Component and Connector Map
WLAN LED
Mini PCIe v2.0 Slot
at 4.0mm Height
(5GHz high power)
6x LED
Indicators
Mini PCIe v2.0 Slot
at 4.0mm Height
(2.4GHz high power)
WLAN LED
SD Card Socket
Copyright © Compex Systems. All rights reserved. COMPEX and the COMPEX logo, are registered trademarks of Compex Inc.
Atheros and other trademarks are properties of their respective owners. While every effort is made to ensure the information is accurate,
1
Compex does not accept liability for any errors or mistakes that may arise. All specifications are subject to change without notice.
Compex Systems Pte Ltd | www.compex.com.sg | (+65) 6288 8220 | sales@compex.com.sg | Last Updated: 08/02/2018 WH XG KG
hardware guide - wpq865 6B02
2x SIM Card Slot
2x e-SIM (optional)
Hardware Reset Button
Boot
config
NAND
flash
WLAN
Mini PCIe v2.0 Slot at 9.2mm Height
LED
Firmware Reset Button
Serial 4 Pin Connector
Boot
config
NOR
flash
WAN Port
PoE In
Ethernet
LAN Port 0
Ethernet
LAN Port 1
Ethernet
LAN Port 2
Ethernet
LAN Port 3
e-SATA
USB 3.0 Port
DC Jack
