Page 1 MIL-BOOK 20 SERIES NOTEBOOK OPERATOR’ S MANUAL 22355 TAG Way, Dulles, VA 20166 Tel: (703) 406.3000 Fax: (703) 607.3853...
Page 3 TRADEMARKS All brand and product names are trademarks or registered trademarks of their respective companies. NOTE Information in this manual is subject to change without notice.
Page 4: Regulatory Information
Regulatory Information This appendix provides regulatory statements and safety notices on your computer. NOTE: Marking labels located on the exterior of your computer indicate the regulations that your model complies with. Please check the marking labels and refer to the corresponding statements in this appendix.
Page 5: On The Use Of The System
On the Use of the System Class B Regulations Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 6: Canadian Department Of Communications
Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
Page 7 ENGLISH CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufacturer's instructions. DEUTSCH VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ.
Page 8: About The Modem
About the Modem Caution 1. Never install telephone wiring during a lightning storm. 2. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. 3. Never touch non-insulated telephone wires or terminals unless the telephone line has been disconnected at the network interface.
Page 9: Usa And Canada Safety Requirements And Notices
IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
Page 10 20 cm (8 inches) from all persons and that the antenna must not be co-located or operating in conjunction with any other antenna or radio transmitter.
Page 11 EMC Requirements This device uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC). This device complies with the limits for a Class B digital device pursuant to Part 15 subpart C of the FCC Rules and Regulations.
Page 12: European Union Ce Marking And Compliance Notices
Canada Radio Frequency Interference Requirements To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing.
Page 13 Greek To προϊόν αυτό πληροί τις προβλέψεις της Ευρωπαϊκής Οδηγίας 1999/5/EC. Icelandic Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 1999/5/EC. Italian Questo prodotto è conforme alla Direttiva Europea 1999/5/EC. Norwegian Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 1999/5/EC.
Page 14 General European standards dictate maximum radiated transmit power of 100 mW Effective Isotropic Radiated Power (EIRP) and the frequency range 2400 – 2483.5 MHz. Belgium and the Netherlands In Belgium and the Netherlands, the product may not be used outdoors. See the instructions next under the heading “How to Turn Off the Wireless LAN Radio.”...
Page 15 Departments in Which the Wireless LAN Module’s Maximum EIRP Not Shown in the Previous Table Frequency Ranges (MHz) 2400 – 2446.5 10 mW 2446.5 – 2483.5 100 mW Turning Off the Wireless LAN Radio NOTE: Turning the wireless LAN radio off is not the same as disabling the wireless LAN card.
Page 16: Table Of Contents
Table of Contents Preface ... XiX Chapter 1 Getting Started ... 1-1 Getting the Computer Running...1-2 Unpacking ...1-2 Before You Begin ...1-3 Connecting to AC Power ...1-4 Positioning the Tablet PC...1-5 Using the Wireless Keyboard (option)...1-6 Turning On and Off the Computer...1-7 Taking a Look at the Computer ...1-9 Right-side Components ...1-9 Left-side Components ...1-11...
Page 17 Mouse-control Buttons...2-4 Typewriter Keys...2-5 Cursor-control Keys...2-5 Numeric Keypad ...2-6 Euro Symbol ...2-6 Windows Keys ...2-7 Function Keys ...2-7 Using the Touchscreen ...2-8 Configuring the Touchscreen...2-9 Using the Floppy Disk Drive (option) ...2-10 Connecting the Floppy Disk Drive ...2-10 Inserting and Ejecting Floppy Disks...2-12 Using the Hard Disk Drive ...2-14 Using the Optical Drive (option) ...2-15 Connecting the Optical Drive ...2-16...
Page 18 Power-Saving Tips...3-10 Chapter 4 Expanding Your Computer... 4-1 Connecting a Serial Device...4-2 Connecting a USB Device ...4-3 Connecting an IR Device ...4-5 Using PC Cards...4-7 CardBus Support ...4-7 Inserting and Removing a PC Card...4-7 System Memory Upgrade ...4-9 Chapter 5 Setup Configuration Utility (SCU)... 5-1 When and How to Use the SCU Program...5-2 When to Use...5-2 Starting SCU ...5-2...
Page 19 Location Guidelines ...7-3 General Guidelines...7-3 Cleaning Guidelines...7-4 Battery Pack Guidelines...7-4 When Traveling ...7-6 Chapter 8 Troubleshooting...8-1 Preliminary Checklist ...8-2 Solving Common Problems...8-3 Battery Problems...8-4 Optical Drive Problems...8-5 Display Problems ...8-5 Floppy Disk Drive Problems...8-7 Hardware Device Problems...8-7 Hard Disk Drive Problems...8-8 Infrared Problems...8-8 Keyboard and Mouse Problems ...8-9 LAN Problems ...8-9...
Page 20 xviii...
Page 21: Preface
Preface This manual contains information that will help you operate the computer. It is divided into 8 chapters and 2 appendices. Chapter 1, Getting Started, takes you through the process of setting up the computer and identifying its external components. Chapter 2, Operating Your Tablet PC, tells you how to use the computer’s components and features.
