Lemco MLF-201 Manual

Dtv - headend 4 x dvb-s/s2/s2x to ip
Hide thumbs

Advertisement

Quick Links

Download this manual
DTV -
MLF-201
4 x DVB-S/S2/S2X to IP
www.lemco.gr
www.lemco.gr
© 2020 Lemco. All rights reserved.
Manual
Headend
v.1.1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MLF-201 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lemco MLF-201

Summary of Contents for Lemco MLF-201

  • Page 1 Manual v.1.1 DTV - Headend MLF-201 4 x DVB-S/S2/S2X to IP www.lemco.gr www.lemco.gr © 2020 Lemco. All rights reserved.

  • Page 2: Table Of Contents

    DTV - Headend | MLF-201 Manual Contents Important safety precautions information Introduction Installation Technical specifications Warranty Notes © 2020 Lemco. All rights reserved.

  • Page 3: Important Safety Precautions Information

    When installing the unit, make sure that an outlet is within easy reach. In case of malfunction, switch the unit off and unplug the power cord. When the unit is not in use for a long period of time, make sure that the mains cord is disconnected. © 2020 Lemco. All rights reserved.
  • Page 4 Contact the manufacturer’s technical support department. • Do not step on or place heavy objects on top of the unit. To avoid hardware damage, handle all buttons, con- nectors and switches gently. © 2020 Lemco. All rights reserved.

  • Page 5: Introduction

    (4) inputs and assign it to any of the four (4) IP outputs providing great flexibility. The embedded web server of the MLF-201 provides a very friendly user interface as well as the ability of remote or local control of the device via LAN.
  • Page 6 4 outputs providing great flexibility. 3.2.3- IP streaming The MLF-201 is able to make IP streaming of all programs coming from the 4x RF inputs using UDP or RTP protocol in multicast/unicast IP addresses. The max. output bitrate can be up to 480 Mpbs.
  • Page 7 DTV - Headend | MLF-201 Manual 3.3 - BLOCK DIAGRAM DVB-S/S2/S2X DVB-S/S2/S2X MLF-201 IP (up to 64SPTS/4 MPTS) DVB-S/S2/S2X DVB-S/S2/S2X © 2020 Lemco. All rights reserved.
  • Page 8 DTV - Headend | MLF-201 Manual 3.4 - Product drawing views 1. Reset button 2. Status LED 3. RF inputs 4. LAN control 5. IPTV streaming 6. Dual power supply inputs 7. Fan cooler © 2020 Lemco. All rights reserved.

