Technical instruction
Manual for use and maintenance
ELECTRIC FAT FRYER
MODEL
FL15 – FL25 – FL15S – FL25S
73/23/CEE EN 60335-1 – EN 60835-2-37
These appliances comply with requirements of E.E.C
PRODANAS SOTIRIOS & CO
PROFESSIONAL ELECTRIC & GAS MACHINES FOR RESTAURANT – PATISSERIES – SNACK BAR
OFFICE – FACTORY :National Road Kilkis-Thessaloniki P.C 545 00 Tel. : ++30 23410 41991 Fax: ++30 23410 41539
P.O BOX 400 70, P.C : 564 04
www.north.gr
- e-mail : info@north.gr
1
Advertisement
Table of Contents
Related Manuals for North FL15
Summary of Contents for North FL15
- Page 1 Technical instruction Manual for use and maintenance ELECTRIC FAT FRYER MODEL FL15 – FL25 – FL15S – FL25S 73/23/CEE EN 60335-1 – EN 60835-2-37 These appliances comply with requirements of E.E.C PRODANAS SOTIRIOS & CO PROFESSIONAL ELECTRIC & GAS MACHINES FOR RESTAURANT – PATISSERIES – SNACK BAR OFFICE –...
-
Page 2: Main Components
General Characteristics 1. APPLIANCE DESCRIPTION The Present handbook is reported for models FL15 – FL25 – FL15S – FL25S. The appliance has the following • Digital Display (indicate Cook time – Temperature Tank – Temp. PCB) • Thermostatic Sensor • On/Off General Switch •... -
Page 3: General Warnings
GENERAL WARNINGS ECOLOGY AND ENVIRONMENT • All the materials of packing are compatible with the Before you install and place in operation environment. They can be stored without danger or be the appliance you carefully read the burn at an authorised incineration plant. present handbook that offers important information •... -
Page 4: Instructions For Installation
INSTRUCTIONS FOR INSTALLATION 1. INSTALLATION PLACE 3. ELECTRIC CONNECTION • The connection in the network of electric Install the appliance only in spaces with sufficient ventilation appliance be executed according to the 2. POSITIONING being in effect regulations • • Before you realise the connection you are Remove the appliance from the packing;... -
Page 5: Safety Device
7. TROUBLESHOOTING 4. SAFETY DEVICE The appliance it allocates the following safeties: Even at the regular use of appliance can present dysfunctions. 4.1 Safety fuse of protection placed on the control panel The heating elements does PCB. To replace them loosen the retainer cap and not activate or is inefficient replace the burned safety with other (benefit this price is Possible causes:... -
Page 6: Layout Of Main Components
9. LAYOUT OF MAIN COMPONENTS 10. INSTRUCTION FOR USE (Any work inside of appliance should is executed from trained installer authorised by the Before you place in operation the appliance it is necessary constructor) you read carefully the present handbook. Instruction contain constitute important source of information on the Removing the back side from appliance, you right and sure use of oven. - Page 7 10.5 STAND-BY COOKING CYCLE 10.1 TURN ON FRYER. Switch on general rocket switch in position «I» While cooking cycle is running you can pause At the display, you will notice one blinking dash. time by pressing the » button once. Press the red on button until you hear beep and The display start blinking and the time is in pause turn on the display with dashes.
-
Page 8: Run Programs
10.9 STORAGE TIME IN MEMORY PROGRAM 10.11 TEMPERATURE CHECKING While the appliance is in cooking cycle press the • «M» button on the display will be showed the Open the appliance (see chapter 4.1). • temperature of the heating elements for about 4 Push button «M»... -
Page 9: Cleaning And Maintenances
CLEANING AND MAINTENANCES In the end of each day you must clean the 11. ALARM AND DIAGNOSTIC MESSAGE appliance using the suitable products and The appliance forecasts the appearance of special following the directives of supplier. conditions: Don't wash the appliance with direct of water Irregular operation or damage.
