- Page 1 Nexsan E48 and Nexsan E60 Storage Systems FRU Removal and Replacement Guide Part Number: P0450139, Rev. B NEXSAN | 1289 Anvilwood Avenue | Sunnyvale, CA | 94089 USA Printed Sunday, April 3, 2022 | www.nexsan.com...
- Page 2 , BEAST™, BEAST P™, BEAST Elite™, BEAST X™, Nexsan E60™, Nexsan E60V™, Nexsan E60VT™, Nexsan E60P™, Nexsan E60X™, Nexsan E48™, Nexsan E48V™, Nexsan E48P™, Nexsan E48VT™, Nexsan E48X™, Nexsan E32F™, Nexsan E32V™, Nexsan E32X™, Nexsan E18™, Nexsan E18P™, Nexsan E18F™, Nexsan E18V™, Nexsan E18X™, and the Nexsan logo are trademarks or registered trademarks of Nexsan.
-
Page 3: Table Of Contents
Materials Environment Chapter 2: Adding Modules Take proper ESD precautions Adding a second RAID Controller Adding disk drives Chapter 3: Replacing Modules Power Supply Units (PSUs) RAID Controllers Disk drives Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide www.nexsan.com... - Page 4 Contents Front drive drawer fans Rear drive drawer fan assembly Glossary Part Number: P0450139, Rev. B Nexsan BEAST™ and E-Series™ www.nexsan.com...
-
Page 5: About This Manual
About this manual This FRU removal and replacement guide provides detailed procedures for installing, removing, and replacing field-replaceable units (FRUs) in Nexsan E48 and Nexsan E60 and their variants . Note While Nexsan makes every effort to ensure the accuracy of technical documentation, screen images and procedures may change after publication. -
Page 6: Contacting Nexsan
Nexsan E-Series Multipathing Best Practices Guide Safety notices This guide covers the Nexsan E60 and Nexsan E48 Storage Systemss only. Refer to the relevant product manuals for information on other Nexsan Storage Systems or Storage Expansions and other Nexsan products mentioned in this guide. -
Page 7: Revision History
35º C (41º to 95º F), with operating relative humidity at 20 to 80%, non-condensing. The cordset specification for the Nexsan E60 and Nexsan E48 in North America is USA IEC C13 to IEC C14, rated 250V/10A. When applying power to the storage system, use ONLY the IEC power cords originally supplied with it. - Page 8 About this manual viii Part Number: P0450139, Rev. B Nexsan BEAST™ and E-Series™ www.nexsan.com...
-
Page 9: Chapter 1: Overview
Chapter 1: Overview Nexsan E48 and Nexsan E60 4U, rack-mountable Storage Systems can hold up to 48 or 60 SATA, SAS, or SSD data disks respectively. Nexsan E-Series base models use 3Gb/s SAS for internal communication between the RAID Controllers and hard disks. -
Page 10: Front Panel
Component Description Active Drive Each drawer can hold up to 16 (for Nexsan E48 Storage Systems) or 20 (for Drawers (3) Nexsan E60 Storage Systems) 3.5" disk drives, for a total of up to 48 or 60 drives in the enclosure. - Page 11 Nexsan High-Density Storage User Guide). Table 1-5: Other items Number Component Description Drawer Lock: Secures the drive drawer in place. When this lock is disengaged, the STAT LED turns amber. Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide www.nexsan.com...
-
Page 12: Rear Panel
Rear panel Rear panel Use this section as a legend for rear panel components. Figure 1-6: Nexsan E48 and Nexsan E60 rear panel (8Gb/s Fibre Channel connections shown) HOST HOST HOST HOST EXP 0 EXP 1 EXP 0 EXP 1... -
Page 13: Legend
(see Power Supply Units (PSUs) on page 30). Table 1-9: Other modules Number Component Description Interconnect Service Modules Can only be replaced by a fully-trained Service (ISMs) (3) Engineer. Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide www.nexsan.com... - Page 14 Description Power (2): 200–240VAC, 47–63Hz CAUTION: The cordset specification for the (for Nexsan E60 Storage Nexsan E48 and in North America is IEC Expansions) or 110–240VAC, 47– C13 to IEC C14 rated 250V/10A. When 63Hz (for Nexsan E48 Storage applying power to the system, use ONLY Expansions).
- Page 15 Nexsan Nexsan High-Density Storage User Guide. Expansion port LEDs For Nexsan E48 and Nexsan E60 controllers: There are two LEDs (L0 and L1), each indicating the connection status for an expansion port. Green indicates that the SAS cable is properly connected.
- Page 16 Rear panel Number Component Description Controller status LED (STAT) Indicates the status of the RAID Controller. For Nexsan E48V/VT and Nexsan E60V/VT controllers: Solid blue indicates that the controller is operating within specifications and that there is no user data in the cache.
