Lemco MLH-200 Manual

Hide thumbs Also See for MLH-200:

Advertisement

Quick Links

Download this manual
DTV -
MLH-200
2 x HDMI to IP
www.lemco.gr
www.lemco.gr
© 2020 Lemco. All rights reserved.
Manual
Headend
v.1.1
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the MLH-200 and is the answer not in the manual?

Questions and answers

Related Manuals for Lemco MLH-200

Summary of Contents for Lemco MLH-200

  • Page 1 Manual v.1.1 DTV - Headend MLH-200 2 x HDMI to IP www.lemco.gr www.lemco.gr © 2020 Lemco. All rights reserved.

  • Page 2: Table Of Contents

    DTV - Headend | MLH-200 Manual Contents Important safety precautions information Introduction Installation Technical specifications Warranty Notes © 2020 Lemco. All rights reserved.

  • Page 3: Important Safety Precautions Information

    When installing the unit, make sure that an outlet is within easy reach. In case of malfunction, switch the unit off and unplug the power cord. When the unit is not in use for a long period of time, make sure that the mains cord is disconnected. © 2020 Lemco. All rights reserved.
  • Page 4 Contact the manufacturer’s technical support department. • Do not step on or place heavy objects on top of the unit. To avoid hardware damage, handle all buttons, con- nectors and switches gently. © 2020 Lemco. All rights reserved.

  • Page 5: Introduction

    3. INSTRUCTIONS 3.1 - DESCRIPTION The MLH-200 is a very powerful, all-in-one mini headend device, able to receive up to two (2) HD signals and con- vert them in IPTV streaming using UDP/RTP protocols multicast/unicast. It supports “pool” technology, meaning that the user is able to select any program from any of the two (2) inputs and assign them to any of the two (2) IP outputs providing great flexibility.
  • Page 6 Manual 3.2.2 - “Pool” technology The MLH-200 supports “pool” technology, meaning that the user is able to select any TV or Radio program from any input and assign it to any of the two (2) outputs providing great flexibility. 3.2.3 - IP streaming The MLH-201 is able to make IP streaming of all programs coming from the two (2) x HD inputs using UDP or RTP protocol in multicast/unicast IP addresses.
  • Page 7 DTV - Headend | MLH-200 Manual 3.3 - BLOCK DIAGRAM HDMI MLH-200 IP (up to 64SPTS/4 MPTS) HDMI © 2020 Lemco. All rights reserved.
  • Page 8 DTV - Headend | MLH-200 Manual 3.4 – Product drawing views 1. HDMI inputs 2. Reset button 3. Status LED 4. LAN control 5. IPTV streaming 6. Dual power supply inputs 7. Fan cooler © 2020 Lemco. All rights reserved.

