KNOWING YOUR LAWN MOWER

Please use the illustration below to familiarize yourself with the location and function of the
components that control of your lawn mower.
1
2
3
4
1 Recoil Starter handle
2 Grass catcher
3 Cutting height adjustment lever
4 Rear wheel
5 Side discharge chute
6 Oil dipstick
7 Front wheel
14
5 6 7
8
9
10
11
12
13
14
10
13 12
8
Cutting height adjustment lever
Primer bulb
Fuel tank cap
Rear discharge door
Lower handle
Upper handle
Engine start/stop control