- Page 17 RAID Controllers into Emergency mode (see the Nexsan Nexsan High-Density Storage User Guide). Emergency mode is indicated by the controller status LED alternating between blue and red (see LEDs on page 14). Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide www.nexsan.com...
-
Page 18: Host Port Options
Rear panel Host port options The RAID Controllers can be configured (with one or two optional Host Bus Adapter (HBA) cards) for one of four different host port options: 16Gb/s Fibre Channel, 8Gb/s Fibre Channel, 10Gb/s iSCSI (10GbE), or SAS-to-Host. Figure 1-13: Host port options Fibre Channel 10gb Ethernet, Optical... -
Page 19: Drawer Interior
Chapter 1: Overview Notes: The SAS-to-Host port option has no LEDs. For Nexsan E48/E48V and Nexsan E60/E60V Storage Systems with two HBA cards, the right HBA card's LEDs are inverted. Drawer interior Use this section to understand Drawer interior components. Figure 1-14: Nexsan E60 drawer interior 1. -
Page 20: Physical Characteristics
For disk drive slots where no disk drive is installed, this LED is off. Physical characteristics Use this section as a reference for the physical characteristics of Nexsan Storage Systems or Nexsan Storage Expansions. Dimensions, Nexsan E48 Measurement Value Chassis height 4U: 177mm (6.97") Chassis length 835mm (32.87") -
Page 21: Dimensions, Nexsan E60
Nexsan E60 nominal input voltage is 200–240VAC, 47–63Hz. Cordset specification in North America is IEC C13 to IEC C14 rated 250V/10A. Nexsan E48 nominal input voltage is 110–240VAC, 47–63Hz. Cordset specification in North America is IEC C13 to IEC C14 rated 250V/10A. -
Page 22: Environment
Physical characteristics Environment Ambient operating temperature: 5°C–35°C (41°F–95°F) Minimum drawer operation temperature: 10°C (50°F) Part Number: P0450139, Rev. B Nexsan BEAST™ and E-Series™ www.nexsan.com... -
Page 23: Chapter 2: Adding Modules
Chapter 2: Adding Modules Nexsan E48 and Nexsan E60 Storage Systems are designed so that adding data disks can be performed while the system is powered on and operating normally. Also, a second RAID Controller can be added to single-Controller systems, but this requires the system to be powered down. -
Page 24: Take Proper Esd Precautions
Take proper ESD precautions Take proper ESD precautions CAUTION: Computer components and disk drives are sensitive to electrostatic discharge (ESD). Always ground any electrostatic charge from your person before touching components with your hands or with any tools. Always use an anti-static wrist strap (one ships with each storage system) while installing or performing maintenance on any Nexsan Storage System. -
Page 25: Adding A Second Raid Controller
It is possible to upgrade a single-Controller system to a dual-Controller system by installing a second RAID Controller module. This is necessary if you want to attach a Nexsan Storage Expansion to the Nexsan E48 or Nexsan E60 Storage System or if you want to use any of the system modes that enable failover (see System Mode in the Nexsan High-Density Storage User Guide for more information). -
Page 26: Adding Disk Drives
Adding disk drives 6. Make sure that the new RAID Controller is right-side up. The Host ports should be at the top. 7. Insert the RAID Controller into the slot and carefully slide it back until the spring lock tab clicks. Figure 2-3: Inserting the new RAID controller 8. - Page 27 CAUTION: Where possible, always load disk drives in rows of four across the width of the drive drawer. Leaving large gaps between disk drives decreases cooling efficiency and may result in some disk drives overheating. 5. Close the drive drawer lid. Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide www.nexsan.com...
- Page 28 Adding disk drives 6. Carefully slide the drawer back into the enclosure, making sure that it is flush with the rest of the front panel. 7. Turn the drawer lock clockwise to lock the drawer into place. The STAT LED on the front of the drawer turns from amber to green to let you know that the drive drawer is properly latched.
-
Page 29: Chapter 3: Replacing Modules
Chapter 3: Replacing Modules Nexsan E48 and Nexsan E60 Storage Systems are designed so that some components can be replaced without turning off the system or interrupting its functioning. This chapter describes how to replace each of these modules in the field while the unit is running. -
Page 30: Power Supply Units (Psus)
Power Supply Units (PSUs) Power Supply Units (PSUs) In the event of a power supply or PSU fan failure, replace the PSU using the following procedure. CAUTION: DO NOT REMOVE THE FAILED PSU until the new PSU has arrived and is ready to be installed. -
Page 31: Raid Controllers
Execute NOW. If you have a single-RAID Controller Nexsan Storage System or if you must replace both RAID Controllers in a dual-Controller Nexsan Storage System , navigate to System Admin > Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide... - Page 32 RAID Controllers Reboot in the graphical user interface (GUI), select System Shutdown, select the confirmation check box, and click Execute NOW. 3. Carefully note communication cable locations, then remove all cables from the failed RAID Controller. Note Cables should only be reconnected to the same ports from which they were removed in order to ensure proper communication between the Nexsan Storage System and connected hosts.
