  • Page 1 COMPACTION RAMMER SRA 60 SRA 68 USER MANUAL Safety, Operation and Maintenance © 2015 Stanley Black & Decker, Inc. New Britain, CT 06053 U.S.A. 74914 2/2016 Ver 3...
  • Page 2: Declaration Of Conformity

    Disposizioni speciali: Misurazioni Representative in the Union: Patrick Vervier, Stanley Dubuis 17-19, rue Jules Berthonneau-BP 3406 41034 Blois Cedex, France. Vertreter in der Union/Représentant dans l’union/Representante en la Union/Rappresentante presso l’Unione Done at/Ort/Fait à/Dado en/Fatto a Stanley Hydraulic Tools, Milwaukie, Oregon USA...
  • Page 3: Table Of Contents

    REPAIRS AND / OR SERVICE TO THIS TOOL MUST ONLY BE DONE BY AN AUTHORIZED AND CERTIFIED DEALER. For the nearest authorized and certified dealer, call Stanley Hydraulic Tools at the number listed on the back of this manual and ask for a Customer Service Representative.
  • Page 4: Safety Symbols

    SAFETY SYMBOLS Safety symbols and signal words, as shown below, are used to emphasize all operator, maintenance and repair ac- tions which, if not strictly followed, could result in a life-threatening situation, bodily injury or damage to equipment. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
  • Page 5: Foreword

    Also observe the corresponding rules and regulations valid in your state and or country. Stanley is not liable for the function of the machine when used in an improper manner and for other than the intended purpose.
  • Page 6: Safety

    It should be noted that parts and special equipment not supplied by Stanley are not approved by Stanley . The instal- Parking the machine lation and/or the use of such products can also affect the active If possible, park the machine on a level, firm surface.
  • Page 7 SAFETY Refuelling Disposal of the machine after finish of its service life Only refuel the machine with the engine switched off. Do not At disposal of the machine after finish of its service life, the owner refuel the machine in enclosed areas. is obliged to comply with national regulations and laws on wastes Avoid naked flames, no smoking.
  • Page 8: Technical Data

    TECHNICAL DATA SRA 60 SRA 68 1. DIMENSIONS 340 MM / 13.3 IN 280 MM / 11 IN 710 MM / 28 IN 1020 - 1120 MM / 40.1 IN - 44 IN 355 MM / 14 IN 2. WEIGHTS SERVICE WEIGHT (CECE) 62 KG / 136.6 LB...
  • Page 9 TECHNICAL DATA SRA 60 SRA 68 5. OPTIONAL EQUIPMENT CYCLONIC FILTER OPTION (STANDARD, NO GUAGE) TRANSPORTATION WHEELS OPTION - TRAILER ASSY P/N-75085 SEE PARTS MANUAL PAGE 27 BASE PLATE B=165 MM / 6.5 IN. OPTION (P/N-75348) BASE PLATE B=200 MM / 8 IN.
  • Page 10: Operation

    Follow Danger the safety instructions. The SRA 60 / 68 vibrating tamper is a reliable compacting Follow the operation and maintenance manual. device thanks to its stable, robust design. The engine drives the crank mechanism by a centrifugal Read the motor operating manual.Comply with its...
  • Page 11 OPERATION Engine Operation Start the Engine Low oil protection The motor is equipped with low oil protection: • If the motor oil is too low, the motor won't start. • Turn the fuel tap (3) «ON». • When the starter handle (1) is pulled, the control light (2) blinks.
  • Page 12 OPERATION After the motor starts • Turn the motor switch (6) to «ON». • Set the throttle lever to «MIN» (idle). • Let the motor warm up for one or two minutes. • Pull the starter handle (1) lightly until you feel resis- tance (I.), and then pull it hard all the way (II.).
  • Page 13 OPERATION Working with the tamper Shutting off the motor In emergency situations, turn the motor switch Setting the working height to «OFF» to shut off the motor. Important Setting the guide bar out of the optimal position can increase hand/arm vibration. This must be considered when determining the exposure period.
  • Page 14 OPERATION Operation • The rate of advance can be influenced in two ways: - By changing the tilt: Guide the machine only with the guide bar, and Forward tilt = forward quickly don't lift it during operation. Rearward tilt = forward slowly Always keep an eye on the machine when its Danger motor is running.
  • Page 15: Transport