Page 22: Notational Conventions
Notational Conventions Throughout this manual, the following conventions are used to distinguish elements of text. NOTE: identifies additional information that requires special attention. CAUTION: identifies important information which, if not followed, may result in loss of data or damage to the computer. Keyboard keys are shown in a bold typeset.
Page 23: Chapter 1 Getting Started
Getting Started Congratulations on purchasing this Tablet PC. This hand-held computer, having no fan and being almost noiseless, is especially designed for the practical applications of warehouses, automobiles, vehicles, public security, repairing, assisting the handicapped, and other demanding situations where conventional notebook computers just cannot measure up.
Page 24: Getting The Computer Running
Getting the Computer Running This section guides you through the procedures for getting the computer ready for operation. Unpacking After unpacking the shipping carton, you should find these standard items: Tablet PC Accessories: − AC adapter (100~240 VAC, 50~60 Hz) −...
Page 25: Before You Begin
Inspect all the items. If any item is damaged or missing, notify your dealer immediately. Keep the shipping carton and packing materials in case you need to ship or store the computer in the future. Before You Begin To prevent depletion of the backup battery’s power during transit, a switch is provided at the bottom-side of the Tablet PC.
Page 26 NOTE: Power Supply Cord: (optional) Detachable, minimum 1.5 m long. Listed, rated minimum 125 V, 7 A, having a 2/18 AWG, type SVT flexible cord. One end terminates with a parallel blade, molded-on, attachments plug with a 7 A, 125 V (NEMA 1-15P) configuration;...
Page 27: Positioning The Tablet Pc
CAUTION: When you disconnect the AC adapter, disconnect from the electrical outlet first and then from the computer. A reverse procedure may damage the AC adapter or the computer. When unplugging the connector, always hold the plug head. Never pull on the cord. NOTE: When the AC adapter is connected, it also charges the battery pack.
Page 28: Using The Wireless Keyboard (Option)
Using the Wireless Keyboard (option) The wireless keyboard can either be placed flat on the table or inclined using its stand found at the back. To place the wireless keyboard in an inclined position, pull open the stand located at the back as shown on the next figure.
Page 29: Turning On And Off The Computer
Turning On and Off the Computer Turning On 1. Make sure the computer is connected to AC power. 2. Press the power button Getting Started...
Page 30 3. Each time the computer is turned on, it performs a Power-On Self Test (POST), and the operating system such as Windows should start. Turning Off To turn off the computer power, use the “Shut Down” command of your operating system. NOTE: There are other ways you can stop the computer so that you will be back to where you left off when you next turn on the computer.
Page 31: Taking A Look At The Computer
Taking a Look at the Computer This section identifies the external components of the computer and briefly describes the function of each component. Right-Side Components Component USB Port Connects a USB device, such as a USB floppy drive, printer, digital camera, joystick, and more. Microphone Connects an external microphone.
Page 32 Component Expansion Port For connecting to: Port Replicator, CD/DVD-RW/Combo drive module, or USB FDD module. Connects the AC adapter. Power Connector PC Card Slot Accepts a PC Card for additional functions. 1-10 Description See Also Getting Started P. 2-16, P. 1-4 P.
Page 33: Left-Side Components
Left-Side Components Component X-Bay Interface Connects additional wireless modem (GPRS/GSM), internal PCMCIA or four ports (COM 4, IEEE 1394, LAN, and USB 2.0). IR Port Connects an IrDA-compliant device for wireless data transfer. RJ-11 Connects the telephone line. Connector Getting Started Description See Also P.
Page 34: Rear Components
Rear Components Component System’s vertical angle of inclination after the Stand stand is released 18 ± 3 Supplies power to your computer when external Main Battery power is not connected. Pack Touchscreen Provides a convenient way to use the touchscreen. Can be stretched for better grip and handling.
Page 35: Front Components
Front Components Component LCD Panel and Displays the output of the computer. Also serves as your touchscreen. Touchscreen Turns the computer power ON and OFF. Also Power Button serves as the SUSPEND/RESUME switch. Allows you to toggle between adjusting the Volume Control/ sound volume of the computer or brightness of...
Page 36 Component Shows the speaker volume, the LCD brightness level,and the main battery capacity Suspend mode indicator (in reverse video) Hard disk drive in-use indicator Main battery status indicator Volume adjust indicator LCD brightness adjust indicator Speaker The upper button provides you a quick way to Volume/LCD increase while the lower button decreases the sound volume of the computer or brightness of...
Page 37: Bottom-Side Components
Bottom-Side Components Component Description See Also CCD Port Connects a CCD PC camera. P. 4-3 Getting Started 1-15...
Page 38: Where To Go From Here
Where to Go from Here As your computer is ready for operation, you may want to do any of the following now: For this purpose… To know more about the computer… To install the operating system if your dealer has not already done so… To know more about the operating system…...
