Related Manuals for Orava MT-330
Summary of Contents for Orava MT-330
- Page 1 MT-330 Instruction manual 0197 26.04.2019 rev.3.0 Infrared contactless digital thermometer...
-
Page 2: General Safety Instructions And Warnings
1. GENERAL SAFETY INSTRUCTIONS AND WARNINGS This document contains important safety instructions and precautions for the safe and proper operation and use of the “medical device - body temperature measurement “. Its compliance helps the user avoid risks, increase reliability and product life. 1.1 General safety instructions Read these operating instructions thoroughly before putting the device into operation. - Page 3 1.3 Safety instructions for power supply - batteries • The device is powered from its own internal source - from the battery. • The device operates with a safe low voltage. • Always store batteries out of reach of children. In case of battery swallowing, immediately seek medical advice.
-
Page 4: Before First Use
2. SPECIAL SAFETY INSTRUCTIONS AND WARNINGS • The device is designed exclusively for private, non-commercial use - body temperature measurement. Verification of accuracy of measurement is possible by comparison with another verified measuring device. Verification interval is recommended once every 2 years. •... - Page 5 Advantages of the thermometer Two measurement methods: measurement from ear and forehead 1. Thermometer measures body temperature (Body Temp mode) from ear and forehead. Depending on what you prefer, you can choose a place for temperature measurement. 2. The thermometer also measures the surface temperature of objects (Surface mode). High measurement accuracy with the latest measurement sensor technology the latest generation of measurement sensors guarantees a very high accuracy of temperature measurement when measured from ear and forehead.
-
Page 6: Part Description
Part description display infrared measuring sensor button v to display memory data upward switch on button button n for display backlight button V to display memory data downword button Mode Displey battery cover 1 mode of measurement (surface) 2 measuring Mode (body temp) 3 measured value 4 measurement memory 5 sound signal symbol... - Page 7 2 Before measuring, you must turn on the thermometer. Press the on/off button. Turning on the display, displaying all segments at a moment when the thermometer is switched on for the first time for a long time, the mode name and the temperature that is being measured are displayed (if the temperature sensor is in the body temperature mode and is not aimed at the human body, Lo (temperature below 32 °...
- Page 8 Body temperature measurement in the ear Measurement from ear You can measure from the right or left ear. The thermometer measures infrared radiation emitted from the drum and the ear canal. The sensor captures this radiation and converts it to its temperature. 1 Turn the thermometer on by briefly pressing the on/off button, and in the body temperature mode (Body temp), point the measuring sensor to the ear canal at a distance of max.
- Page 9 Measuring body temperature on forehead The thermometer measures infrared radiation emitted from the skin in the forehead and sleep area and surrounding tissue. Radiation captures sensors and converts them to temperature. 1 Turn on the thermometer by briefly pressing the on/off button in the body temperature measurement mode (Body temp), point the measuring sensor on the face at a distance of max.
-
Page 10: Setting The Thermometer
2 To start the measurement, press the on/off button and release it after a beep sounds. Measurement takes about one second. When the measurement stops, a beep sounds and a measurement result is displayed. After the measurement, the thermometer will be ready for further measurement. 3 If you do not perform any operation within 15 seconds, the thermometer will turn off automatically.. -
Page 11: Replace The Battery
Setting F3 (Turning on or off the beep/signal) Turn on the thermometer and press the MODE button for more than 3 seconds until F1 appears on the display. Then double-press the MODE button to enter the F3 setting. Pressing V turns off the sound, indicator 5 disappears. Press the V button to turn on the sound, indicator 5 appears on the display. -
Page 12: Cleaning And Maintenance
Cleaning and maintenance The measuring sensor is the most important and sensitive part of the thermometer. In order to guarantee the most accurate measurement results, the measuring head must always be clean and undamaged. Clean the head with the measuring sensor with a suitable cleaning cloth, a damp cloth, and a suitable alcohol solution (70% isopropyl). -
Page 13: Technical Specifications
Technical specifications Model: MT-330 Measuring range: Body temperature: 32.0 °C to 42.5 °C Surface Surface Temperature 0 C to 100 °C below the indicated range, “Lo” appears on the display and the display shows “Hi” Measurement accuracy: Body Temperature ± 0.3 C (at standard ambient temperature 22 °C) -
Page 14: Disposal Of Used Electrical And Electronic Equipment
Gongming, Guangming Shenzhen 518107, China Authorized representative for the EU: ALTHOME France SARL, 32390 Montestruc France, Francis Cadrens +33 562 622 323 Importer: ORAVA retail 1, a.s. ORAVA distribution CZ, s.r.o. Seberíniho 2 Ostravska 494 821 03 Bratislava 739 25 Sviadnov Slovenská republika Česká...
