Installer's Guide
ELECTRICAL CONNECTIONS FOR DUAL WHOLE HOUSE AIR CLEANERS
AND FURNACE IN CONVENTIONAL 24V MODE
FIELD SUPPLIED 50 VA TRANSFORMER
ELECTRICAL CONNECTIONS FOR DUAL WHOLE HOUSE AIR CLEANER AND
FURNACE IN COMMUNICATING MODE
FIELD SUPPLIED 75 VA TRANSFORMER
Pub. No. 18-HE122D1-1-EN
Numbers in [brackets] are for 50 Hz international systems.
17