Page 39: Chapter 2 Operating Your Tablet Pc
Operating Your Tablet PC This chapter provides information about the use of the computer. If you are new to computers, reading this chapter will help you learn the operating basics. If you are already a computer user but are new to Tablet PCs, you may choose to read only the parts containing information unique to your computer.
Page 40: Starting And Stopping The Computer
Starting and Stopping the Computer There are a number of ways to start and stop the computer. Starting the Computer You always start the computer using the power button A computer starts up with an operating system (OS) existing on the storage device such as the hard disk;...
Page 41 If you choose to stop in Standby or Suspend mode, you can return to where you left off the next time you start up the computer. (See “Power Management” in Chapter 3 for more information.) Operating Your Tablet PC...
Page 42: Using The Wireless Keyboard (Option)
Using the Wireless Keyboard (option) Before using the wireless keyboard, see section on “Positioning the Tablet PC and Wireless Keyboard” on chapter 1. Your wireless keyboard has all the standard functions of a full-sized computer keyboard. The standard functions of the keyboard can be further divided into five major categories: Mouse-control buttons Typewriter keys...
Page 43: Typewriter Keys
Typewriter Keys Typewriter keys are similar to the keys on a typewriter. Several keys are added such as the Ctrl Control key ( Ctrl ) is normally used in combination with other keys for program-specific functions. The Alternate key ( combination with other keys for program-specific functions.
Page 44: Numeric Keypad
Numeric Keypad A 15-key numeric keypad is embedded in the typewriter keys as shown next: Numeric keys facilitate entering of numbers and calculations. When Num Lock is on, the numeric keys are activated; meaning you can use these keys to enter numerals. NOTES: When the numeric keypad is activated and you need to type the English letter in the keypad area, you can turn Num Lock off.
Page 45: Windows Keys
Windows Keys The keyboard has two keys that perform Windows-specific functions: Windows Logo key and Windows Logo key opens the Start menu and performs software-specific functions when used in combination with other keys. Application key usually has the same effect as a right mouse click.
Page 46: Using The Touchscreen
Using the Touchscreen NOTE: To take advantage of the touchscreen feature, make sure that the touchscreen driver is correctly installed. CAUTION: Do not use a sharp object such as a ballpoint pen or pencil on the touchscreen. Doing so may damage the touchscreen surface. Use the included touchscreen pen instead, which can be stretched for better grip and handling.
Page 47: Configuring The Touchscreen
Term Point Move your finger or pen on the touchscreen until the cursor points to the selection on the screen. Click Tap gently anywhere on the touchscreen. Double-click Tap twice on the touchscreen rapidly. Drag and Press lightly on the touchscreen and move your finger or drop pen until you reach your destination (drag).
Page 48: Using The Floppy Disk Drive (Option)
Using the Floppy Disk Drive (option) Your Tablet PC comes with an USB floppy disk drive as drive A through the USB port on the right side, or port replicator on an optional expansion box, or through the USB port located on the plug of an optional optical drive module, or on the included private cable.
Page 49 Through the Expansion Port Plug of the Optical Drive Module – Insert the USB plug of floppy disk drive into the USB port located on the expansion port plug of the optical drive module. Operating Your Tablet PC 2-11...
Page 50: Inserting And Ejecting Floppy Disks
Through the Private Cable – Insert the USB plug of the floppy disk drive into the USB port located on the private cable. Inserting and Ejecting Floppy Disks To insert a floppy disk, hold it with the arrow facing up and towards the drive.
Page 51 CAUTION: Never turn off or reset the computer while the floppy disk drive in-use indicator is Always store your floppy disks in a safe, clean container, to protect them from the environment and magnetic fields. A floppy disk must be formatted before you can use it. (To know how to format a floppy disk, see your operating system manual.) Operating Your Tablet PC 2-13...
Page 52: Using The Hard Disk Drive
Using the Hard Disk Drive Your computer comes with a hard disk drive as drive C. A hard disk drive is a storage device with non-removable, rotating, magnetic storage platters inside it. It is where your operating system and application software programs are stored. Your hard disk drive is a 2.5-inch IDE (Integrated Drive Electronics) hard disk drive.
Page 53: Using The Optical Drive (Option)
Using the Optical Drive (option) Depending on the model, your computer comes with a CD/DVD-RW/ Combo drive module. This drive is usually configured as drive D and is connected to the expansion port located on the right side of the Tablet PC. The drive uses removable 5.25-inch silver discs, which look like standard music CDs.
Page 54: Connecting The Optical Drive
NOTE: For DVD-RW/Combo drive only. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
Page 55 2. Press the eject button and the CD tray will slide out partially. Gently pull on it until it is fully extended. 3. To insert a disc, place down the disc in the tray with its label facing up. Slightly press the center of the tray until it clicks into place. To remove a disc, hold the disc by its outer edge and lift it up from the tray.
