  • Page 1 TRC-8543 2022-06-30...

  • Page 2: Table Of Contents

    Connecting a CAN Bus to the TRC-8543........

  • Page 3: Overview

    Safety Guidelines for Hazardous Locations The TRC-8543 is suitable for use in hazardous locations; , and hazardous locations; and nonhazardous locations only. Follow these guidelines if you are installing the TRC-8543 in a potentially explosive environment. Not following these guidelines may result in serious injury or death.
  • Page 4 Internationally The TRC-8543 has been evaluated as equipment under DEMKO ATEX and is IECEx certified. Each TRC-8543 is marked and is suitable for use in Zone 2 hazardous locations, in ambient temperatures of -40 °C ≤ Ta ≤ 70 °C.

  • Page 5: Electromagnetic Compatibility Guidelines

    TRC-8543 Caution The system shall be mounted in an ATEX/IECEx-certified enclosure with a minimum ingress protection rating of at least IP54 as defined in IEC/EN 60079-15. Caution The enclosure must have a door or cover accessible only by the use of a tool.

  • Page 6: Mounting The Trc-8543

    (6.0 in.) from the chassis and do not mount more than six cables directly beneath the chassis. You can route and strain relieve the TRC-8543 similarly to ordinary cables. You also can panel mount it using its removable jackscrews, zip tie, or screw mount it. The screw mounting holes support #6 and M3 screws spaced 35.56 mm (1.400 in.)

  • Page 7: Wiring To The Trc-8543

    Figure 4. TRC-8543 Connections The TRC-8543 has one 9-pin male D-Sub connector that provides connections to a CAN bus. The TRC-8543 has pins for CAN_H and CAN_L, to which you connect the CAN bus signals. Connect these signals using twisted-pair cable.
  • Page 8 When tightening the D-Sub connector jackscrews, do not exceed the maximum jackscrew torque of 0.56 N · m (5.0 lb · in.). The TRC-8543 receives power from the NI-XNET host port, but also requires an external power supply of +9 V to +30 V to operate in Low-Speed/Fault-Tolerant mode.

  • Page 9: Can Bus Topology And Termination

    TRC-8543 Connector Signal Name CAN Bus Topology and Termination A CAN bus consists of two or more CAN nodes cabled together. The CAN_H and CAN_L pins of each node are connected to the main CAN bus cable through a short connection known as a “stub.”...

  • Page 10: Connecting A Can Bus To The Trc-8543

    Figure 6. CAN LS/FT Bus Topology and Termination Resistor Locations High-Speed/Flexible Data-Rate CAN You can connect the TRC-8543 port to any location on a CAN bus. The following figure shows one example of connecting the TRC-8543 directly to one CAN node.

  • Page 11: Low-Speed/Fault-Tolerant Can

    TRC-8543 High-Speed/Flexible Data-Rate CAN Table 5. ISO 11898 Specifications for Characteristics of a CAN_H and CAN_L Pair of Wires Characteristic Value Impedance 95 Ω min, 120 Ω nominal, 140 Ω max Length-related resistance 70 mΩ/m nominal Specific line delay 5 ns/m nominal Low-Speed/Fault-Tolerant CAN Table 3.

  • Page 12: Cable Lengths

    For existing overall network termination above 125 Ω, you should select the 1 kΩ termination option for your NI-XNET device. Onboard termination on the low-speed/fault-tolerant ports of the TRC-8543 is set through the NI-XNET software to either 1.11 kΩ or 4.99 kΩ.

  • Page 13: Number Of Can Nodes

    Fault-Tolerant CAN, up to 32 nodes may be connected to the bus. TRC-8543 Hardware Overview The TRC-8543 has one full-featured CAN port that is isolated from the host it is plugged into. Software can select between either an NXP TJA1043T High-Speed CAN transceiver or NXP TJA1055T Low-Speed/Fault-Tolerant CAN transceiver by controlling on-board relays.

  • Page 14: Inserting And Removing The Trc-8543

    The TRC-8543 connects to a host device with an active latching connector. To connect the TRC-8543 to a host device, push the connector assembly into the host receptacle until the internal latch snaps into position. The latch emits an audible click when engaged.

  • Page 15: Trc-8543 Specifications

    TX or RX) Hardware is running, and controller transitioned to Solid green Solid red bus off TRC-8543 Specifications The following specifications are typical for the range -40 °C to 70 °C unless otherwise noted. High-Speed/Flexible Data-Rate CAN Characteristics...
  • Page 16 440 mW typical (High-Speed active mode) 333 mW typical (Low-Speed/Fault-Tolerant active mode) Power consumption from 550 mW maximum (High-Speed active mode) TRC-8543 host 440 mW typical (High-Speed active mode) 310 mW maximum (Low-Speed/Fault-Tolerant active mode) 245 mW typical (Low-Speed/Fault-Tolerant active mode)
  • Page 17 Port-to-earth ground Continuous 60 V DC, Measurement Category I Note The TRC-8543 COM signals are not connected to the host port ground. Caution Do not connect the product to signals or use for measurements within Measurement Categories II, III, or IV.
  • Page 18 TRC-8543 surtensions de catégorie II, III ou IV pouvant présenter des surtensions transitoires supérieures à ce que le produit peut supporter. Le produit ne doit pas être raccordé à des circuits ayant une tension maximale supérieure à la tension de fonctionnement continu, par rapport à la terre ou à...
  • Page 19 TRC-8543 CSA 60079-0:2011, CSA 60079-15:2012 ■ Note For UL and other safety certifications, refer to the product label or Online Product Certification section. Hazardous Locations U.S. (UL) Canada (C-UL) Europe (DEMKO) Environmental Characteristics Refer to the manual for the host you are using for more information about meeting these specifications.
  • Page 20 30 g, 11 ms half sine; 50 g, 3 ms half sine; 18 shocks at 6 orientations Shock and Vibration To meet these specifications, you must securely mount your TRC-8543 and ensure all cables and connectors have proper strain relief.
  • Page 21 TRC-8543 Note In the United States (per FCC 47 CFR), Class A equipment is intended for use in commercial, light-industrial, and heavy-industrial locations. In Europe, Canada, Australia and New Zealand (per CISPR 11) Class A equipment is intended for use only in heavy-industrial locations.
  • Page 22 TRC-8543 regulations and directives with which NI complies, as well as other environmental information not included in this document. EU and UK Customers • Waste Electrical and Electronic Equipment (WEEE)—At the end of the product life cycle, all NI products must be disposed of according to local laws and regulations.
