Isotemp Laboratory Freezers
Freezer Models
13-986-223F/FA/FR, 13-986-223FHK/223FRHK/223FAHK
13-986-247F/FA/FR, 13-986-247FHK/247FRHK/247FAHK
13-986-274F/FA/FR, 13-986-274FHK/274FRHK/247FAHK
102999 • Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Isotemp 13-986-223F and is the answer not in the manual?

Questions and answers

Summary of Contents for Fisher Scientific Isotemp 13-986-223F

  • Page 1 Isotemp Laboratory Freezers Freezer Models 13-986-223F/FA/FR, 13-986-223FHK/223FRHK/223FAHK 13-986-247F/FA/FR, 13-986-247FHK/247FRHK/247FAHK 13-986-274F/FA/FR, 13-986-274FHK/274FRHK/247FAHK 102999 • Rev. A...
  • Page 2: Table Of Contents

    Table of Contents Safety Information ..............................3 Alert Signals..............................3 Unpacking ................................4 Visible Loss or Damage..........................4 Concealed Loss or Damage ........................4 Packing List ..............................4 Performance Characteristics ..........................5 Temperature Ranges ............................5 Temperature Stability ............................5 Electrical Requirements..........................5 Installation ................................6 Selecting a Location ............................6 Casters................................6 Leveling the Unit ............................6 Shelves ................................6 Shelf Installation ............................7...
  • Page 3: Safety Information

    Safety Information Your satisfaction and safety are important to Fisher Alert Signals Scientific and a complete understanding of this unit is necessary to attain these objectives. Warning As the ultimate user of this apparatus, it is your responsi- Warnings alert you to a possibility of bility to understand its proper function and operational personal injury.
  • Page 4: Unpacking

    Unpacking Save all packing material if apparatus is received dam- aged. This merchandise was carefully packed and thor- oughly inspected before leaving our factory. Responsibility for its safe delivery was assumed by the carrier upon acceptance of the shipment; therefore, claims for loss or damage sustained in transit must be made upon the carrier by the recipient as follows: Visible Loss or Damage...
  • Page 5: Performance Characteristics

    Performance Characteristics Temperature Ranges -30° to 0°C (-22° to 32°F) Temperature Stability ±4°C Electrical Requirements Catalog Number Volts (±10%) Amps 13-986-223F/FA/FR 10.0 13-986-247F/FA/FR 10.5 13-986-274F/FA/FR 16.0 13-986-223FHK/FRHK/FAHK 13-986-247FHK/FRHK/FAHK 13-986-274FHK/FRHK/FAHK...
  • Page 6: Installation

    Installation Selecting a Location Choose a location for the freezer that will provide at least three inches of clearance between the cabinet and any adjacent vertical surface at the sides and the rear. Appropriate electrical power must be available. Locate the freezer within six feet of the power outlet so that no extension cord is required.
  • Page 7: Shelves

    NSTALLATION Shelves Included are three (3) epoxy coated wire shelves per door opening. Also included are three epoxy coated filler shelves for the two and three door models. Shelf spacing is adjustable on half-inch centers with the enclosed shelf supports to suit requirements. Replacement shelves are available individually.
  • Page 8 NSTALLATION Insert four shelf supports into pilasters for each shelf. Shelf Support Tab Length Figure 2 Figure 3...
  • Page 9: Electrical Connection

    NSTALLATION Electrical Connection Caution The frequency and nominal voltage requirements for the Insufficient line voltage is often the unit are specified on the data plate, which is located on cause of compressor start-up failure, the interiors upper left side. Plug the unit into a power especially in 115V freezers.
  • Page 10: Operation

    Operation Begin operation by inserting the key into the key switch located on the header panel. The key switch is packed Warning inside the envelope, which is shipped in the freezer This product is NOT approved for stor- chamber. Turning the key switch to the ON ( | ) position age of flammable or explosive materi- will energize the compressor and condenser fans and the als.
  • Page 11: Setting The Temperature

    PERATION Setting the Temperature To change the set temperature, press and release the Menu keypad once. The display will flash SP and the Mode LED will be illuminated. The last set temperature will then be shown in the display. To change the tempera- ture, press the UP or DOWN arrow key.
  • Page 12: Hold-Off Time

    PERATION chamber temperature of -17°C and the system begins to control to the desired temperature of -15°C (as long as the 3 min. time delay has expired). Allow an additional 30 to 40 minutes for the freezer to again stabilize. If the display is still inaccurate, repeat the calibration offset procedure.
  • Page 13: Defrost System

    PERATION Defrost System Caution The defrost heaters are controlled by a defrost timer. The Changes to the defrost cycle are not timer is a 24 hr. dial timer located in the wire termination recommended and void the warranty. box behind the header panel. The timer is factory set to provide four defrost cycles per 24 hour period (at 6 and 12 pm and am).
  • Page 14: Troubleshooting

    Troubleshooting This table is intended to assist in resolving user-correctable freezer problems by relating symptoms to their likely causes. If service beyond the scope of this table is required, contact service at 1-800-438-4851. Symptom Probable Cause Action Does not run. Unit unplugged.
  • Page 15: Maintenance

    Maintenance Cabinet Cleaning Warning The exterior of the freezer cabinet should be cleaned with When servicing the unit, disconnect a solution of mild soap and water. Do not use caustic from the electrical power source. soap or abrasive cleaners since these may damage the cabinet finish.
  • Page 16: Replacement Parts

    Replacement Parts Replacements for Laboratory Freezer parts serviceable by the user may be ordered, by part number, from Fisher Scientific Co. at 1-800-438-4851. Item Part Number Freezer Replacement Shelf SPN13986210E Solid State Relay (K1) SPN88616 Temperature Controller W/Sensor SPN103508 (220V) International Version Control SPN105402 Front Shelf Support SPN103264...
  • Page 17: Wiring Diagrams

    Wiring Diagrams Catalog Numbers: 13-986-223F/FA/FR, 13-986-223FHK/223FRHK/223FAHK, 13-986-247FHK/247FRHK/247FAHK, 13-986-274FHK/FRHK/FAHK 115 VAC 60Hz, (domestic) 220VAC 50Hz (international) FREEZER LIGHT DOOR SWITCH Shown in door open position. PRPL EVAPORATOR DEFROST EVAPORATOR FAN CONTROL SWITCH 2 FAN(S) FACE HEATER(S) DEFROST TIMER DEFROST HEATER DEFROST CUT-OUT COIL SWITCH 1 DEFROST LIMIT...
  • Page 18 IRING IAGRAMS Catalog Numbers: 13-986-247F/FA/FR, 13-986-274F/FA/FR 230 VAC GRN/YEL DOOR SWITCH #1 FREEZER LIGHT DOOR SWITCH #2 (2-DOOR MODEL ONLY) PRPL EVAPORATOR DEFROST FAN CONTROL SWITCH 2 FAN(S) DOOR SWITCH #3 (3-DOOR MODEL ONLY) HEATER DEFROST TIMER DEFROST HEATER DEFROST CUT-OUT COIL SWITCH 1 DEFROST LIMIT...
  • Page 20: Warranty

    Warranty Laboratory instruments and equipment manufactured by Fisher Scientific Company L.L.C. – Laboratory Equipment Division (hereinafter called “the Company”) are warranted only as stated below. Subject to the exceptions and upon the conditions specified below, the Company agrees, at its election, to...
