NO: S2DZ1605V0
2D Barcode Scanner
User Manual
Factory Default
Version
Strueture chart
Cable remove:
Paper clip socket
Interface
Insert paper clip into the socket and press to
remove device cable.
Interface
trigger
Press trigger to remove device cable.
Product Feature
(1).Brand new decoding chip to read various 1D
& 2D barcodes.
(2).Advanced technology which can read.
e-payment barcodes like Ali-pay,apple-pay etc.
(3).Easy to use ,plug and play.
(4).Strong case to withstand 1.5m drop to
concrete.
Basic Configuration
Interface
USB-HID
RS232
(default)
USB-COM
(1) USB-HID Mode: Factory default mode ,
automatically identify and install driver.
(2) RS232 Mode:Require special customized
RS232 cable and designated serial port APP
(Default parameters :Baud Rate 9600 Data
Bit:8bits Stop Bit :1bit Check Bit :None)
(3) USB-COM ,Required to install special
driver (Claim it from distributor).
Scan Mode
Manual
(default)
Continuous
Auto-sensing
Suffix Setting
CR
(default)
TAB
CR
& LF
None
Buzzer
ON
OFF
Eg , Add prefix "A"
Step 1, Scan above code to enter into "add prefix "
Step 2, Scan above code to add "prefix "
Step 3, Scan the numeric code correspond to "A" ,
the ASCII value of A in Hexadecimal is 4 1
Low
High
Refer to Appendix 1 & Appendix 2
Step 4,Scan "save" code to save(refer to
Appendix 1)
Keyboard Language
USA
(default)
Czech
Eg , Add suffix "A"
Step 1, Scan below code to enter into "add suffix "
Step 2, Scan below code to add "suffix"
Franch
German
Step 3, Scan the numeric code correspond to "A" ,
the ASCII value of A in Hexadecimal is "4" "1"
Refer to Appendix 1 & Appendix 2
Step 4, Scan "save" code to save(refer to
Appendix 1)
Spain
Italy
Turkey Q
Turkey F
Prefix Setting
Prefix
Add prefix
Suffix Setting
Add Suffix
Suffix
Image Reverse
Disable
Enable