Page 56: Using The Video Features
Using the Video Features The video subsystem of your computer features: 10.4-inch TFT (Thin-Film Transistor) 18-bit color LCD display with 1024 768 XGA (Extended Graphics Array) resolution. × Simultaneous display on LCD and external monitor, which is useful when you have a presentation as you can control the screen from your computer and face the audience at the same time.
Page 57 Display Mode Resolution Colors 8-bit × 16-bit 24-bit 32-bit 8-bit × 16-bit 24-bit 32-bit 8-bit × 16-bit 24-bit 32-bit 8-bit × 16-bit 24-bit 32-bit 1024 8-bit × 16-bit 24-bit 32-bit 1152 8-bit × 16-bit 24-bit 32-bit Operating Your Tablet PC LCD Only CRT Only Simultaneous Display √...
Page 58 1200 8-bit × 16-bit TABLE NOTE: 8-bit = 256 colors; 16-bit = High Color or 65,536 (64 K) colors; 24 and 32-bit = True Color 16,770,000 (16 M) colors. 2-20 LCD Only CRT Only Simultaneous Display √ √ √ √...
Page 59: Using The Audio Features
Using the Audio Features NOTES: To take advantage of the enhanced audio capabilities, the audio and volume control drivers supplied with your computer must be installed (see Chapter 6 for details). If you experience interference while recording, try lowering the microphone recording volume.
Page 60: Connecting Audio Devices
Ways of playing and recording sound vary with the operating system used. See your operating system documentation or online help for specific information. Connecting Audio Devices For higher audio quality, you can send or receive sound through external audio devices. Microphone Connector ( microphone for recording voice or sound.
Page 61: Using The Communication Features
Using the Communication Features Using the Modem NOTE: To take advantage of the modem feature, the device driver supplied with your computer must be installed. The internal 56 K fax/data modem allows you to use the telephone line to communicate with others by fax, email, or connect to an online service or bulletin board.
Page 62: Using The Wireless Lan
Using the Wireless LAN Depending on your model, an internal Mini PCI Wireless LAN (WLAN) card may have been pre-installed by your computer manufacturer at the factory. This card allows you to access corporate networks or the Internet in a wireless environment. The WLAN features include: 2.4 GHz DSSS (Direct Sequence Spread Spectrum) technology Peer-to-Peer (Ad-Hoc) and Access Point (Infrastructure) modes...
Page 63: Using The Wireless Modem
Turning Off/On the WLAN Radio NOTE: The FAA (Federal Aviation Agency) has deemed it unsafe to operate wireless devices in aircraft as this may interfere with flight safety. Remember to turn off wireless LAN when using your computer in the airplane. The Windows XP WLAN utility must be on for the WLAN function to work.
Page 64: Using The Gps
Your computer can send and receive data via a mobile network using the GSM protocol. To send or receive data over a GSM network, you must have an account with a service provider that supports GSM data services, and the service provider must enable the data features on your account.
Page 65 The Global Positioning System (GPS) is a worldwide radio-navigation system formed from a constellation of 24 satellites and their ground stations. GPS uses these "man-made stars" as reference points to calculate positions accurate to a matter of meters. In fact, with advanced forms of GPS you can make measurements to better than a centimeter! In a sense it is like giving every square meter on the planet a unique address.
Page 66: Chapter 3 Managing Power
Managing Power Your computer operates either on external AC power, car adapter, or internal battery power. This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way. The topics in this chapter include: What is an AC or car adapter How to charge the battery pack...
Page 67: Ac And Car Adapter
AC and Car Adapter CAUTION: The AC and car adapter is designed for use with your computer only. Connecting the AC adapter to another device can damage the adapter. The AC power cord supplied with your computer is for use in the country where you purchased your computer.
Page 68: Battery Pack
Battery Pack The battery pack is the internal power source for the computer. It is rechargeable using the AC or car adapter. The operating time of a fully charged battery pack depends on how you are using the computer. When your applications often access peripherals, you will experience a shorter operating time.
Page 69: Initializing The Battery Pack
To charge the battery pack, connect the AC adapter to the computer and an electrical outlet. The Battery Charge Indicator ( PC’s Device Indicators appears to indicate that charging is in progress. You are advised to keep the computer power off while the battery is being charged.
Page 70: Replacing The Main Battery Pack
By Operating System You can check the approximate battery level using the battery meter function of the operating system. To read the battery level in Windows, double-click the icon computer is using AC power.) By Gas Gauge The internal backup battery pack does not support the gas gauge display on the battery itself, but on the exterior side of the main battery pack (option) is a gas gauge for displaying the estimated battery charge.
Page 71 pack from your dealer and keep it with you in a fully charged state as a backup. To replace the battery pack, follow these steps: 1. Make sure the computer is not turned on or connected to AC power. However, the Tablet PC supports the battery hot-swap function, providing you the ability to replace the battery even during system 2.
Page 72: Battery Low Signals And Actions
Battery Low Signals and Actions Battery Low occurs when the battery has approximately 10% of its charge remaining. The computer gives warning beeps and the Battery Charge Indicator ( ) blinks to alert you to take actions. NOTE: You can set up your threshold and signals of Battery Low under Windows. Immediately save your data upon Battery Low.
