- Page 1 AirSentry® II IMS Calibration Quick Guide Without measurement there is no control...
- Page 2 AirSentry II Calibration Station Calibration Station The AirSentry II Calibration Station allows users to calibrate the AirSentry II IMS to a specific calibration stream concentration. An internal pneumatic diagram of the calibration station is included on page 9 for reference, if needed.
- Page 3 Note After installing the permeation tube, allow 24 to 48 hours elapse time prior to calibrating an AirSentry II IMS analyzer. This time allows for the permeation device to warm up and near its expected permeation rate. Most permeation tubes will have reached equilibrium five to seven days after installation.
- Page 4 Without measurement there is no control As an example, a 0 - 50 ppbv Amines analyzer would be span calibrated at 25 ppbv. The span calibration provides a correction factor to adjust the calibration curve appropriately. Because most users are sampling in a wet environment (where the RH > 5%), a wet span calibration is most appropriate.
-
Page 5: Calibration Procedure
The AirSentry II IMS was designed so that it can be easily calibrated by disconnecting it from its sampling location and moving it to the location of the calibration station. The AirSentry II IMS is then set on top of or next to the calibration station allowing the various utilities to be shared between the instruments. - Page 6 Without measurement there is no control Figure 4 AirSentry II IMS - Pneumatic Setup (With Calibration Station) 5475 Airport Boulevard +-303-443-7100 info@pmeasuring.com Boulder, CO 80301 +1-800-238-1801 www.pmeasuring.com +1-303-449-6870 Page 5...
- Page 7 1. Verify that all utilities are connected and working properly for both the calibration station and the AirSentry II IMS. Note The best way to set the CDA pressure to 5 psi is to connect the AirSentry II IMS via the Service Software. The Press CDA column, located on the Control tab, digitally indicates the CDA pressure in kilopascals.
- Page 8 9. Re-verify that all utilities are connected and working properly for both the calibration station and to the AirSentry II IMS. 10. Verify that the AirSentry II IMS has a source of vacuum installed on the vacuum fitting (> 15 in. Hg is required).
- Page 9 Without measurement there is no control Preventive Maintenance – AirSentry II Calibration Station Calibration Station Service & Parts Description Time Interval Part Number Quantity Calibration Station Pump 1 Year 1000006584 1 per calibration system Diaphragm Kit Acids Permeation Tube 1 Year 1000012381 1 per calibration system Ammonia Permeation...
- Page 10 Without measurement there is no control Calibration Station A pneumatic diagram is included here for troubleshooting the AirSentry II calibration station, if needed. However, it is highly unlikely that you will need to remove the lid of the calibration station for troubleshooting purposes.
- Page 11 Without measurement there is no control Flowrates — Calibration Station Typical flowrates for the calibration station’s various analyzers are described in Table 4. Flow Type How to Measure Ammonia and Acids (cc/min) Amines (cc/min) Place calibration station into ZERO and either Span Oven Flow RUN or STANDBY.
