16 VARIABLE SPEED SCROLL
"
SAW WITH FOOT PEDAL SWITCH
IMPORTANT:
For your own safety, read and follow all of the Safety
Guidelines and Operating Instructions before operating
this product.
Contact Us:
email: service@bucktool.com
https://www.bucktool.com
909-255-1088 (8AM-5PM PST)
GET IT DONE !
INSTRUCTION
MANUAL
Advertisement
Table of Contents
Related Manuals for Bucktool SSA16LVF
Summary of Contents for Bucktool SSA16LVF
- Page 1 GET IT DONE ! 16 VARIABLE SPEED SCROLL " SAW WITH FOOT PEDAL SWITCH Contact Us: email: service@bucktool.com https://www.bucktool.com 909-255-1088 (8AM-5PM PST) IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety MANUAL Guidelines and Operating Instructions before operating...
-
Page 2: Table Of Contents
SSA16LVF TABLE OF CONTENTS Specifications Safety guidelines Package contents Key parts diagram Assembly/Mounting Maintenance Troubleshooting Exploded view Parts list Warranty SPECIFICATIONS Input 120VAC, 60Hz , 1.2A No Load Speed 550-1,600 r/min(RPM) Table Size 16" x 9" Table tilting 0°- 45°... -
Page 3: Safety Guidelines
SSA16LVF SAFETY GUIDELINES - DEFINITIONS WARNING WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury. 1. READ AND UNDERSTAND the instruction manual before operating this machine. 2. DO NOT OPERATE THIS MACHINE until it is completely assembled and installed according to the instructions. - Page 4 SSA16LVF 21. NEVER BACK A BOUND BLADE OUT OF A KERF with the saw running. Turn the saw “OFF”, disconnect the saw from the power source, wedge the kerf and remove the blade. 22. USE CAUTION WHEN CUTTING IRREGULAR WORKPIECES. This type of workpiece can pinch the blade before the cut is complete.
- Page 5 SSA16LVF on how to work safely, properly and economically with your machine and how to avoid dangers, save repair costs, reduce downtime, and increase the reliability and working life of the machine. In addition to the safety regulations contained herein, you must in any case comply with the applicable regulations of your country with respect to the operation of the machine.
- Page 6 SSA16LVF • Use the right tool. Do not force small tools to do the job of a heavy-duty tool. Do not use tools for purposes not intended; for example do not use circular saws to cut tree limbs or logs.
- Page 7 SSA16LVF relevant safety rules. Repairs should only be carried out by a qualified person using original spare parts; otherwise this may result in considerable danger to the user. ELECTRICAL EXTENSION CORDS Use only 3-wire extension cords that have 3-prong grounding plugs and 3-pole receptacles that accept the product’s plug.When using a power product at a...
- Page 8 SSA16LVF WARNING Keep the extension cord clear of the working area. Position the cord so that it will not get caught on lumber, products or other obstructions while you are working you are working with a power product. Failure to do so can result in serious personal injury.
- Page 9 SSA16LVF for any damages resulting from unauthorized users are the sole responsibility of the operator. • The machine has been built using modern technology in accordance with recognized safety rules.Some remaining hazards, however, may still exist. • Long hair and loose clothing can be hazardous when the work piece is rotating.
- Page 10 SSA16LVF is equipped with an electric cord having an equipment grounding conductor and a grounding plug. The plug must be plugged into a matching outlet that is prop- erly installed and grounded in accordance with all local codes and ordinances.
-
Page 11: Package Contents
SSA16LVF Package contents No. Description Qty. Scroll saw Blade The Manual LED Light Assy Type I Hex Nut Philips Screw Lamp Holder Knob Foot Pedal Switch T Type Wrench(for pinless blade changing) -
Page 12: Key Parts Diagram
SSA16LVF No. Description Qty. Blade tension knob Bearing covers Work table Sawdust Blower Nozzle Side cover plate Bevel lock knob Dust connection port ON/OFF switch Variable speed control knob Mounting holes LED Light Assy Pressure Rod Locking Knob Foot pedal switch... -
Page 13: Assembly/Mounting
SSA16LVF The machine is designed to operate in closed rooms and must be placed stable on firm and levelled surface. The machine can be bolted down if required. For packing reasons the machine is not completely assembled. WARNING If you notice any transport damage while unpacking, notify your supplier immediately. - Page 14 SSA16LVF NOTE: Replace with batteries that have a rating of 1.5 volts (Number 7 series and AAA size or equivalent). When replacing the batteries, the battery guide should be thoroughly cleaned. Use a soft paintbrush or similar device, to remove all sawdust and debris.
- Page 15 SSA16LVF BEVEL CUTTING The table can be tilted between 0° and 45° for bevel cutting. Loosen the locking knob (1， in Fig11). Tilt the table to the left until the desired angle on the scale (2， in Fig11) has been reached.
- Page 16 SSA16LVF Using Foot Switch • Easy to operate – press the on/off switch side marked “ON”, power stays on as long as foot pressure is applied. • Keep both hands free to control your work at all times. • Turn machine on and off instantly simply.
- Page 17 SSA16LVF REMOVING SAW BLADE blade tension handle 1. Release the blade tension by lift up the blade tension handle. If necessary, turn the handle counterclockwise to loosen the blade holder further. Fig. 6 2. Unscrew the inner hex nut of upper blade holder by TURN CLOCKWISE.
- Page 18 SSA16LVF INSTALLING THE BLADE NOTE: Install the blade with the teeth pointing downward. 1.Install the blade on the blade holders. For Pinned Blade: Hook the blade pins in the recess of the lower blade holder. While pushing down on the upper blade holder, insert the blade pins into the recess of the upper blade holder.
-
Page 19: Maintenance
SSA16LVF General notes: Maintenance, cleaning and repair work may only be carried out after the machine is protected against accidental starting by pulling the mains plug. Repair and maintenance work on the electrical system may only be carried out by a qualified electrician. -
Page 20: Troubleshooting
SSA16LVF TROUBLE SHOOTING WARNING In the interests of operational safety, always switch off the saw and remove the mains plug before carrying out maintenance work. SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION Tension incorrectly set Set the correct tension Feed the work piece more... -
Page 21: Exploded View
SSA16LVF... -
Page 22: Parts List
SSA16LVF Description Size Qty. ID Description Size Qty. Philips Screw M5X8 Clip Seat Flat Washer Lock Washer Side Cover Hex Screw M4X20 Hex Nut Stand Cushion Spring Washer Blade Pin Type Base Hex Screw M5X25 Oil Cap Big Cushion Left Stand... - Page 23 SSA16LVF Description Qty. Size Pointer Miter Gauge Work Table Blade Knob ST Screw ST4.2X9.5 Hex Screw M6X30 Philips Screw M4X8 Hex Socket Screw M8X8 Eccentric Wheel DC Motor Switch Box Cord Clip Philips Screw M4X10 Variable Switch Circuit Board Table Tilt Lock Knob...
-
Page 24: Warranty
TUCKTOOL GET IT DONE ! TWO-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product Email : service@bucktool.com https://www.bucktool.com 909-255-1088 (8AM-5PM PST) https://www.bucktool.com...
