- Page 1 User Manual EXT-H101L-HDBT Ultra-thin HDMI2 0 Extender 131ft/40m 4K UHD All Rights Reserved Version: EXT-H101L-HDBT_2019V1.0...
- Page 2 Ultra-thin HDMI2.0 Extender Statement Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated by December 2019.
- Page 3 Ultra-thin HDMI2.0 Extender Introduction The EXT-H101L-HDBT is an ultra-thin HDMI2.0 Extender consist of a transmitter and a receiver. It extends 1080p/4K HDMI signal over CAT5e/CAT6a cable up to 70m /40m (PoC) and enables IR and RS232 pass-through to control source or display device remotely. It also adapts a visually lossless video compression technology to ensure the HD lossless transmission of HDR and 4K@60Hz/4:4:4 over CAT5e/CAT6a cable.
- Page 4 Ultra-thin HDMI2.0 Extender Panel Description Transmitter Receiver Name Description CTRL: RS232 pass-through control mode. ① UPDATE A: Update Valens IC program, connect a PC to the RS232 port, and then double-click the update file (.bat). MODE Switcher UPDATE B: Update compression IC program, the upgrade ...
- Page 5 Ultra-thin HDMI2.0 Extender Specification Model Transmitter Receiver Spec Input HDMI IN HDBT IN Output HDBT OUT HDMI OUT Control Ports IR IN, IR OUT, RS232 IR IN, IR OUT, RS232 General Transmission Mode & Distance HDBaseT; 1080p ≤ 70m; 4K×2K ≤ 40m Resolution Up to 4K×2K@60Hz 4:4:4 Bandwidth...