-
Page 33: Disk Drives
2. Turn the drawer lock counter-clockwise to unlock the drive drawer. Figure 3-5: Unlocking the drive drawer The STAT LED turns amber to let you know that the drive drawer is unlocked. Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide... - Page 34 Disk drives CAUTION: Only open ONE drawer at a time. Fully close and lock each drawer before opening another one. Failure to do so may overbalance the rack, causing equipment damage or injury to personnel. 3. Carefully slide the drawer all the way out. Figure 3-6: Sliding the drive drawer out CAUTION: Do not lean on or place any heavy object on an open drive drawer.
- Page 35 See Home Page in Chapter 3 of the Nexsan High-Density Storage User Guide for more information. Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide www.nexsan.com...
-
Page 36: Front Drive Drawer Fans
Front drive drawer fans Front drive drawer fans In the event of the failure of a front drive drawer fan, replace the drawer front assembly by using the following procedure: ► To replace the frond drive drawer fans: 1. Determine which drive drawer contains the failed fan by examining the ENV LEDs on the front of each drawer (see Front panel on page 10). - Page 37 12. In the Nexsan GUI, go to the Home page and verify that the status bar for the replacement fan assembly is green. See Home Page in Chapter 3 of theNexsan High-Density Storage User Guide for more information. Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide...
-
Page 38: Rear Drive Drawer Fan Assembly
Rear drive drawer fan assembly Rear drive drawer fan assembly In the event of the failure of a rear drive drawer fan, replace the rear fan assembly by using the following procedure: ► To replace the rear drive drawer fans: 1. - Page 39 8. In the Nexsan GUI, go to the Home page and verify that the status bar for the new fan assembly is green. See Home Page in Chapter 3 of theNexsan High-Density Storage User Guide for more information. Nexsan E48 and Nexsan E60 Nexsan FRU Removal and Replacement Guide...
- Page 40 Rear drive drawer fan assembly Part Number: P0450139, Rev. B Nexsan BEAST™ and E-Series™ www.nexsan.com...
- Page 41 An advanced, built-in cable management sys- tem allows cables to extend and retract with the active drawer for easy servicing. Nexsan Nexsan E48 and Nexsan E60 FRU Removal and Replacement Guide www.nexsan.com...
- Page 42 Glossary cache E-Series Reserved areas of memory that are used to The series of Nexsan Storage Systems that speed up instruction execution, data retrieval, includes the Nexsan E18, E48, and E60 Stor- and data updating. In Nexsan Storage Sys- age Systems (and their V, VT and P variants), tems, a memory unit in the RAID controller that the Nexsan E32V, the Nexsan E18X, E48X, temporarily holds user data.
- Page 43 See graphical user interface. hot-plug Gigabit. Approximately one billion To insert a new piece of hardware into a com- (1,000,000,000) bits. puterized system while the system is running. See also hot-swap. Nexsan Nexsan E48 and Nexsan E60 FRU Removal and Replacement Guide www.nexsan.com...
- Page 44 Glossary hot-swap To replace a failed or faulty component of a Light Emitting Diode. LEDs are used for indic- computerized system while the system is run- ator lights on the front and back of Nexsan Stor- ning. See also hot-plug. age Systems.
- Page 45 A type of rack mount that enables a device to be easily slid into and back out of a rack. Nexsan Nexsan E48 and Nexsan E60 FRU Removal and Replacement Guide www.nexsan.com...
- Page 46 Glossary municate with users and computers in other locations. Terabyte. Approximately one trillion (1,000,000,000,000) bytes. Used to describe the storage capacity of hard disk drives. A tera- byte is usually computed as 1012 (1,000,000,000,000) bytes, but can also be computed as 240 (1,099,511,627,776) bytes (often called a “binary terabyte”...
- Page 47 Nexsan —Sunnyvale, CA, USA Nexsan — European Head Office, UK 1289 Anvilwood Avenue Units 33–35 Parker Centre, Mansfield Road Sunnyvale, CA 94089 Derby, DE21 4SZ United States of America United Kingdom Worldwide Web site Contact www.nexsan.com https://helper.nexsansupport.com/contact E-Series/BEAST support: https://helper.nexsansupport.com/esr_support Copyright ©...
