-2-65, the clause 201.4.3.101, there are 2 potential essential performance: Accuracy of loading factors;...
  • Page 17: Product Components

    1 pc. Default Power cord 1 pc. Default Battery 1 pc. Default Wrist strap 1 pc. Default Collimator Cone (200mm) 1 pc. Default Product Description ① DI-IN ⑧ Power button (ON/OFF) ② USB port ⑨ Product label Canis014D07 User Manual...
  • Page 18: Component Installation

    Free from a computer, Smart P is an independent dental DR system and could finish the whole workflow: Patient registration, image acquisition, image diagnostics.  Smart P+PC+iRay Sensor Smart P is an independent dental DR system, and need a PC for Mini PACS installation. Canis014D07 User Manual...
  • Page 19: Recommended Exposure Time

    Mandibular incisor 0.06~0.08 Mandibular canine 0.10~0.16 Mandibular bicuspids and first molar 0.10~0.25 Mandibular second and third molars 0.10~0.25 The exposure time set in each mode is recommended by the manufacturer, and each time can be adjusted. NOTE Canis014D07 User Manual...
  • Page 20: Technical Specifications

     Drawing ± ⌀  Specifications Item Specification Model Canis014D07 Application Intraoral X-Ray imaging Output kV 70KV±10% Output mA 2mA±20% X-ray tube anode angle 12° X-ray tube focal spot 0.4mm X-ray exposure time range 0.1~2sec HVG frequency 30kHz Canis014D07 User Manual...
  • Page 21 Android Exposure record Cumulative exposure time and times record  Environment Requirements Please confirm that the environment meets the basic requirements of Canis014D07 to ensure that it can be stored or operated in a reliable environment. Item Operation Storage & Transport...
  • Page 22: Adapter

    30%RH~75%RH 30%RH~75%RH Atmospheric pressure range (mbar) 700mbar~1060mbar 700mbar~1060mbar Adapter  Drawing 125.0±1.0 POWER LED 33.5±1.0  Specifications Item Specification Model LXCP61-024300 Input 100~240V AC input Output 24V single output mode, 72W Battery  Drawing +0.15 *53.6 -0.1 Canis014D07 User Manual...
  • Page 23 T≤45℃ 7.2C (18000mA); 45℃ T≤60℃ 4.0C (10000mA) < < Less than 1 month: -20℃ ~ +50℃ Less than 3 months: -20℃ ~ +40℃ Storage temperature Less than 1 year: -20℃ ~ +20℃ Relative humidity 65±20%RH Dimensions (L×W×H) 78.5×54×40mm Canis014D07 User Manual...
  • Page 24: User Interface

    The default user name is “admin” and the password is “123456”. Username and password can be changed in the setting page. The length of the user name must be no more than 60 characters, and NOTE the length of the password must be within 6~10 characters. Canis014D07 User Manual...
  • Page 25: Home Page

    Click this button to jump to the image acquisition Image acquisition button interface Click this button to jump to the image browse Image browse button interface Current logged-in username Status bar Navigation button includes “Back to login”, “Setting”, “About” and “Correct”. Canis014D07 User Manual...
  • Page 26: Patient Information Page

    Jump to the image acquisition page to examine the selected patient Back to Home page Image Acquisition Page The detailed functions of the buttons on this interface are described in the following table: Item Description Status Current logged-in username Canis014D07 User Manual...
  • Page 27 Jump to the image view page and view the teeth images that have been shot A prompt box will pop up, "Closing the detector, please wait a moment", and then return to the home page Canis014D07 User Manual...
  • Page 28: Image View Page

    Adjust the overall brightness and darkness of the image, the range is Adjust light/dark 1~50, the default value is 10 Adjust the high threshold of the image, the range is 0~5, the default High threshold value is 1 Canis014D07 User Manual...
  • Page 29: Setting Page

    This page is still under development Set the country code, account number, password, detector IP of the connected sensor Select the applied connection mode, such as demo mode, independent mode, intelligent filming mode, etc.  Administrator’s Functions Button Sub Button Figure Description Canis014D07 User Manual...
  • Page 30 Exposure process: 60KV 2MA 2s repeated 10 times with 15s interval; 70KV repeated 10 times with 15s interval Canis014D07 User Manual...
  • Page 31 Among them, when isMartket is set to false, the time interval of two exposures is 30 times, and when it is set to true, the time interval of two exposures is 7 times. The relevant configuration file page is shown in the figure below Canis014D07 User Manual...
  • Page 32 User Interface Canis014D07 User Manual...
  • Page 33: Service Information

    Check if all visible labels are intact and legible. Monthly Battery Check the battery life and check whether the battery is swollen Yearly The enssential performance of the equipment should be tested by Enssential performance Yearly the local third-party organization. Canis014D07 User Manual...
  • Page 34: Disinfection And Cleaning

    No. 2, Caohejing RD., Haining 314499, Jiaxing, Zhejiang, P.R.China Tel: +86-21-50720560 CS dept.: Customer service of iRay Imaging Technology (Haining) Limited CS dept. address: No. 2, Caohejing RD., Haining 314499, Jiaxing, Zhejiang, P.R.China CS tel: +86-21-50720560 CS fax: +86-4008266163-60610 Canis014D07 User Manual...
  • Page 35: Manufacturing Site

    Service Information CS email: service@iraygroup.com Website: www.iraygroup.com Factory Site Factory: iRay Imaging Technology (Haining) Limited Address: 3rd floor, Building 1, No. 2, Caohejing RD., Haining 314499, Jiaxing, Zhejiang, P.R.China Tel: +86-512-53690872 Canis014D07 User Manual...
  • Page 36 Maunfacturer: iRay Imaging Technology (Haining) Limited Address: No. 2, Caohejing RD., Haining 314499, Jiaxing, Zhejiang, P.R.China Tel: +86-512-53690872 Fax: +86-512-53690872 Website: www.iraygroup.com...
