- Page 1 Istruzioni di montaggio Just 3D telai legno massiccio e ricoperto e anta vetro Fitting and adjustment instructions Just 3D solid timber or cover frames and glass sash Montage und Verstellanleitung Just 3D Block oder Futterzarge und Glasflügel...
- Page 2 Einsetzen der Verstelleinheit in die Bandaufnahme. Befestigen mit den mitgelieferten Senkschrauben DIN 7991 - M6x12 Mill the frame using special SFS jig, in order to obtain the dimensions as shown. Position the support into the milled recess and fasten the 3 screws as shown. The length of fasteners required may vary dependent upon the application.
- Page 3 Einsetzen der Verstelleinheit in die Bandaufnahme. Befestigen mit den mitgelieferten Senkschrauben DIN 7991 - M6x12 Mill the frame using special SFS jig, in order to obtain the dimensions as shown. Position the reinforcement plate into the milled recess. Shim in accordance with the profile measurement .
- Page 4 Istruzioni di montaggio - Fitting instructions- Montageanleitung Svitare e togliere la vite . Importante: Svitare il grano con una chiave a brugola finchè tocca il coperchio. Sicherungsschraube loslösen und entfernen. Wichtig: Die angegebene Schraube solange mit dem Innensechskantschlüssel loslösen bis die Abdeckung erreicht wird. Unscrew and remove screw .
- Page 5 Fix the sash plate and the washer onto the sash with the assembled fixing points. Tighten the fixing point with the special SFS key AW 30 cod. 763931. Assemblare la porta con il telaio. Inserire la spina e avvitare il grano solo nel foro dell’anello superiore.
- Page 6 +/- 2,5mm: turn the screw clockwise to lift the door and counterclockwise to lower it. 3 - Horizontal adjustment +/- 2,5mm: turn the screw clockwise in order to increase the air gap and counterclockwise to decrease it. SFS intec S.r.l. Division Construction Via Castelfranco Veneto, 71 it.info@sfs.com IT-33170 Pordenone...
