- Page 1 Professional Pistol Grip Grease Gun Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #75479 READ & SAVE THESE INSTRUCTIONS...
- Page 2 ® Thank you very much for choosing a Roughneck product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code (if applicable): ______________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Grease Gun ........................7 Assembly Instructions .......................... 7 Before Each Use ..........................10 Operating Instructions ........................ -
Page 4: Intended Use
Intended Use The Roughneck Professional Pistol Grip Grease Gun is used to grease fittings in automotive, fleet, industrial, farm, and construction fields. • 14-oz. capacity • Grease cartridge or bulk fill • Develops up to 5000 PSI • Delivers up to 1-oz./56 strokes •... - Page 5 ⚠WARNING PROP 65 • This product can expose you to chemicals including lead and phthalates, which is known to the State of California to cause cancer. For more information, go to www.p65warnings.ca.gov. ⚠WARNING WORK AREA SAFETY • Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury.
-
Page 6: Specific Operation Warnings
⚠CAUTION GREASE GUN USE AND CARE • Do not force the grease gun. Products are safer and do a better job when used in the manner for which they are designed. Plan your work and use the correct product for the job. •... -
Page 7: Main Parts Of Grease Gun
Main Parts of Grease Gun Subassembly Grease gun barrel (1) Grease gun head (2) Grease coupler (3) Flexible hose (4) Assembly Instructions Setting Up the Grease Gun Head (refer to Parts Diagram) Note: Use Teflon tape while connecting the flexible hose (19) to the grease gun head (13) and grease coupler (18) to the flexible hose (19). - Page 8 ⚠WARNING • Grease or empty cartridge in barrel is under pressure from the internal spring, be alert when removing head of the barrel. • Do not apply excessive torque or over-tighten the grease gun head as this will apply undue stress to the die cast outlet and may cause it to fracture.
- Page 9 2. Remove the grease gun head (13) from the grease gun barrel (1) by turning it counter clockwise. 3. Insert the open end of the cartridge into the grease gun barrel (1) and push it all the way in. 4. Remove the seal or pull the tab end from the cartridge. 5.
-
Page 10: Before Each Use
Removing Trapped Air After filling the grease gun, trapped air should be removed by following these steps: 1. After filling the grease gun barrel (1) with grease (using methods previously mentioned) and reassembling the gun, keep the barrel at least 2-3 turns open. 2. -
Page 11: After Each Use
After Each Use ⚠WARNING • After each use, store the gun in a safe, dry, and childproof location. Keep the gun clean and in good working order for best and safest performance. Maintenance ⚠WARNING • After each use, store the gun in a safe, dry and childproof location. Maintain the grease gun by adopting a program of conscientious repair and maintenance in accordance with the following recommended procedures. -
Page 12: Parts Diagram
Use the table below to troubleshoot problems before contacting service personnel or your local dealer. If the problem continues after troubleshooting, call your local dealer for assistance. Failure Possible Cause Corrective Action Barrel not completely tightened. Tighten the barrel completely. Remove air pocket by referring to “Removing Air pockets are trapped in trapped air”... -
Page 13: Replacement Parts
Reference Part Number Part Description Quantity Rivet O-ring Block nut Rivet Piston Grease gun head Steel ball Non-return spring Rubber washer Plunger handle Grease coupler Flexible hose Follower Replacement Parts • For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. •... -
Page 14: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Roughneck product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 15 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in India Page 15 of 15...
