sensolus TRACK 1000 Replacement Manual

TRACK 1000 Battery replacement manual
Step 1
• Make sure that the serial number and logo are facing
the right way up.
• Then turn the tracker face down.
• Unscrew the 6 screws.
Tip: If using a power drill, use power setting 7, on low.
(Note: not all power drills have the same settings!)
Step 4
Place the chip so the connector is towards the holder.
Step 7
Make sure that the seal is completely flat/intact on the
back of the tracker.
www.sensolus.com | info@sensolus.com
Step 2
• Remove the back plate and the 6 screws.
Step 5
Insert new batteries. Position the new batteries and make
sure the batteries are in the center (on top of the sponge)
- not too low or too high.
Step 8
Close the case again by tightening the 6 screws in the
corresponding holes. Be careful not to break the casing
when using a power drill.
Step 3
Remove the batteries - pull them out of the
•
connector.
Tip: place a finger on the sponge to hold it in place
Step 6
Make sure the connector is inside the holder and that the
cable is tucked to the left-hand side.
Step 9
The green light on the front of the tracker will rapidly
flash green. From this moment, your asset tracker will
start sending activity (movement) and GPS location.
This information will be visible in the Sensolus Platform
if you find yourself in an area with Sigfox communication
network coverage.
