OWNER'S MANUAL
AUTOMATED CEILING MOUNTED DRYING RACK
Patented system
Made in Portugal
BUNGY
MODEL CDH1R-E
Thank you for purchasing a BUNGY drying rack.
Now the ease of drying clothes in a convenient
and environmentally friendly way is at the dis-
tance of a simple assembly.
Before starting the installation of your drying
rack please read this entire manual.
If you have difficulties please contact one of our
installers who can do the assembly for you.
bungy.pt
facebook.com/bungy.pt
Advertisement
Related Manuals for BUNGY CDH1R-E
Summary of Contents for BUNGY CDH1R-E
- Page 1 OWNER’S MANUAL AUTOMATED CEILING MOUNTED DRYING RACK BUNGY MODEL CDH1R-E Thank you for purchasing a BUNGY drying rack. Now the ease of drying clothes in a convenient and environmentally friendly way is at the dis- tance of a simple assembly.
- Page 2 Screwdriver Drill bit 6mm and 8mm Drilling Set up Where to mount your BUNGY? On the roof, indoors, in a sheltered area, need- ing only a power point with live, neutral and earth. Free area of 130cm x 80cm. Should be taken into account the existence of any obstacle to the ascent and descent of the drying rack.
- Page 3 Wiring BUNGY Assemble the motor cover Place the motor cover and tighten the two screws. Connect BUNGY to power respecting the color code: Blue - neutral; Brown - live; Green and yellow - Earth WARNING: The gray and black conductors should not be used, must be isolated and can not be connected to electricity.
- Page 4 You will not need to do any reprogramming. Reprogramming of the limit switches Your BUNGY is pre-programmed with upper and lower Cancellation the lower and higher limit switched limit switches. - Press the "P" key three times. When necessary these setting can be changed using the...
