GNS3 Receiver
Quick Start Guide
A) MCX ANTENNA PORT
B) USB TYPE-C PORT
C) LED FUNCTION
GPS/DGPS Fix
Bluetooth
Charging
Power
© Copyright Juniper Systems 09MAR22. All rights reserved. Part Number 30393-00
C
LIGHT OFF
No 3D GNSS
position
No connection
No external power
applied
Unit off
A
FLASHING LIGHT
3D GNSS position
N/A
Slow = charging
Fast = power fault
Battery low
B
SOLID LIGHT
Corrected position
Connected
Fully charged
Powered on
Advertisement
Related Manuals for Juniper geode GNS3
Summary of Contents for Juniper geode GNS3
- Page 1 3D GNSS position Corrected position position Bluetooth No connection Connected No external power Slow = charging Charging Fully charged applied Fast = power fault Power Unit off Battery low Powered on © Copyright Juniper Systems 09MAR22. All rights reserved. Part Number 30393-00...
- Page 2 OFF. HARDWARE RESET Geode and Geode Connect are trademarks of Juniper Systems, Inc. iPhone and iPad are trademarks of Apple Inc., registered in the U.S. This device has a hardware reset function. To and other countries and regions. App Store is operate, press and hold the power button: a service mark of Apple Inc.
