- Page 1 User Manual EXT-H102UETH-HDBT HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 All Rights Reserved Version: EXT-H102UETH-HDBT_2021V1.0...
- Page 2 HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material ⚫...
-
Page 4: Table Of Contents
HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Packing List ....................... 2 1.3 Customer Service ....................2 2. Specification ....................... 3 3. Panel Description ......................5 3.1 Transmitter ...................... -
Page 5: Product Introduction
HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 1. Product Introduction Thanks for choosing the EXT-H102UETH-HDBT HDMI2.0b Extender set, which consists of a transmitter and a receiver. This set is utilizing the latest HDBaseT 3.0 technology. It can extend 4K or 1080p video to distance up to 100 meters (328 feet) over a single CAT6A solid core cable without any compression. -
Page 6: Packing List
HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 1.2 Packing List • 1x EXT-H102UETH-HDBT Transmitter • 1x EXT-H102UETH-HDBT Receiver • 1x DC power adapter with EU plug(24v1.25A) • 4x Mounting Ears with 4x Screws • 8x Plastic Cushions •... -
Page 7: Specification
HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 2. Specification Transmitter Receiver Video (1) HDMI IN (1) HDBT IN Input Input Connector (1) Type-A female HDMI 2.0b (1) RJ45 Input Resolution Up to 4K@60Hz 4:4:4 Up to 4K@60Hz 4:4:4 Output (1) HDBT OUT, (1) HDMI LOOP OUT (1) HDMI... - Page 8 HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 Control Part (4) DEVICE, (4) DEVICE, (1) HOST, (1) HOST, (1) USB Switch, (1) ARC Switch, (1) IR IN, (1) USB Switch, (1) IR OUT, (1) IR IN, (1) RS232, (1) IR OUT, (1) ETHERNET (1) RS232, (1) ETHERNET...
-
Page 9: Panel Description
HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 3. Panel Description 3.1 Transmitter Transmitter Front Panel ① POWER LED: Illuminates green when power is applied, or blinks when in firmware upgrade mode. ② LINK LED: Illuminates when there is a valid HDBaseT link between the transmitter and the receiver. - Page 10 HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 Transmitter Rear Panel HDBT OUT HDMI IN LOOPOUT ARC OUT AUDIO OUT ① ETHERNET: Used for Gigabit Ethernet extension together with the ETHERNET port of receiver. ② HDBT OUT: RJ45 port to connect the HDBT input port of receiver by CAT6A Ethernet cable.
-
Page 11: Receiver
HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 3.2 Receiver Receiver Front Panel ① POWER LED: Illuminates green when power is applied, or blinks when in firmware upgrade mode. ② LINK LED: Illuminates when there is a valid HDBaseT link between the transmitter and the receiver. - Page 12 HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 USB devices which are connected to type-A USB 2.0 ports of transmitter. Receiver Rear Panel HDBT IN HDMI OUT ARC IN ① ETHERNET: Used for Gigabit Ethernet extension together with the ETHERNET port of transmitter.
-
Page 13: System Connection
HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 4. System Connection The following diagram illustrates typical input and output connections that can be utilized with the HDMI2.0 Extender: 4.1 ARC System Connection 1) When ARC switch is selected to HDMI, and the TV supports ARC, the TV audio can be transmitted back to the transmitter via HDMI output port of receiver, and then it will be available on both the ARC OUT &... - Page 14 HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 3) When ARC switch is selected to PASS, the extender can pass the ARC signal and support CEC pass-through. If the amplifier can work with the TV for ARC function, the ARC audio can be transmitted back to the transmitter via HDMI output port of receiver, and then it will be available on both the ARC OUT &...
-
Page 15: Panel Drawing
HDMI 2.0 Extender over HDBaseT 3.0 with USB 2.0 5. Panel Drawing...