Page 73: Power Management
Power Management Your computer supports ACPI (Advanced Configuration and Power Interface) for power management. The power management feature allows you to reduce the power consumption for energy saving. With an ACPI-compliant operating system such as Windows 2000 and Windows XP, power supply to different computer components is controlled on an as-needed basis.
Page 74: Hibernation
Hibernation NOTE: Make sure that the hibernation feature is enabled in the Hibernate tab of the Power Options Properties from the Control Panel in Windows XP. Hibernation is a very useful feature. People frequently open many applications when they use computers. It takes some time to get all these applications open and running, and normally they all have to be closed before the system can be turned off.
Page 75: Power-Saving Tips
Power-Saving Tips In addition to your computer’s automatic power management, you can do your part to maximize the battery’s operating time by following these suggestions. Do not disable Power Management. Decrease the LCD brightness to the lowest comfortable level. Disable the parallel and serial ports if no devices are connected to these ports.
Page 76: Chapter 4 Expanding Your Computer
Expanding Your Computer You can expand the capabilities of your computer by connecting other peripheral devices. When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter. This chapter gives guidelines on installing and using these devices: Serial device IR device USB device...
Page 77: Connecting A Serial Device
Connecting a Serial Device Your computer has a private port for connecting a serial device such as a serial mouse or modem through the private cable. Follow this procedure to connect a serial device: 1. Make sure the COM Ports item is set properly in the SCU program. (See “Advanced Menu”...
Page 78: Connecting A Usb Device
Connecting a USB Device Your computer has one USB port on the right side for connecting USB devices such as digital camera, scanner, printer, modem, or mouse; and one CCD USB port at the rear-side for connecting an optional CCD camera.
Page 79 Expanding Your Computer...
Page 80: Connecting An Ir Device
Connecting an IR Device Your computer has an IR (InfraRed) port for connecting an infrared- equipped device wirelessly such as a wireless keyboard/mouse, another computer, printer, or PDA (Personal Digital Assistant). The infrared feature supports these standards: For the front panel’s IR port IR keyboard/mouse that supports Forward FK34PUS002 (US language) specification For the left side’s IR port...
Page 81 When using the left side’s IR port: Place the transmitting device where its IR port faces the IR port of your computer within the effective range − within ±15-degrees vertical angle and within ±15-degrees horizontal angle at no greater than 0.8~1.0 meter distance. Place the receiving device where the IR port of the Tablet PC faces its IR port within the effective range −...
Page 82: Using Pc Cards
Using PC Cards Your computer has one PC card slot to accommodate one type II card. CardBus Support Your computer’s PC card slot supports the CardBus specifications. CardBus is the 32-bit version of PC card technology. It allows speeds of up to 133 Mbps at 33 MHz.
Page 83 3. When a new card is seated, the computer will detect it and try to install the appropriate driver. Follow the on-screen instruction to complete the process. To remove a PC card: 1. Double-click on the Safely Remove Hardware the Windows XP taskbar and the Safely Remove Hardware window appears on screen.
Page 84: System Memory Upgrade
System Memory Upgrade You can upgrade your computer by changing system memory to a maximum of 1 GB on the SO-DIMM slot. However, to avoid damage during the installation procedure, please ask your dealer for help. Expanding Your Computer...
Page 85: Chapter 5 Setup Configuration Utility (Scu)
CHAPTER Setup Configuration Utility (SCU) SCU is a program for configuring the BIOS (Basic Input/Output System) settings of the computer. BIOS is a layer of software, called firmware, that translates instructions from other layers of software into instructions that the computer hardware can understand.
Page 86: When And How To Use The Scu Program
When and How to Use the SCU Program When to Use You need to run the SCU program when: You see an error message on the screen requesting you to run Setup. You want to restore the factory default settings. You want to modify some specific settings according to the hardware.
Page 87: Moving Around And Making Selections
Moving Around and Making Selections A brief description of keyboard (if installed) usage is listed next: ←, → Selects a menu title. ↑, ↓ Selects an item or option. Enter 1) Brings up the sub-menu when an item with the arrow sign is selected.
Page 88: Main Menu
Main Menu The Main menu contains the basic configuration settings of the system. Date and Time Sets the system time (Hour, Minute, Second) and date (Year, Month, Day). Setup Configuration Utility (SCU)
Page 89: Usb Emulation
Internal Numlock Sets if the numeric keypad will function. A check mark (√) indicates enabled, while underline (_) indicates disabled. USB Emulation Sets if the system supports the USB port in DOS mode. A check mark (√) indicates enabled, while underline (_) indicates disabled. Setup Configuration Utility (SCU)
Page 90: Advanced Menu
Advanced Menu The Advanced menu contains the Input/Output (I/O) configuration settings of the system. Geyserville Support This item is only available if the CPU you are using supports the Intel® SpeedStep™ function. It allows maximum CPU performance when using AC/car power but minimum CPU performance when using battery power.
