Page 1: Table Of Contents
Installation Guide Refer to the Release Notes for information on supported software applications and versions. Note: This document applies to the B2-800-QD-4-T1S and B2-800-OSFP-4-T1S appliances. The term B2-800 appliance will be used throughout. • Getting Started ..4 •...
Page 2 The information contained in this document is subject to change without notice and does not represent a commitment on the part of Spirent Communications. The information in this document is believed to be accurate and reliable, however, Spirent Communications assumes no responsibility or liability for any errors or inaccuracies that may appear in the document.
Page 3 Spirent B2-800 Appliance Installation Guide right to change the warranty and service policy set forth above at any time, after reasonable notice and without liability to Customer. TO THE EXTENT PERMITTED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO IMPLIED WARRANTIES OF...
Page 4: Getting Started
Getting Started The B2-800 appliance is operated with specialized software designed to help you create and analyze realistic traffic for determining the operating characteristics of a device, system, or network under test. Due to the powerful traffic generating capabilities of the B2-800 appliance, precautions should be taken when connecting the test ports to an operational network.
Page 5: Certifications And Standards
Connect the appliance test ports to your device or system under test. Certifications and Standards Spirent B2-800 appliance complies with the limits for a Class A digital device in accordance with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when this equipment is operated in a commercial environment.
Page 6 Spirent B2-800 Appliance Installation Guide Certifications and Standards The CE symbol on the product label (on the back of the box) indicates this network appliance meets all of the Class A specification limits defined by the FCC Code of Federal Regulations Title 47, Part 15, Subpart B, European Standards.
Page 7: Site Selection
Spirent B2-800 Appliance Installation Guide Site Selection Site Selection The Spirent B2-800 appliance is a high-end network testing device that must be installed in a dust free and dry environment with adequate airflow, power, and cooling. • The appliance is designed with front to rear airflow and both ventilation locations must remain unobstructed for proper operation.
Page 8: Rack Mounting Considerations
Spirent B2-800 Appliance Installation Guide Rack Mounting Considerations • Power • Two (2) power supplies • Inlet AC: Two each of 110-127VAC @15A Nominal or 208-240VAC @10A Nominal. • Peak power requirement: 1,000W per PSU • Administration and Operation •...
Page 9: Requirements
Spirent B2-800 Appliance Installation Guide Requirements Requirements This section describes the appliance system requirements, cable requirements, and network connectivity. Refer to Table 1 on page 11 for connector descriptions. Power Requirements Important: The B2-800 appliance mu be connected to a dedicated 208-240VAC @10A or 110-127VAC @15A circuit with no other connected equipment and its own breaker.
Page 10: System Description
The appliance hardware is maintenance-free and should not be disassembled. Servicing the units yourself jeopardizes your warranty. Connector Panel Figure 2 shows the connector panels for the B2-800-QD-4-T1S and B2-800-OSFP-4-T1S appliance models. Table 1 on page 11 describes the appliance connectors.
Page 11 Spirent B2-800 Appliance Installation Guide System Description Table 1. B2-800 Appliance Connectors Connector Description – Power switch press this button to power on and off the appliance. QSFP-DD800 test ports - take care to insert QSFP-DD800 transceivers or cables in the proper direction.
Page 12 Spirent B2-800 Appliance Installation Guide System Description Front Panel System LEDs The LEDs located on the front of the appliance show the status of the appliance and the PC connection. Table 2 describes the operation. Table 2. Front Panel System LEDs...
Page 13 Spirent B2-800 Appliance Installation Guide System Description Test Port LEDs Each test port has one multi-color LED to indicate the speed for which the port is configured. The SPEED LEDs are labeled on the front panel. Table 3 describes the speed LEDs.
Page 14 Spirent B2-800 Appliance Installation Guide System Description Test Port Link LED Numbering The test port link LEDs are numbered as shown in Figure 3. Only the number for the first port of each column is labeled on the front panel of the appliance.
Page 15: Appliance Firmware Support
Spirent B2-800 Appliance Installation Guide Appliance Firmware Support Powering down the Appliance Press and release the power button on the front of the unit (Figure 2 on page 10) to turn off the appliance. Warning: Do not unplug the appliance while it is in operation (blue indicator light on).
Page 16: Connecting To The Appliance
Spirent B2-800 Appliance Installation Guide Connecting to the Appliance Connecting to the Appliance The appliance connects and operates through your local network much like a standard PC. It boots with the IP address and subnet mask: . Refer to 192.168.0.100/255.255.255.0 “Setting the Addressing mode, IP Address, Netmask and Gateway”...
Page 17 Spirent B2-800 Appliance Installation Guide Connecting to the Appliance You can now use the following commands to set the addressing mode and/or set the IP address, netmask and gateway. When you have made your changes, you must activate the new settings and reboot the appliance: admin(hypervisor)>>...
Page 18 Spirent B2-800 Appliance Installation Guide Connecting to the Appliance Table 6. Spirent Admin Commands Command Description activate [[<deviceName>]<ipaddress> Save and activate the network configuration <netmask> <gwaddress>] | [dhcp] | [ipv6 [<deviceName>] <ipv6addres> <ipv6gwaddress>] authenticate [on|off|reset] Enable | Disable | Reset authenticate mode console <vm name>...
Page 19 Spirent B2-800 Appliance Installation Guide Connecting to the Appliance Table 6. Spirent Admin Commands (continued) Command Description ping6 <ipv6address> Ping an IPv6 address Display or change the ptp settings reboot Reboot the system recovery <chassis|tm> <enable|disable> Enable or disable appliance or test module recovery (Test...
Page 20 Spirent B2-800 Appliance Installation Guide Using Authenticate Mode (optional) Using Authenticate Mode (optional) Authenticate mode allows the user to set a password on a chassis or appliance, so only authorized users can access the equipment. The Authenticate commands can only be accessed when the user is directly connected to the chassis or appliance using a USB keyboard and DVI video monitor.
Page 21: Related Documentation
Spirent B2-800 Appliance Installation Guide Related Documentation Related Documentation Additional documentation related to this guide is listed below. • Release Notes – Contains information that may affect product installation, test configuration, or test results; including last-minute requirements or product changes.
Page 22: How To Contact Us
Phone: +86 (400) 810-9529 (toll-free mainland China only) Phone: +86 (10) 8233 0033 (China) Hours: Monday through Friday, 09:00 to 18:00, Beijing Time Information about Spirent Communications and its products and services can be found on the main company website at https://www.spirent.com. Company Address Spirent Communications, Inc.
