QUICK SETUP GUIDE
Congratulations on your purchase of a DURABRAND DVD/VCR. This Quick Setup Guide takes
you through the first-time setup with simple instructions so you can enjoy exceptional audio and
video quality as soon as possible. Please refer to the Owner's manual for detailed instructions. If you
have read your instructions and still need assistance, call ASDA helpline at
Unless stated, all procedures described use the remote control.
Loading Batteries in the Remote Control
1) Open the battery cover.
Connecting to a TV
VHF/UHF
UHF
MIXER
AERIAL
RF OUT
DVD
AERIAL
DIGITAL ANALOG S-VIDEO
AUDIO OUT AUDIO OUT OUT
VCR AV2 (DECODER)
L
COAXIAL DVD/VCR AV1 (TV) RF OUT
R
scart cable
RF cable
(supplied)
(supplied)
to 21-pin
scart jack
(TV) to aerial socket
PAL I_EN
for AD980BD
0870 3833010.
2) Insert two R6 (AA) batteries, 3) Close the cover.
with the (+) and (-) ends
in the correct positions.
WARNING!
VHF
Never make or change connections with
the power switched on.
1) Disconnect the antenna or cable from the
TV and connect it to the AERIAL jack of the
VHF/UHF
unit.
MIXER
2) Connect the RF OUT jack of the unit
to the antenna in jack of the TV using the
supplied RF cable.
3) Connect the AV1 (TV) scart jack of the
unit to the scart input jack of the TV
using the supplied scart cable.
4) Plug in the TV and the unit.
Note:
• Playback picture from DVD and VCR
cannot be delivered through the RF
cable. The RF cable is only for sending
the antenna signal to the TV.
1VMN23180
E8D81BD *****
Clock Setting
Setting the Clock
This unit incorporates a 24-hour clock.
The clock must be set for the Timer Recording function
to operate correctly.
1) Press , then .
2) Press or to select "INITIAL" then press ,
3) Press or to select "CLOCK" then press ,
4) Use , or to select current year, month,
date, hour and minutes.
5) Press to start the clock.
Note:
• Press to go back to the item you want to correct during step 4).
• Although seconds are not displayed, they begin counting from 00 when you exit
by pressing .
Use this feature to synchronize the clock with the correct time.
• If the unit is unplugged or if there is a power failure for more than 30
seconds, you may have to reset the clock.
Channel Presetting
Channel Presetting
Tuning of broadcast channels not already preset in the unit can be
performed in two ways.
Automatic Channel Preset
1) Turn on the TV and select the channel set as
the video channel on the TV.
2) Press , then .
,
3) Press or to select "INITIAL"
then press .
,
4) Press or to select "CH TUNING"
then press .
,
5) Press or to select "AUTO"
then press .
MENU
TIMER
SET UP
INITIAL
INITIAL
. CH TUNING
CLOCK
.
CLOCK
YEAR 2 0 0 6
MONTH 0 1
DAY 0 4 WE
_ _
HOUR
_ _
MINUTE
MENU
TIMER
SET UP
INITIAL
INITIAL
CH TUNING
CLOCK
CH TUNING
AUTO
MANUAL
MOVE
Scanning