  • Page 9: Installation

    4. INSTALLATION 4.1 - General The MLH-200 has a very friendly interface for programming and monitoring purposes. The user is able to gain access to the embedded webserver, by opening an Internet browser (e.g. Internet Explorer, Firefox or Chrome) and type the following static IP: 192.168.1.205.
  • Page 10 • Excel – All the program list is exported in .xlsx format • CSV – All the program list is exported in .csv format • M3U – All the program list is exported in .m3u © 2020 Lemco. All rights reserved.
  • Page 11 All icons are clickable providing the ability to the user to go directly to the setup page of all internal modules of the device. The grey icons mean that the current module is disabled. © 2020 Lemco. All rights reserved.
  • Page 12 DTV - Headend | MLH-200 Manual Setup 4.2.4 “Input” page In the “Input page” (Figure No 4) the user is able to setup each HD input independently. • Figure No 4 © 2020 Lemco. All rights reserved.
  • Page 13 Once all settings are being written, the user must click the “Apply” button for the settings to be saved. Encoder status For each HD input the MLH-200 provides its current state e.g. if it is running or if it is in idle state. 4.2.5 - “Program Selection” page In the “Program Selection”...
  • Page 14 By doing the same process for each program, from all inputs the user is able to create the two (2) custom multiplexes in device’s output. Caution! The number of programs that the MLH-200 can distribute on its output depends on the video bitrate that the user selects for each program. •...
  • Page 15 In Figure No 8 we have general settings of the IP streamer as follows: • IP address: This is the IP address of the streamer for ping purposes. • MAC address: This is the MAC address of the streamer © 2020 Lemco. All rights reserved.
  • Page 16 Figure No 9 In order to setup the IP address for each program there are two tabs one for each IP output of the MLH-200. By selecting e.g. the TS1 tab (Figure No 9) the user is able to setup the IP streamer for this specific output, following...
  • Page 17 Select the NIT version Global NIT: Select the input source of Global NIT. In this case NIT will be the same for all outputs. LCN provider: Choose the appropriate LCN provider (EACEM, ITC, Nordig, APN) © 2020 Lemco. All rights reserved.
  • Page 18 The user has the ability to select which kind of events to display as well as the device gives the opportunity to export these logs as follow: • Excel – All the program list is exported in .xlsx format • – All the program list is exported in .csv format © 2020 Lemco. All rights reserved.
  • Page 19 Primary DNS: Set the IP address of the primary DNS • Secondary DNS: Set the IP address of the secondary DNS • Port: Assign the control port • MAC address: Depicts the MAC address of the LAN control © 2020 Lemco. All rights reserved.
  • Page 20 At “Administration” section (Figure No 13) the user is able to change the default password of the webserver. • Figure No 13 Caution! • In case of factory default procedure, the username and password will be reset unless we select the check box “Keep username & password after applying factory defaults”. © 2020 Lemco. All rights reserved.
  • Page 21 In “Factory default” section (Figure No 15) the user is able to apply a factory default reset to the device and select if the event logs should be deleted or not. • Figure No 15 © 2020 Lemco. All rights reserved.
  • Page 22 At “Import/Export Config” section (Figure No 16) the user is able to do the following: • 1. Export: Save all the configuration is a specific file • 2. Import: Upload a previously save configuration file. • Figure No 16 © 2020 Lemco. All rights reserved.
  • Page 23 In “Firmware update” (Figure No 17) section the user is check if there is any new firmware for the device. In case of new firmware the user is able to proceed with the firmware update procedure. Caution! For the above procedure a internet connection is mandatory. • Figure No 17 © 2020 Lemco. All rights reserved.
  • Page 24 In “Regional settings” (Figure No 18) section the user is able to select the NTP server in order for the device to receive the date and time as well as to set the time zone of his country and his region. • Figure No 18 © 2020 Lemco. All rights reserved.
  • Page 25 Manual 4.2.16 - “Info” page In “Info” (Figure No 19) section the user is able to see the serial No of the device as well as firmware and hardware versions. • Figure No 19 © 2020 Lemco. All rights reserved.

  • Page 26: Technical Specifications

    Protocol UDP / RTP (Multicast/Unicast) Speed 1Gbit (480 Mbps in IP only mode) IGMP support Yes, v2, v3 Type MPTS (up to 4 TS) SPTS (up to 4 HD programs) Max. Bitrate 480Mbps max. © 2020 Lemco. All rights reserved.
  • Page 27 2 x +12VDC Power supply consumption 2A max. Operating Temperature 0 ºC to 40 ºC Storage Temperature -10 ºC to +70 ºC Humidity Up to 90% Dimensions 235 x 115 x 48 mm Weight 0.45 Kg © 2020 Lemco. All rights reserved.
  • Page 28 DTV - Headend | MLH-200 Manual 6. DIMENSIONS *dimensions in mm © 2020 Lemco. All rights reserved.

  • Page 29: Warranty

    Products covered by Lemco warranty policy are products solely produced by Lemco and labeled under the Lemco logo, as well as products sold by Lemco and labeled under the Lemco Addons logo. No third-party products or parts of products are covered by Lemco warranty policy. Lemco bears not responsibility for third party products sold along with Lemco products.
  • Page 30 [24] hours after the product has been delivered to Lemco. If the product is covered by warranty, Lemco will repair or replace it and send it back to customer within 15 working days from receiving the product (depending on product’s overall condition) at no repair costs to customer.

  • Page 31: Notes

    DTV - Headend | MLH-200 Manual 9. NOTES © 2020 Lemco. All rights reserved.
  • Page 32 Address: Latheas 46, 13678, Acharnes, Greece Tel: +30 210 2811401, +30 210 2405237 - Fax: +30 210 2825755 Email: info@lemco.gr - Website: www.lemco.gr Follow us: facebook.com/Lemco twitter.com/lemco linkedin.com/company/lemco © 2020 Lemco. All rights reserved. © 2020 Lemco. All rights reserved.
