- Page 1 Instruction Manual Candy Apple Stoves Model No. 4110BG, 4110HD Stove shown with Kettle Item No. 4111 (sold separately). 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 USA © 2022 Gold Medal Products Co. Part No. 32006...
-
Page 2: Safety Precautions
Candy Apple Stoves Model No. 4110BG, 4110HD SAFETY PRECAUTIONS DANGER Gas is safe when used properly, but can be very dangerous when used improperly. We suggest that installation be carefully made by qualified personnel only. Gas companies have competent service personnel to provide safe installation. - Page 3 007_010914 Note: Improvements are always being made to Gold Medal’s equipment. This information may not be the latest available for your purposes. It is critical that you call Gold Medal’s Technical Service Department at 1-800-543-0862 for any questions about your machine operations, replacement parts, or any service questions.
-
Page 4: Installation Instructions
Medal Products Co., 10700 Medallion Drive, Cincinnati, OH 45241 USA 1-(800)-543-0862. Model Description 4110BG: Candy Apple Stove 4110HD: Heavy Duty Candy Apple Stove Items Included with this Unit Wood Spoon (PN 46207) (included with Model 4110BG only) Tank Regulator (PN 89920) Wood Paddle (PN 2093) Tank Hose (PN 109000) - Page 5 Candy Apple Stoves Model No. 4110BG, 4110HD Setup 1. Remove all packaging and tape prior to operation. 2. This unit is for outdoor use only. 3. Place unit in a level position on a surface strong enough to support it when in use. The unit must be placed in a non-combustible location with no trip hazards.
-
Page 6: Gas Requirements
Model No. 4110BG, 4110HD Gas Installation Instructions Gas Requirements The 4110BG and 4110HD are designed for Propane only. Converting the unit to an alternate fuel source will void the warranty and may cause a dangerous condition. 4110BG: Propane Gas, 34,557 BTU/HR 4110HD: Propane Gas, 52,000 BTU/HR NOTE: The unit must be attached to a minimum of 40 pound LPG cylinder. -
Page 7: Checking For Gas Leaks
Stop using the appliance immediately if damage is found, and contact a qualified professional to inspect and correct any issue. 3. Securely route all gas lines away from flames and high temperature areas. 4. Contact Gold Medal Technical Support, or a qualified Gas Service Technician with any questions. Gas Pressure We have determined that optimum cooking occurs when the gas pressure is adequate. - Page 8 Candy Apple Stoves Model No. 4110BG, 4110HD gmpopcorn.com Page 8...
- Page 9 Candy Apple Stoves Model No. 4110BG, 4110HD gmpopcorn.com Page 9...
- Page 10 Candy Apple Stoves Model No. 4110BG, 4110HD gmpopcorn.com Page 10...
- Page 11 Candy Apple Stoves Model No. 4110BG, 4110HD gmpopcorn.com Page 11...
- Page 12 Candy Apple Stoves Model No. 4110BG, 4110HD gmpopcorn.com Page 12...
- Page 13 Candy Apple Stoves Model No. 4110BG, 4110HD OPERATING INSTRUCTIONS Controls and Their Functions GAS SAFETY VALVE The Gas Safety Valve has three settings used to control gas flow; PILOT, ON, and OFF positions. (Reference the Lighting and Shutdown Instructions in the Operating Instruction section of this manual.)
-
Page 14: Lighting And Shutdown Instructions
Candy Apple Stoves Model No. 4110BG, 4110HD Lighting and Shutdown Instructions Steps to Light the Pilot and Burner: 1. Turn the Gas Safety Valve to the PILOT position. 2. Depress the Safety Valve Button next to the safety valve handle. Hold this button down for 30-45 seconds. - Page 15 The large 5½" long, round Northern wood stick is preferred. The length makes small apples seem larger. Gold Medal also sells the smaller 4½" lengths for economy. The round geometry makes spinning the apple in the pot easier than flat or square sticks.
- Page 16 Candy Apple Stoves Model No. 4110BG, 4110HD Dipping the Apples Make sure apples are cleaned and sticks are inserted. When temperature is 275°F, turn heat OFF. 1. Pick up apple by stick, with thumb and index finger, insert into candy apple coating (immersing entire apple).
-
Page 17: Care And Cleaning
Candy Apple Stoves Model No. 4110BG, 4110HD Care and Cleaning WARNING To avoid burns, DO NOT touch heated surfaces. DO NOT place or leave objects in contact with heated surfaces. 009_092414 Good sanitation practice demands that all food preparation equipment be cleaned regularly (only use non-toxic, food grade cleaners). -
Page 18: Maintenance Instructions
Candy Apple Stoves Model No. 4110BG, 4110HD THE FOLLOWING SECTIONS ARE FOR QUALIFIED SERVICE PERSONNEL ONLY MAINTENANCE INSTRUCTIONS DANGER Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Any alterations to this equipment will void the warranty and may cause a dangerous condition. This appliance is not intended to be operated by means of an external timer or separate remote-control system. -
Page 19: Ordering Spare Parts
4. Please include your model number, serial number, and date of manufacture (located on the machine nameplate/data plate) with your order. 5. Address all parts orders to Parts Department, Gold Medal Products Co., 10700 Medallion Drive, Cincinnati, Ohio 45241-4807 or place orders by phone or online:... - Page 20 Candy Apple Stoves Model No. 4110BG, 4110HD Stove Unit - Parts Breakdown Aluminum Tubing 11, 12 (not shown) 16 17 Leg Assembly (mounting brackets are preinstalled) To replace an old-style leg, replace all three as a set to make sure unit sits correctly.
- Page 21 Candy Apple Stoves Model No. 4110BG, 4110HD Stove Unit - Parts List Part Number Item Part Description 4110BG 4110HD JET BURNER UNIT 32001 C-90 BURNER 32036 BURNER CLIP 105003 105003 BURNER MOUNT 105002 105002 PRESSURE REGULATOR 74115 89916 ADAPTER, GAS LINE 3/8 NPT (Flare Pipe Fitting, use...
-
Page 22: Warranty
© 2022 – The text, descriptions, graphics, layout, and other material in this publication are the exclusive property of Gold Medal Products Co. and shall not be used, copied, reproduced, or published in any fashion, including website display, without its express written consent.
