  • Page 1 USER MANUAL MODEL 2100 DLS PRODUCT LINE REDILEVEL 2100 DLS EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 2 Electrolab, Inc. reserves the right to revise this publication and to make changes from time to time in its content without the obligation to notify any person or organization of such revision or changes.

  • Page 3: Table Of Contents

    Enter High Level Electronic Shut Down (ESD mode) (version 3.15 and higher) ..........8 Exit High Level Electronic Shut Down (ESD mode) (version 3.15 and higher) ..........8 Configuration Request Commands ........................9 EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 4 Table 4. Warning Codes ..........................18 Table 5. Error Codes ............................18 Notes for advanced users ..........................18 Model 2100 DLS Specifications ........................18 Part Numbering System ..........................24 Contact Information ............................25 EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 5: Description

    5. Unscrew the round side cover from the sensor top housing and feed the signal cable through the cord grip on the side of the sensor top. Unplug the gray, 6-position connector from the internal fuse board. 6. Make sure power is off before proceeding. EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 6: Sensor Calibration Procedure - Setting The Initial Offset

    5. To program the level offset in the sensor using the HHC-1000, go to the “Set Points” menu and then to the “Level” menu. Press F2 in the “Level” menu to bring up the level offset screen. EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 7: Testing And Troubleshooting

    2. Lowercase characters represent data fields in the command and response streams. Further explanation of data field structure is provided as necessary with each command. 3. All commands are terminated with carriage return <cr>. EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 8: Data Request Commands

    (i.e., only one float is present or both floats are abutted). Note: The number of decimal places in a data field implies nothing about the accuracy of the data, i.e., levels are not accurate to 0.01 inches. EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 9: Report Level And Temperature Continuously (Factory Diagnostics)

    = unit number (from 00 to 31) nn = new unit number Note: Unit number 00 is not valid in Modbus RTU mode Response: UuuNOK Where uu = newly assigned unit number EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 10: Assign Unit Number To Sensor With The Corresponding Serial Number (Version 3.15 And Higher)

    Example of setting top level offset for Unit 00 to 2.25 inches - U00L1O2.25 UuuL[2|B]Oslll.ll Sets the bottom float offset. (Dual Float Sensor only) Example of setting bottom level offset for water interface to 1.75 inches - U00L2O1.75 Where uu = unit number EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 11: Set Temperature Offset

    The relay (which power cycles the sensor to reduce power consumption) is rated for 10,000,000 cycles. Set 4-20mA Minimum (4mA) Range UuuMINmm.mm Where uu = unit number mm.mm = level for 4mA output (Default is 00.00) Response: UuuMINOK EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 12: Set 4-20Ma Maximum (20Ma) Range

    ESD mode was successfully activated Exit High Level Electronic Shut Down (ESD mode) (version 3.15 and higher) UuuESDOFF Response: UuuESDOFFOK ESD mode exit successfully Note: UuuESDON0 also turns off ESD mode EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 13: Configuration Request Commands

    = distance between switches as integral tenths of an inch (e.g., 5 = 0.5 inches, 10 = 1 inches) Report Total Switches UuuS? Response: UuuSssss Where uu = unit number ssss = total number of switches in the sensor Report Receive to Transmit delay UuuR? Response: UuuRmmm EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 14: Report 4-20Ma Configuration

    If sensor works in normal operation parameters the message will be UuuSENSOR-OK Error, one or more of the following Error messages NO-SWITCH-CLOSED ONLY-ONE-GROUP-FOUND-ON-A-TWO-FLOAT-SYSTEM TOO-MANY-GROUPS-TO-RESOLVE-THE-LEVEL NO-FLOAT-CONFIGURED TRANSMIT-TO-PIC-PROCESSOR-FOR-LEVEL-FAILED RECEIVE-FROM-PIC-PROCESSOR-FOR-LEVEL-FAILED TRANSMIT-TO-PIC-PROCESSOR-FOR-TEMP-FAILED RECEIVE-FROM-PIC-PROCESSOR-FOR-TEMP-FAILED Warning, one or both of the following Warning messages: EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 15: Report The Level Error Setting (Version 3.09 And Higher)

    = 2 is set for 2x16 bit floating point mode (v3.14 and higher) Report Battery Voltage UuuBV? Response: UuuBVvv.vV Where uu = unit number vv.v = battery voltage in volts EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 16: Modbus Registry Map

    1000 bbls/in Unsigned Top level offset x 40117 Factory setting: 16 bit Signed 100: -9999 to 9999 Bottom level offset x 40118 Factory setting: 16 bit Signed 100: -9999 to 9999 EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 17 1= Sensor errors or (v3.15 and low battery higher) Read only Group 0 top 40137 16 bit Unsigned (v3.15 and higher) Group 0 bottom 40138 Read only 16 bit Unsigned (v3.15 and higher) EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 18 40142 16 bit Unsigned (v3.15 and higher) Group 3 top 40143 Read only 16 bit Unsigned (v3.15 and higher) Read only Group 3 bottom 40144 16 bit Unsigned (v3.15 and higher) EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 19 16 bit Unsigned integer or 32 bit floating point Read Only Temperature8 44004 4003 Temperature8 16 bit Unsigned integer or 32 bit floating point Read Only Battery 44005 4004 Battery Voltage (*100 for 16 Voltage bit) EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 20 5011 Read Water Volume(bottom level x K factor) Floating point lower two bytes Only (v3.14 and higher) Temperature1 45013 5012 Read (v3.14 and higher) Temperature1 Only Floating point upper two bytes EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 21 5032 Read Floating point upper two bytes (v3.14 and higher) (See Notes) Register (see Only Table 3) 45034 5033 Read Floating point lower two bytes (v3.14 and higher) (See Notes) Only EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 22: Notes For Advanced Users

    “2” for 2 x 16 bit floating point format. RediLevel 2100 DLS Specifications Measurement Length: Available from 2 to 16 feet in length Tubing Material: 18 gauge, 316L stainless steel Dimensions: .75” x 1.5” EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 23 Modbus RTU 32 bit floating point* Modbus RTU (2x 16 bit) for alternate 32 bit floating point** Serial data via ASCII *Note Modbus RTU available in version 3.13 and higher. **Available in version 3.14 and higher. EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 24 Four-wire communication - three twisted pair, (16-18 AWG) recommended Classification: Class I, Div. 1, Group D Hazardous Locations (when connected to an approved intrinsically safe barrier board) Certification: ANSI/UL-913 CAN/CSA C22.2, No. 157 EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 25 RediLevel 2100 DLS page 21 Figure 1. RediLevel™ 2100 DLS EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 26 RediLevel 2100 DLS page 22 Figure 2. DLS2100 Assembly Diagram EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
  • Page 27 RediLevel 2100 DLS page 23 Figure 3. DLS2100 Connection Diagram EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.

  • Page 28: Part Numbering System

    Measurements 1 is standard Up to 8 available Figure 4. RediLevel 2100 DLS Part Numbering System In addition to the information provided within the part number, other information is necessary when ordering: 1. Total Tube Length: Default is Measurement Length plus 18 inches.

  • Page 29: Contact Information

    RediLevel 2100 DLS page 25 Contact Information For further information or for assistance, please contact: Electrolab, Inc. 159 Enterprise Parkway Boerne, Texas 78006 Phone: (210) 824-5364 TF: (888) 301-2400 Email: InsideSales@electrolabcontrols.com www.electrolabcontrols.com EL 29306 © 2022 Electrolab, Inc. All Rights Reserved.