Page 91: Com Ports
NOTE: For Windows 2000, you need to install the SpeedStep driver to use this function (see Chapter 6 for details). Shared Video Memory Sets the shared memory size of the video controller. The available options are 4M, 8M, 16M, and 32M. NOTE: The shared video memory size of the video controller will depend on your system memory.
Page 92: Lpt Port
Allows you to assign COM1/COM2/COM3/COM4 to specific functions that you wish to use. In general, COM1/COM4 can be assigned to RS-232C (serial port), COM2 can be assigned to IR (InfraRed), while COM3 can be assigned to touchscreen. Select Disabled if you need the resources (3F8/IRQ4 of COM1, 2F8/IRQ3 of COM2, 3E8/IRQ5 of COM3, 2E8/IRQ11 of COM4) for other devices.
Page 93 HDD Heater Sets if the system automatically turns on the built-in hard disk drive heater for low temperature operation. A check mark (√) indicates enabled, while underline (_) indicates disabled. Function Key 1/2/3 Define (FN1/FN2/FN3) These three items allow user to define the corresponding function key associated with the three function buttons ( front panel.
Page 94 NOTE: The backlight switch function is supported only if your LCD is the transflective type (option). Power Button Define Allows you to set whether system power on/off would occur by just pressing the power button (when set at Power) or whether a combination of the speaker volume / LCD brightness down arrow key located on the front panel plus the power button (when set at on/off system power.
Page 95: Security Menu
Security Menu The Security menu contains the security setting that safeguards your system against unauthorized use. Set Password Allows you to set the password for your system. When typing the password, first make sure that in the entry fields and press again and pressing Enter is enabled, the set password is always required to boot the computer.
Page 96: Hard Disk Boot Sector
Hard Disk Boot Sector Helps prevent infection of computer viruses by protecting the hard disk boot sector (partition table) from changes. A check mark (√) indicates enabled, while underline (_) indicates disabled. CAUTION: Disable this item before installing an operating system, running Fdisk or Format program.
Page 97: Boot Menu
Boot Menu The Boot menu sets the sequence of the devices to be searched for the operating system. Boot Sequence Sets the first, second, third, and fourth boot device. The system will try to boot from the first device but if it is not available, will try the next boot device.
Page 98: Exit Menu
Exit Menu The Exit menu allows you to leave the SCU program. After finishing with your settings, you must save and exit so that the new settings can take effect. Save Changes and Exit saves the changes you have made and exits the SCU program.
Page 99 Discard Changes and Exit exits the SCU program without saving the changes you have made. Get Default Values loads factory default values for all the items. Setup Configuration Utility (SCU) 5-15...
Page 100 Load Previous Values restores previous values for all the items. 5-16 Setup Configuration Utility (SCU)
Page 101: Chapter 6 Installing Software Drivers
CHAPTER Installing Software Drivers To take full advantage of the unique features of your Tablet PC, some operating systems require custom software, known as drivers, to be installed. If you purchased the Tablet PC with Windows pre-installed, your dealer may have already installed the drivers. If not, you need to install the drivers using the CD supplied with your Tablet PC.
Page 102: How To Use The Cd
How to Use the CD NOTES: • The drivers may have been updated after this manual was published. For drivers upgrade, please contact your dealer. • You can always find the README or document files on the CD. These files contain the latest information from the software supplier.
Page 103 Just click the Device Driver link on the main screen. After installing the device drivers, proceed to the following: Touchscreen The touchscreen driver allows you to use your fingers as well as the touchscreen pen as a pointing device. Volume Control The volume control driver allows you to use the volume control buttons located on the front panel.
Page 104 Name Directory Audio driver \WinXP\audio\ or \Win2000\audio\ setup.exe Modem driver \WinXP\modem\ \Win2000\modem\ ptuninst.exe LAN driver \WinXP\LAN\ \Win2000\LAN\ prounstl.exe WLAN driver \WinXP\WLAN\ or (optional) \Win2000\WLAN\ Description Installs the audio driver that allows you to take full advantage of the audio subsystem. NOTE: The Windows Plug-and-Play capability may automatically detect the new device (Realtek AC'97 codec)
Page 105: Dos Mode Setting
Dos Mode Setting When connect CRT display, the CRT full screen disappear under the DOS mode, you can follow step as below: 1. Select right side corner ( 2. Select “Graphics Options” then click on the “Graphics Properties”. Installing Software Drivers ) icon then will appear next figure.
Page 106 3. Select “Device”, “Intel® Dual Display Clone” and check mark indicates enabled “Same display configuration driven on both displays”. Installing Software Drivers...
Page 107: Touchscreen Driver
Touchscreen Driver To install the touch screen driver; perform the following: 1. Insert the driver CD into the drive. 2. Click on “TOUCH SCREEN” and follow the onscreen instructions to continue. 3. When finished installing, select “Yes” to reboot your system. The diver should now be loaded.
