- Page 1 Li-Ion Portable Power Generator PG700 - 700W 1150Wh Ruggedised Inverter Power Station Operating Manual Revision 1.0 www.blueshape.net Printed in Malta 2022...
-
Page 3: Explanation Of Symbols Used In This Manual
This manual contains important safety and operating instructions for the PG700 power-generator (the device). Explanation of symbols used in this manual This symbol indicates the presence of an electrical shock hazard. It is intended to avert users not to open the product as there are no user-serviceable parts inside. -
Page 4: General Safety Instructions
General Safety Instructions Warning Earth the power-generator before using it as a power source to any other device or equipment. To earth the power-generator, remove one any of the four front-facing panel cap nuts and attach an earthing lead with an M6 ring terminal. The other end of the earthing lead must be terminated with: - an earth rod inserted into the ground or - a crocodile clip attached to a conductive earthed structure. - Page 5 This device outputs voltages that can cause injury or death. DANGER ELECTRIC SHOCK Danger - Do not disassemble or modify the device. - Do not discard the device into fire or heat. - Do not leave the device near a heat-source such as a fire or heater.
-
Page 6: Package Contents
- Do not obstruct ventilation - always operate the device with the lid wide open. PG700 Package Contents The PG700 package contains the following: - PG700 portable power generator - AC power cord [according to region] Device-End Connector: IEC 60320 C13... - Page 7 This is an all-in-one product, which also features built-in charging capability. The PG700 is built in a rugged portable hard case. When the lid is closed for storage and handling; it can withstand shocks as well as dust and water ingress.
-
Page 8: Graphic Description
Graphic Description Storage and Handling The PG700 is constructed in a rugged hard-case and consists of the following: 1. Telescopic Handle 2. Upright Carry Handle 3. Enclosure Lid 4. Roller Wheels 5. Lid Latches 6. Mid Carry Handle... - Page 9 Operation The PG700 front facing panel consists of the following: 1. Exhaust Fans 2. Silent Charging Switch 3. Front Panel Cap Nuts 4. Charge AC Input Socket 5. Mains Outlet 6. Mains Output Switch 7. Intake Ventilation 8. Display...
- Page 10 Operating Instructions This section details the operational procedure for this power-generator. The last sub-section details the different statuses, warnings and errors shown on the display. Charging the Device To charge the device: 1. Switch off mains output switch 2. Connect the provided IEC 60320 C13 lead into the socket labelled ‘charge in’.
- Page 11 Operating the Device in Inverter Mode To use the mains output: 1. Connect a compatible mains cable to socket labelled ‘AC Output’. 2. Press the switch to the on position. Unless the device is equipped with a universal mains socket, be sure to match the mains cable with the socket fitted in the device.
- Page 12 Notes on Inverter Mode Behaviour This device is equipped with multiple safety features to safe-guard use and device longevity. - If the electrical load attached to the device is in excess of the power generator’s maximum power rating, an audible alarm will sound to alert the user.
- Page 13 Operating the Device in Online UPS Mode - 200W This power-generator can also function as an Online UPS, only if the electrical load is less than 200W. Loads larger than 200W will eventually deplete the internal batteries nonetheless. To use the device in UPS mode: 1.
- Page 14 Status, Warnings and Errors This section details the different warnings and errors which may be shown on the last line of the display. 4 % ~ - - - - - - - - - - - - - - - 7 0 0 W E m p t y i n :...
-
Page 15: Technical Specifications
Technical Specifications The PG700 comes in different model variants. To clarify your model number, check the front panel markings. Parameter Specification 240/110 V AC 50/60 Hz Output Voltage (Model Dependant) Max. Continuous AC Power Output 700 W Max. Instantaneous AC Power Output... -
Page 16: Storage And Handling
If for some reason, the pack temperature reaches 60°C, then the discharge activity is suspended. The pack resumes normal charging once the temperature drops back to below 50°C. This is a safety feature incorporated in all BLUESHAPE battery packs. Disposal Instructions... - Page 17 This page has been intentionally left blank.
- Page 18 This page has been intentionally left blank.
-
Page 20: Warranty
Warranty BLUESHAPE batteries are warranted to be free from defects in materials, workmanship and functionality for a period of 18 months commencing from the date of purchase. This warranty shall not apply to any products or parts there-of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation.
