- Page 1 FLAIL MOWER BE-EFGCXXXF OPERATIONS & PARTS MANUAL FOR MODELS: • BE-EFG95F • BE-EFGC155F • BE-EFGC105F • BE-EFGC165F • BE-EFGC125F • BE-EFGC175F • BE-EFGC145F • BE-EFGC200F PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
- Page 2 TABLE OF CONTENTS SAFETY PRODUCT SPECIFICATIONS OPERATION SERVICE & MAINTENANCE STORAGE TROUBLESHOOTING EXPLODED VIEWS & PARTS LISTS...
- Page 3 Remember, YOU are the key to safety. Good safety practices not only protect you but also the people around you. Make these practices a working part of your safety program. Be certain that EVERYONE operating this equipment is familiar with the recommended operating and maintenance procedures and follows all the safety precautions.
- Page 4 Never exceed the limits of a piece of machinery. If its ability to do a job, or to do so safely, is in question DON’T TRY IT. Clear working area of stones, branches or hidden obstacles that might be hooked or snagged, causing injury or damage.
- Page 5 Only use genuine parts for service and maintenance. A fire extinguisher and first aid kit should be kept readily accessible while performing maintenance on this equipment. Periodically tighten all bolts, nuts and screws and check that all pins are properly installed to ensure unit is in a safe condition.
- Page 6 SAFETY AWARENESS. The position of safety decals are shown in the illustration below. Good safety requires that you familiarize yourself with the various safety signs and increase your SAFETY AWARENESS. EFGC Model EFGCH Model BE-EFGCXXXF USER MANUAL...
- Page 7 SAFETY & MODEL DECALS (CONTINUED) BE-EFGxxxF EFG-125 Model No. Description/ Information Date Country of Origin Serial No. BE-EFGCXXXF USER MANUAL...
- Page 8 SAFETY & MODEL DECALS (CONTINUED) BE-EFGxxxF BE-EFGCXXXF USER MANUAL...
- Page 9 • Perfect for use after storms when debris is scattered throughout areas usually maintained with normal mowers • Multi-purpose machines for mulching foliage and sticks • Ideal for thick grass, sticks, undergrowth and light vine mulching • Vegetable & pasture topping • Roadside maintenance BE-EFGCXXXF USER MANUAL...
- Page 10 6. Check that the tractor PTO shaft turns freely and that the machine driving shaft can telescope easily. 7. Check the blades. Be sure they are not damaged or broken and swing freely in their mount. Repair or replace as required 8.
- Page 11 Use a straight edge to make sure the belt pulleys are in-line and run Adjust the drive belt tension. The correct belt tension is achieved when the belt can be deflected by the belt If mis-angled, call your dealer or service agent for technical suppor thickness about 10mm at the center point between the pulleys.
- Page 12 Ensure they are secured with lynch pin. Attach the top link to the top link bracket. Adjust the lower link sway chains to allow minimal lateral movement. Attach the PTO shaft to the tractor PTO ensuring it has been cut to the required length. BE-EFGCXXXF USER MANUAL...
- Page 13 Store them in an area protected from dust, moisture and other contaminants. Greasing • Use a hand-held grease gun for all greasing. • Wipe grease nipple with a clean cloth before greasing, to avoid injecting dirt and grit. • Replace broken nipples immediately. BE-EFGCXXXF USER MANUAL...
- Page 14 • Repair or replace the side skirts back to their original size and shape. Replace damaged or broken protective devices. The oil should be drained out and replaced after the first 50 hours of operation, then the oil should be changed every 250 hours, or at least once a year.
- Page 15 • Check and clean the universal joint, driving belt press roller or replace them if they are not in good condition. • Spread oil on all parts required. • Re-coat the parts rubbed and damaged for anti corrosion. • Store the machine in a dry, level area. BE-EFGCXXXF USER MANUAL...
