- Page 1 U S B T Y P E C H A R D W I R I N G K I T I N S T A L L A T I O N G U I D E Need Help? +44 (0)330 320 3030 RoadAngelGroup.com...
- Page 2 What’s in the box Negative 12-24VDC to 5VDC Regulator Positive 5V Type C USB Power Quick Guide...
- Page 3 Mini Fuse Low Profile - Fuse Tap Connector ATO Fuse - Fuse Tap Connector Mini Fuse - Fuse Tap Connector The Road Angel Hardwire Kit is designed for use with Road Angel products that require a USB Type C 5V connection.
- Page 4 Fitting instructions Fuse Box STEP 1 Locate the fuse box within your vehicle (usually within the lower dashboard, boot compartments or in the engine bay) which will have a detailed chart with the fuse layout or check your vehicles operating manual. STEP 2 Use the fuse box chart to pick a fuse which is associated with a function of the device you are using this hardwiring kit...
- Page 5 Fitting instructions Branch Diagram Hardwire Original Kit fuse vehicle fuse STEP 5 Ensure all excess cable is located out of the way to cause any obstruction to driver and passengers. Connect the USB connector into the device (see user manual of device for optimum installation position).
- Page 6 Disclaimer Road Angel Group has made every effort to ensure the information contained in this manual is accurate and reliable. However, the information is subject to change without notice. Road Angel Group assumes no responsibility for any damage or injury resulting from incorrect installation of electric devices or components.
- Page 7 Other products & accessories Scan below using your Smart phone camera.
- Page 8 Illustrations and manual contents are subject to change without notice. RoadAngelGroup.com Designed in the United Kingdom Designed and manufactured by Road Angel Group, DB House, Rani Drive, Nottingham, NG5 1RF UK IPI Road Angel Snooper Ltd Unit 3D North Point House, North Point Business Park...