Page 108: Touchscreen Calibration
Touch screen Calibration: 1. After the system has finished rebooting, click on the “Penmount monitor” icon located on the taskbar to bring up the “Penmount Control Panel”. 2. Select the “Standard Calibration” folder and click on “OK”. 3. If you need 4,9,16,25 dot of the calibrate, we suggest select “Advanced Calibration”...
Page 109: Intel Speedstep Utility
Intel SpeedStep Utility After installing the SpeedStep driver, you can now optimize the power consumption of the CPU. Click on “Start,” then “Programs,” then “Intel SpeedStep Utility.” The following screen appears as shown next: Make the necessary settings according to your system requirements. Installing Software Drivers...
Page 110: Wireless Lan Utility Installation
Wireless LAN Utility Installation Upon clicking on the PROSet link on the main screen, the Installation Wizard appears on screen. Upon clicking on “Next,” the following screen appears as shown next. After making your selection, follow the onscreen instructions to complete the wireless LAN utility installation.
Page 111: Chapter 7 Caring For The Tablet Pc
Caring for the Tablet PC Taking good care of your computer will ensure a trouble-free operation and reduce the risk of damage to your computer. This chapter gives you guidelines covering these areas of maintenance: How to protect the computer What to note when using and storing the computer How to clean the computer What to note when using the battery pack...
Page 112: Protecting The Computer
Protecting the Computer To safeguard the integrity of your computer data as well as the computer itself, you can protect the computer in several ways as described in this section. Using the Password The power-on password protects your computer against unauthorized use.
Page 113: Taking Care Of The Tablet Pc
Taking Care of the Tablet PC Location Guidelines Use the computer where the temperature is between 10 °C (50 °F) and 35 °C (95 °F). Avoid placing the computer in a location subject to high humidity, extreme temperatures, mechanical vibration, direct sunlight, or heavy dust.
Page 114: Cleaning Guidelines
Cleaning Guidelines Never clean the computer with its power on. Use a soft cloth moistened with water or a non-alkaline detergent to wipe the exterior of the computer. Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the display.
Page 115 If you will not be using the computer for a long period of time (more than two weeks), remove the Main battery pack from the computer and switch OFF Backup battery. If you remove the battery pack, make sure the battery terminals do not contact any conductors such as metal objects or water.
Page 116: When Traveling
When Traveling Before traveling with your computer, make a backup of your hard disk data into floppy disks or other storage devices. As an added precaution, bring along an extra copy of your important data. Make sure the battery pack is fully charged. Make sure the computer is turned off.
Page 117: Chapter 8 Troubleshooting
Troubleshooting Hardware, software, or a combination of both can cause computer problems. When you encounter any problem, it might be a typical problem that can easily be solved. This chapter tells you what actions to take when solving common computer problems. It is divided into three sections: Preliminary checklist Solving common problems Resetting the computer...
Page 118: Preliminary Checklist
Preliminary Checklist Here are helpful hints to follow before you take further actions when you encounter any problem: Try to isolate which part of the computer is causing the problem. Make sure that you turn on all peripheral devices before turning on the computer.
Page 119: Solving Common Problems
Solving Common Problems For easy reference, the problems are divided into these categories. Problem Type Battery problems Optical drive problems Display problems Floppy disk drive problems Hardware device problems Hard disk drive problems Infrared problems Keyboard and mouse problems LAN problems WLAN problems Modem problems PC card problems...
Page 120: Battery Problems
Battery Problems The battery does not charge (Battery Charge indicator does not appear). Make sure that the AC adapter is properly connected. Make sure that the battery is not too hot – gets above 45 or too cold – below 0 return to room temperature.
Page 121: Optical Drive Problems
The battery operating time indicated by the battery meter does not match the actual operating time. The actual operating time can be different from the estimated time, depending on how you are using the computer. If the actual operating time is much less than the estimated time, we recommend a full cycle of fully charging, discharging, and then charging as above.
Page 122 If the power button button firmly. If you are using battery power, make sure that it has a charge remaining and that it is installed correctly. During operation, the screen may automatically turn off as a result of power management. Press any key to see if the screen comes back. The brightness level might be too low.
Page 123: Floppy Disk Drive Problems
Resolution cannot be adjusted to desired setting. Make sure that the video driver is installed correctly. The external monitor displays nothing. Make sure that the monitor is turned on. Make sure that the monitor’s signal cable is properly connected. Simultaneous display does not work. Make sure that you turn on the external monitor before turning on the computer.
Page 124: Hardware Device Problems
Hardware Device Problems The computer does not recognize a newly installed device. The device may not be correctly configured in the SCU program. Run the SCU program to identify the new type. Make sure if any device driver needs to be installed. (Refer to the documentation that came with the device.) Make sure if the device needs any jumper or switch settings.