- Page 16 Replace Broken flail. Broken flails. Flails can be replaced by a competent operator. Broken rotor support. In other cases, replacement must be done by specialized staff. Excessive vibration of the machine. Broken driving support shaft Replace rotor support with original parts.
- Page 17 (125Model) fender shaft EFGCM125 EF120.00.123 10-4 700970005 (135Model)fender shaft EFGCM135 EF130.00.123 10-5 700980005 (145Model) fender shaft EFGCM145 EF140.00.123 10-6 700990019 (155Model) fender shaft EFGCM155 EF150.00.123 10-7 701000005 (165Model) fender shaft EFGCM165 EF160.00.123 10-8 701010005 (175Model) fender shaft EFGCM175 EF170.00.123 BE-EFGCXXXF USER MANUAL...
- Page 18 Oil cup GB1152-M6 501030185 Bolt GB70.3-M8X25 801160004 Roller supporting EFG120.018 511040007 UC205 bearing EF100.00.012 36-1 801140008 (105Model)(L=1040) mud shield EFG100.024 36-2 801150008 (115Model)(L=1140) mud shield EFG110.024 36-3 801160030 (125Model)(L=1240) mud shield EFG120.024 36-4 801170008 (135Model)(L=1340) mud shield EFG130.024 BE-EFGCXXXF USER MANUAL...
- Page 19 (125Model) gearbox with shaft EFGC120.015 50-3 801240027 (135Model) gearbox with shaft EFGC130.015 (200/220/250Model) gearbox 50-4 802520119 EFGCH200.021A with shaft 506010037 Washer GB96.1-12 703400008 PTO cover FM120.00.199 702420030 Shaft cover EF100.00.177 506010036 Washer GB96.1-10 506030036 Spring washer GB93-10 BE-EFGCXXXF USER MANUAL...
- Page 20 (EFGCM200) gear box 10-1 801220004 EFGC100.018A (EFGC100-110) shaft cover 10-2 801240004 EFGC120.018A (EFGC120-170) shaft cover 10-3 801600032 EFGCH200.026A (EFGCHZ/M/H-200)(L=640) shaft cover 1 506030037 GB93-12 12 washer 505011445 GB70.1-M12X35 M12X35 bolt 705290211 CBW-00-011B Breath plug 516010003 ZBT32001.3-ZG3/8-19" ZG3/8"-19 tapered plug BE-EFGCXXXF USER MANUAL...
- Page 21 Blade shaft 140 801190010 EFG150.013A Blade shaft 150 801200010 EFG160.013A Blade shaft 160 801210010 EFG170.013A Blade shaft 170 503010740 DIN985-M16X1.5 M16X1.5 lock nut 701240008 EFGC120.103 Spacer bush 701240009 EFGC120.104 Y blade 501014730 EFGC120.200A M16X1.5X85 bolt 701240010 EFGC120.104A Hammer BE-EFGCXXXF USER MANUAL...
- Page 22 FB60X85X8 oil seal 1 511040009 UC208 Bearing seat 90208 2 802080080 EFG200.013A-G2 Blade shaft 200 802080085 EFG220.013A-G2 Blade shaft 220 503010740 DIN985-M16X1.5 M16X1.5 Lock Nut 701240008 EFGC120.103 Spacer bush 701240009 EFGC120.104 Y blade 501014730 EFGC120.200A M16X1.5X85 Bolt 701240010 EFGC120.104A Hammer BE-EFGCXXXF USER MANUAL...
- Page 23 JB4342-35 Check ring 511016411 GB297-30207 Tapered roller bearing 1 510020398 CFW-35X72X10 FB oil seal 701240025 EFGC120.132 Connecting sleeve 702480007 AG14.01.C07 leaf spring 702480006 AG14.01.C06 702480001 AG14.01.C01 output shaft gear EFGCMZ105-175 21(1) 702080001 AG14.01.C01-G2 output shaft gear EFGCMZ200-220 BE-EFGCXXXF USER MANUAL...
- Page 24 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-EFGCXXXF USER MANUAL...