    TRANSPORT Transporting and Loading Loading General Instructions The machine must only be transported or loaded with the motor off. Make sure that the machine does not endanger Danger people by tilting or sliding. Tie the machine down so that it is secured against rolling, sliding or tipping over.
  • Page 16: Maintenance

    MAINTENANCE General Information Careful maintenance: Extended life expectancy. • Ensure that fuels, lubricants and replacement parts are Higher functional reliability. disposed of in a safe and environmentally acceptable Lower idle times. manner. Higher reliability. • Avoid short-circuits on current-carrying cables. Lower repair costs.
  • Page 17 MAINTENANCE Lubrication Schedule Changing intervals Lubricating point Quantity Lubricant Order No. [operating hours] 1. Engine Honda GX100 0.4 l Engine oil First time after 20 h; API SG-CE 2-80601100 then every 100 h SAE 10W40 2. Tamping system Engine oil After 200 h 0.65 l API SG-CE...
  • Page 18 MAINTENANCE Motor Maintenance Checking the motor oil level This operating manual explains only the daily motor mainte- Collect used oil and dispose of it in an nance. Be aware of the motor operating manual and the environmentally sound way. maintenance instructions and intervals given in it. Do not let oil seep into the ground or sewer.
  • Page 19 MAINTENANCE Cleaning the Fuel Filter No open flame. No smoking. Danger Do not inhale fuel fumes. Do not spill fuel. Clean up leaking fuel. Do not let it seep into the soil. • Put the fuel filter (3) and the fuel tap (2) back on. Optionally use a new seal.
  • Page 20 MAINTENANCE Air Filter Replace the filter element: – when the filter element is damaged – if there is wet or oily contamination Attention – after six cleanings – if motor performance suffers – at least once a year When cleaning the machine with a pressure washer, do not hold it directly over the air filter or pre-separator.
  • Page 21 MAINTENANCE The visual maintenance display (8) allows the actual dirt level in the air filter to be read even when the motor is off. The yellow indicator bar has 12 stages. The display field shows the remaining air filter life as dirt builds up. Foam Air Filter •...
  • Page 22 MAINTENANCE Maintaining the Machine Tightening Torque Cleaning For cleaning, do not use any flammable or aggres sive materials. Attention When cleaning the machine with a pressure washer, do not hold it directly over the air filter. Strength grades for screws with untreated, unlubricated surfaces.
  • Page 23 MAINTENANCE Screw Connections Checking the Rubber Buffers Check the rubber buffers (1) for tears and breaks, as well as for secure fit. If they are damaged, replace them imme- diately. Checking the Bellows With vibrating devices, it is important to intermittently check the screw connections for tightness.
  • Page 24 MAINTENANCE Padfoot: Checking the oil level Padfoot: Changing the oil Use warm oil when changing the oil. • Stand rammer up vertically. • Shut off the engine. Important Perform the following tasks with extreme care and keep very clean. Let the vibrating tamper stand for a little while so Do not let any dirt or foreign objects fall that the oil can run back into the housing.
  • Page 25 MAINTENANCE • Stand the tamper back up, and screw in the oil sight glass (1) with its seal (2). • Pour fresh oil directly into the guide tube. • Clean the sealing surfaces between the cover (3) and the housing; avoid damage. •...
  • Page 26: Retrofit

    RETROFIT Padfoot Installing the shortener and extensions To change the working height, a tamping foot shortener and two extensions are available. To change, the adap- tor between the padfoot and the suspension strut must be replaced. • Lay the tamper on a firm, even surface (not on the carbu- rettor side).
  • Page 27: Troubleshooting

    • In the event of faults, refer to the operating and maintenance instructions for correct operation and maintenance. • If the fault cannot be located, refer repairs to Stanley Hydraulic Tools at the number listed on the back of this manual.