Page 125: Keyboard And Mouse Problems
Make sure that the device connected is using an equivalent speed. Make sure that the IrDA Fast Infrared Port is set to HP HSDL-2300/3600. Make sure that the IR port is set correctly in the SCU program. If you are printing to an infrared printer, make sure that the appropriate driver is installed.
Page 126: Lan Problems
The serial mouse does not work. Make sure that the mouse cable is properly connected. Make sure that you connect the mouse before booting the computer. LAN Problems I cannot access the network. Make sure that the LAN driver is correctly installed. Make sure that the LAN cable is properly connected to the RJ-45 connector and the network hub.
Page 127 Consult your dealer or an experienced radio technician for help. I cannot connect to another WLAN device. Make sure that the WLAN feature is turned on. Make sure that the SSID setting is the same for every WLAN device in the network. Your computer is not recognizing changes.
Page 128: Modem Problems
Modem Problems The modem does not work. Make sure that the modem driver is correctly installed. Make sure that the telephone line is properly connected. Make sure that the COM port in the communication software is correctly set. Turn off power management. PC Card Problems The PC card does not work.
Page 129: Printer Problems
The PC card stops communicating properly. The application may have been reset when the computer is turned off or in Standby mode. Exit and restart the application. Power Management Problems The computer does not enter Standby or Suspend mode automatically. If you have a connection to another computer, the computer does not enter Standby or Suspend mode if the connection is actively in use.
Page 130: Software Problems
Make sure that the printer driver is correctly installed. Make sure that you have assigned the printer port correctly in your operating system or application program. Make sure that the printer port is enabled in the SCU program. The printer prints garbled information. Make sure that the printer driver is correctly installed.
Page 131: Startup Problems
The sound system does not record. Adjust the playback or recording sound levels. The external microphone or audio device does not work. Make sure that the microphone is connected to the proper connector on the computer. Make sure that your computer is equipped with the driver needed. Click the speaker symbol on the taskbar and check the Windows volume control.
Page 132: Other Problems
If this message appears when you are booting from the hard disk, insert a bootable disk in the floppy disk drive and check the condition of the hard disk. The message “Invalid system disk” or “Disk error” appears on the screen after you turn on the computer.
Page 133: Resetting The Computer
Resetting the Computer You may have to reset (reboot) your computer on some occasions when an error occurs and the program you are using hangs up. If the system operation seems to hang up, first wait. It is possible that the system is processing data.
Page 134: Appendix A Specifications
Specifications NOTE: Specifications are subject to change without any prior notices. Parts Intel Pentium M processor LV, 1.1 GHz in µ-FCBGA package FSB (Front Side Bus) 400 MHz, thermal ceiling 12 W L2 Cache Memory 1 MB on-die ROM BIOS 512 KB Flash EEPROM (system and VGA BIOS), Plug-and-Play capability, ACPI 2.0 capability, boot from IDE devices / LAN / USB optical drive, Suspend-to DRAM/HDD support, PC2001-compliant...
Page 135 Environment Temperature Operating: 0 °C (32 °F) to 50 °C (122 °F) –20 °C (–4 °F) to 50 °C (122 °F) – option Storage: –40 °C (–40 °F) to 70 °C (158 °F) Humidity Operating: 5% to 95% RH, non-condensing...
Page 136 Regulatory Information This appendix provides regulatory statements and safety notices on your computer. NOTE: Marking labels located on the exterior of your computer indicate the regulations that your model complies with. Please check the marking labels and refer to the corresponding statements in this appendix.
Page 137 On the Use of the System Class B Regulations Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 138: Safety Notices
Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
Page 139 ENGLISH CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufacturer's instructions. DEUTSCH VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ.
Page 140 About the Modem Caution Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Never touch non-insulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines.
Page 141 IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
Page 142 20 cm (8 inches) from all persons and that the antenna must not be co-located or operating in conjunction with any other antenna or radio transmitter.
Page 143 EMC Requirements This device uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC). This device complies with the limits for a Class B digital device pursuant to Part 15 subpart C of the FCC Rules and Regulations.
Page 144 Canada Radio Frequency Interference Requirements To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit être utilisé...
Page 145 Greek To προϊόν αυτό πληροί τις προβλέψεις της Ευρωπαϊκής Οδηγίας 1999/5/EC. Icelandic Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 1999/5/EC. Italian Questo prodotto è conforme alla Direttiva Europea 1999/5/EC. Norwegian Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 1999/5/EC.
Page 146 General European standards dictate maximum radiated transmit power of 100 mW Effective Isotropic Radiated Power (EIRP) and the frequency range 2400 – 2483.5 MHz. Belgium and the Netherlands In Belgium and the Netherlands, the product may not be used outdoors. See the instructions next under the heading “How to Turn Off the Wireless LAN.”...
Page 147 Departments in Which the Wireless LAN Module’s Maximum EIRP Not Shown in the Previous Table Frequency Ranges (MHz) 2400 – 2446.5 2446.5 – 2483.5 Turning Off the Wireless LAN Radio NOTE: Turning the wireless LAN radio off is not the same as disabling the wireless LAN card.
