CrewPlex DR10-900 Quick Start Manual

SETUP
Attach the beltpack antenna. It is reverse threaded; screw
1.
counter-clockwise.
2. Connect a headset to the beltpack. Press firmly until it clicks
to make sure the headset connector is seated properly.
3. Power on. Press and hold the Power button for 2 seconds,
until the screen turns on.
4. Access the menu. Press and hold the Mode button for 3
seconds, until the screen changes to <Setting Mode>. Short-
press Mode to scroll through the settings, and then scroll
through setting options using Volume +/−. Press and hold
Mode to save your selections and exit the menu.
a. Select a Group. Select a group number from 00–51.
IMPORTANT: Beltpacks must have the same group
number to communicate.
b. Select an ID. Select a unique ID number.
• Repeater* Mode ID options: M, 01–08, S, or L.
• Roam Mode ID options: M, SM, 02–09, S, or L.
• Standard Mode ID options: M, 01–09, S, or L.
• One beltpack must always use the "M" ID and serve as
the master beltpack for proper system function. An "M"
indicator designates the master beltpack on its OLED.
(
For Roam Mode, one beltpack must use the "SM" ID as well.)
• Listen-only beltpacks must use the "L" ID. You may
duplicate ID "L" on multiple beltpacks.
• Shared beltpacks must use the "S" ID. You may
duplicate ID "S" on multiple beltpacks, but only one
shared beltpack may talk at a time.
• When using "S" IDs, the last full-duplex ID cannot be
used ("08" in Repeater mode and "09" in the Standard
or Roam).
c. Confirm beltpack's Security Code. All beltpacks must
use the same security code to work together as a
system.
*Repeater mode is the default setting. See the DR10-900 Manual for
information about modes.
OPERATION
• LED Modes - Blue (double blink) when logged in. Blue (single
blink) when logged out. Red when battery charging in
progress. (LED turns off when charging is complete.)
• Lock - To toggle between Lock and Unlock, press and hold
the Talk and Mode buttons simultaneously for 3 seconds. A
lock icon appears on the OLED when locked.
• Volume Up and Down - Use the + and − buttons to control
the headset volume. "Volume" and a stair-step indicator
display the beltpack's current volume setting on the OLED.
You will hear a beep in your connected headset volume is
changed. You will hear a different, higher-pitched beep when
maximum volume is reached.
• Talk - Use the Talk button to enable or disable talk for the
device. "TALK" appears on the OLED when enabled.
» Latch talking: A single, short press of the button.
» Momentary talking: Press and hold the button for 2
seconds or longer; talk will remain on until the button
is released.
» Shared users ("S" ID) utilize momentary talking. Only
one Shared user can talk at a time.
• Mode - Short-press the Mode button to toggle between the
channels enabled on the beltpack. Long-press the Mode
button to access the menu.
• Two-Way Push-to-Talk - If you have a two-way radio
connected to the master pack, you may use this button to
activate Talk for the two-way radio from any pack on the
system. See the DR10-900 Manual for more information about
connecting a two-way radio.
Multiple DR10 Systems
Each separate DR10 system should use the same Group and
Security Code for all beltpacks in that system. CrewPlex
recommends that systems operating in proximity to one
another set their Groups to be at least ten (10) values apart.
For example, if one system is using Group 03, another system
nearby should use Group 13.
Battery
• Battery life: Approx. 12 hours
• Charge time from empty: Approx. 3.5 hours (USB port
connection) or approx. 6.5 hours (drop-in charger)
• Charging LED on beltpack will illuminate red while charging
and will turn off when charging complete.
• Beltpack may be used while charging, but doing so may
lengthen charge time.
Menu Options
Aside from Group and User ID, the following settings are
adjustable from the beltpack menu.
Menu Setting Default
Side Tone Off
Mic Gain
Channel A On
Channel B* On
Security Code 0000
*Channel B not available in Roam Mode.
Recommended Settings by Headset
Recommended Setting
Headset Type
SmartBoom LITE and PRO
CrewPlex Hard Hat Headset
CrewPlex Hard Had LITE Headset
CrewPlex In-Ear Headset
Options
On, Off
1 1–8
On, Off
On, Off
Alpha-numeric
Mic Gain
1
6
4
7