  • Page 9: Installation

    4. INSTALLATION 4.1 - General The MLF-201 has a very friendly interface for programming and monitoring purposes. The user is able to gain access to the embedded webserver, by opening an Internet browser (e.g. Internet Explorer, Firefox or Chrome) and type the following static IP: 192.168.1.205.
  • Page 10 CPU temperature, system uptime and CI interface status as well as general status codes of the device for troubleshooting purposes. 4.2.2 - “Program list” page At “Program list” page (Figure No 2) the MLF-201 provides information of all programs that are currently being distributed via its four IP outputs. •...
  • Page 11 All icons are clickable providing the ability to the user to go directly to the setup page of all internal modules of the device. The grey icons mean that the current module is disabled. © 2020 Lemco. All rights reserved.
  • Page 12 5. Band – Select the appropriate SAT band (works only if IF frequency is selected as input method) 6. DiSEqC – Select DiSEqC A, B, C, D 7. PLS – Enter the PLS number of the stream © 2020 Lemco. All rights reserved.
  • Page 13 Moreover, in case PLS is needed the user is able to set the PLS from the available field. Tuner status For each input the MLF-201 provides several information such as tuner status (Locked/Unlocked), total bitrate, signal strength, quality etc. 4.2.5 - “TS configuration” page At the “TS configuration”...
  • Page 14 “Input page” processes. When the user selects one input, the device’s multiplexer does a real time analysis and depicts the program list from this specific input. For each program the MLF-201 provides the following information/options: •...
  • Page 15 Each program title has a small cross at the left which can be expanded if the user will click on it. During this procedure, all the available PIDs of this specific program are reveled (Figure No 7). In this case, the user is able to select/deselect which PID want to be outputted. • Figure No 7 © 2020 Lemco. All rights reserved.
  • Page 16 • Figure No 8 Caution! The number of programs that the MLF-201 is able to distribute depends on the resolution (SD, HD, 4K etc.), the compression (MPEG2, H.264 etc…) and in general from the total bitrate of each program. •...
  • Page 17 In Figure No 10 we have general settings of the IP streamer as follows: • IP address: This is the IP address of the streamer for ping purposes. • MAC address: This is the MAC address of the streamer © 2020 Lemco. All rights reserved.
  • Page 18 Figure No 11 In order to setup the IP address for each program there are four tabs one for each IP output of the MLF-201. By selecting e.g. the TS1 tab (Figure No 11) the user is able to setup the IP streamer for this specific output, following...
  • Page 19 Select the NIT version Global NIT Select the input source of Global NIT. In this case NIT will be the same for all outputs. LCN provider: Choose the appropriate LCN provider (EACEM, ITC, Nordig, APN) © 2020 Lemco. All rights reserved.
  • Page 20 Moreover, this section offers the ability to export / import a NIT table. • Figure No 13 For more information on how to create a custom NIT table please refer to “Lemco NIT creation guidelines.pdf” document in Lemco’s website. 4.2.10 - “SDT” page At this section (Figure 14), the user is able to create custom SDT table for each of the four outputs of the device.
  • Page 21 The user has the ability to select which kind of events to display as well as the device gives the opportunity to export these logs as follow: • Excel – All the program list is exported in .xlsx format • – All the program list is exported in .csv format © 2020 Lemco. All rights reserved.
  • Page 22 Primary DNS: Set the IP address of the primary DNS • Secondary DNS: Set the IP address of the secondary DNS • Port: Assign the control port • MAC address: Depicts the MAC address of the LAN control © 2020 Lemco. All rights reserved.
  • Page 23 At “Administration” section (Figure No 17) the user is able to change the default password of the webserver. • Figure No 17 Caution! • In case of factory default procedure, the username and password will be reset unless we select the check box “Keep username & password after applying factory defaults”. © 2020 Lemco. All rights reserved.
  • Page 24 In “Factory default” section (Figure No 19) the user is able to apply a factory default reset to the device and select if the event logs should be deleted or not. • Figure No 19 © 2020 Lemco. All rights reserved.
  • Page 25 At “Import/Export Config” section (Figure No 20) the user is able to do the following: • 1. Export: Save all the configuration is a specific file • 2. Import: Upload a previously save configuration file. • Figure No 20 © 2020 Lemco. All rights reserved.
  • Page 26 In “Firmware update” (Figure No 21) section the user is check if there is any new firmware for the device. In case of new firmware, the user is able to proceed with the firmware update procedure. Caution! For the above procedure a internet connection is mandatory. • Figure No 21 © 2020 Lemco. All rights reserved.
  • Page 27 In “Regional settings” (Figure No 22) section the user is able to select the NTP server in order for the device to receive the date and time as well as to set the time zone of his country and his region. • Figure No 22 © 2020 Lemco. All rights reserved.
  • Page 28 Manual 4.2.19 - “Info” page In “Info” (Figure No 23) section the user is able to see the serial No of the device as well as firmware and hardware versions. • Figure No 23 © 2020 Lemco. All rights reserved.

  • Page 29: Technical Specifications

    Symbol rate 1 - 45 MBaud (QPSK) 1 - 30 MBaud (8PSK) Roll off factor Από 0.05 to 0.35 (automatic) Code rate 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 8/10 (QPSK- automatic) 3/5, 2/3, 3/4, 5/6, 8/9, 9/10 (8PSK- automatic) © 2020 Lemco. All rights reserved.
  • Page 30 2 x +12VDC Power supply consumption 1.8A max. Operating Temperature 0 ºC to 40 ºC Storage Temperature -10 ºC to +70 ºC Humidity Up to 90% Dimensions 235 x 115 x 48 mm Weight 0.45 Kg © 2020 Lemco. All rights reserved.
  • Page 31 DTV - Headend | MLF-201 Manual 6. DIMENSIONS *dimensions in mm © 2020 Lemco. All rights reserved.

  • Page 32: Warranty

    Products covered by Lemco warranty policy are products solely produced by Lemco and labeled under the Lemco logo, as well as products sold by Lemco and labeled under the Lemco Addons logo. No third-party products or parts of products are covered by Lemco warranty policy. Lemco bears not responsibility for third party products sold along with Lemco products.
  • Page 33 [24] hours after the product has been delivered to Lemco. If the product is covered by warranty, Lemco will repair or replace it and send it back to customer within 15 working days from receiving the product (depending on product’s overall condition) at no repair costs to customer.

  • Page 34: Notes

    DTV - Headend | MLF-201 Manual 9. NOTES © 2020 Lemco. All rights reserved. © 2020 Lemco. All rights reserved.
