Installer's Guide
OUTLINE DRAWING FOR AIR HANDLERS
ifD Air Cleaner
EFD175CLAH000E
EFD215CLAH000E
EFD235CLAH000E
EFD260CLAH000E
26
Dimensions
(all dimensions in inches)
2.8"
AIR HANDLER MODEL NUMBERS
A
17.5
21.5
23.5
26.0
Numbers in [brackets] are for 50 Hz international systems.
21" DEPTH CABINET
ADD DOOR DEPTH FOR TOTAL
Side View
21
18.88
B (multiple
piece cabinet)
14.9
18.9
20.9
23.4
7-7/16
1/8
Front
B
A
of
Cabinet
1/8
B (one piece
cabinet)
15
19
21
23.5
Pub. No. 18-HE122D1-1-EN
